- Page 1 OPERATION MANUAL CARBON MONOXIDE METER Model: 7701...
- Page 2 INTRODUCTION Congratulations on your purchase of this digital pen type CO meter. Please read the manual completely before using the meter. Features: Adjustable CO warning level Dual and digital display Backlight for operating in dark area Low battery indicator Auto power off function CO levels and its effect Symptoms and applicable standard Normal background levels...
-
Page 3: Controls And Indicators
CONTROLS AND INDICATORS LCD display 8888 1888 1.Primary display: Current CO value. 2.Secondary display: Max. CO value. : Low battery indicator. Function Keys :Turn the meter on and off. Select the alarm value. :Turn on and off the backlight. Switch temperature unit C and F. Reset the maximum CO value. - Page 4 2. Switch temperature units Users can select C or F as temperature unit by pressing more than 1 sec. during Self-Test. Alarm setting The meter is preset the alarm value at 25ppm to give warnings of possible danger. Users can adjust the value for different needs or standard by turning off the meter, then press and hold...
- Page 5 CALIBRATION To enter the calibration mode, turn off meter and press simultaneously for 2 seconds. It will show blinking ppm on the upper display and calibration value "0" at lower side. Now the meter is running 0ppm calibration as default. 0ppm calibration The meter is preset calibration value at 0ppm.
-
Page 6: Troubleshooting
OPERATING NOTICE 1.Keep the meter from electromag- netic interference(EMI) which may cause erratic readings. 2.Recovering time is required when meter exposed to high level CO. The longer the exposure, the longer recovering time is needed. 3.Self-Test after power on is to test the sensor and circuit condition. - Page 7 SPECIFICATION 1.CO range: 0~999ppm 2.Resolution: 1 ppm 3.Accuracy: +/- 20% at 0~100ppm +/-15% at 100~500ppm (at 20+/-5 , 50+/-20%RH) 4.Battery: 3 AAA alkaline. Battery life is 250 hours when backlight off and 35 hours when backlight on. MATERIALS SUPPLIED The meter x 1 AAA alkaline battery x 3 Operation manual x1 Wrist Strap x 1...
- Page 8 K type Thermometer K.J.T. type Thermometer K.J.T.R.S.E. type Thermometer pH Meter Conductivity Meter T.D.S. Meter D.O. Meter Saccharimeter Manometer Tacho Meter Lux / Light Meter Moisture Meter Data logger Temp./RH transmitter Wireless Transmitter ..More products available ! 2007/07,1000 www.ponpe.com...
