HD-1605 Single Input DVB-T HD Digital

Modulator with Delayed Audio Output

User Guide and Install Manual

SAFETY PRECAUTIONS..................................................................................................................................2

PACKAGE CONTENTS....................................................................................................................................2

PRODUCT DESCRIPTION...............................................................................................................................3

Features......................................................................................................................................................3

SPECIFICATIONS...........................................................................................................................................4

INSTALLATION..............................................................................................................................................5

UNPACKING and INSPECTION..........................................................................................................................................................................5

HARDWARE INSTALLATION and CONNECTIONS.....................................................................................................................................5

Reset to Default.......................................................................................................................................................................................................6

MODULATOR SETUP AND CONFIGURATION..................................................................................................7

DEVICE Programming and Setup.....................................................................................................................................................................7

Connec#ng to the GUI Interface:..................................................................................................................7

Front Panel LCD Encoder Menu Map...........................................................................................................................................................14

Modulator Con,iguration via Front Panel LCD.........................................................................................................................................15

Common Setup Menu..................................................................................................................................................................................................15

RF Setup Menu...............................................................................................................................................................................................................15

Encoder Setup Menu...................................................................................................................................................................................................16

Network Setup...............................................................................................................................................................................................................17

HD-1605 HD Encoder/Modulator Notes......................................................................................................18

TABLE OF CONTENTS

digi-MOD HD-1605

www.digi-modbyzycast.com

HD-1605 Manual V1.0

Table of Contents

Need help?

Do you have a question about the HD-1605 and is the answer not in the manual?

Questions and answers

Summary of Contents for dig-MOD HD-1605

Page 1: Table Of Contents
HD-1605 www.digi-modbyzycast.com HD-1605 Single Input DVB-T HD Digital Modulator with Delayed Audio Output User Guide and Install Manual TABLE OF CONTENTS SAFETY PRECAUTIONS..........................2 PACKAGE CONTENTS............................2 PRODUCT DESCRIPTION..........................3 Features..............................3 SPECIFICATIONS............................4 INSTALLATION..............................5 UNPACKING and INSPECTION..................................5 HARDWARE INSTALLATION and CONNECTIONS.............................5 Reset to Default........................................6 MODULATOR SETUP AND CONFIGURATION....................7 DEVICE Programming and Setup..................................7 Connec#ng to the GUI Interface:........................7 Front Panel LCD Encoder Menu Map................................14...
Page 2: Safety Precautions
If the device has been in a cold environment allow it to warm to room temperature for at least 2 hours before connecting power PACKAGE CONTENTS This package contains: One HD-1605 HD Digital Modulator One Power Adaptor One User Guide and Install Manual Inspect the package before starting installation to ensure there is no damage and all supplied contents are present.
Page 3: Product Description
Gain adjustment. The unit's front-mounted LCD display allows for easy configuration and adjustments. The compact and economical HD-1605 Modulator is perfect for multi-video distribution solutions in the commercial and institutional market (hotels, motels, sports bars, restaurants, hospitals, casinos, business and university campuses, digital signage, etc.) as well as home entertainment systems.
Page 4: Specifications
Power Supply 12 VDC 3 Amp. Consumption 1200 mA Operating Temperature 0 C to +45 Storage Temperature C to +60 Languages English Dimensions 236mm x 155mm x 35mm Weight 1000g *Specifications subject to change without prior notice HD-1605 Manual V1.0...
Page 6: Reset To Default
SAVE & EXIT. 5. Press OK button to Save and Exit. Caution: Once this process is complete the unit will automatically reset to the factory default settings. All settings or changes to the encoder/modulator will be lost. HD-1605 Manual V1.0...
Page 7: Modulator Setup And Configuration
Note - The installer can enable DHCP via front display - under "Network Setup"section if desired (Default "DISABLE") Connecting to the GUI Interface: Factory Default IP: 192.168.1.9 1. Connect an Ethernet cable directly (no Cross Over cable required) to the Web Management Port on the rear panel of the encoder or connect the Ethernet cable to an Ethernet switch. Connect an Ethernet Cable to your PC/Laptop. 2. Modify your PC/Laptop IP address to 192.168.1.11. 3. Enter ‘192.168.1.9’ into your web browser. 4. The Welcome Page will shown. Welcome page will be displayed as shown HD-1605 Manual V1.0...
Page 8 Select the Common Setup tab. User will be presented with encoders 'Authentication Required' screen. Enter User Name and Password. User Name: admin Password: Admin123 HD-1605 Manual V1.0...
Page 9 Common Setup Remark: The Attenuation in the Common Setup is reserved. Please adjust the attenuation by adjusting the Gain control from the unit. HD-1605 Manual V1.0...
Page 10 RF Setup HD-1605 Manual V1.0...
Page 11 Encoder Setup HD-1605 Manual V1.0...
Page 12 Network Setup HD-1605 Manual V1.0...
Page 13 Administration HD-1605 Manual V1.0...
Page 14: Front Panel Lcd Encoder Menu Map
Program Output DHCP Channel Guard Delayed Channel IP Address Interval Audio Name OFDM Mode Device Provider Subnet Address Name mask TS ID Default Gateway Con,ig Back to Network ID HDCP Back to Main Main Audio Network ID output Network Back to Name Main Back to Main HD-1605 Manual V1.0...
Page 15: Modulator Con,Iguration Via Front Panel Lcd
Scroll Up/Down buttons to select the desired Output Channel. Once the desired output channel is selected press the OK button to set the channel. The LCD Display will show both the channel number and the frequency number of the output channel (example: 39 (606.5 MHz)) Delayed Audio – Use the Scroll Up/Down button to change the Delayed Audio. Use the Scroll Up/Down buttons to select the desired delay from 0~20000ms. Once the desired delay is selected press the OK button to set. Device Address – Use the Scroll Up/Down button to select Device Address. Press the OK button to enter the Device Address menu. Use the Scroll Up/Down to select the Desired Address ranging from 1 to 255 then press OK to set. A unique device address is required if setting up more than 1 encoder per site. This allows the user to distinguish each device. Default Con0iguration –To reset the Encoder/Modulator back to the factory default select the Default Con,iguration Menu. Press OK to enter the Default Con,iguration Menu. There are three options that you can choose. Using the Up/Down button select No, New Zealand and Australia. Press OK to reset all programmed settings back to the factory default setting. Back to Main- Select Back to Main to escape the Common Setup Menu. RF Setup Menu - The FEC is default 7/8. GUARD INTERVAL – The GUARD INTERVAL is default 1/32. OFDM - Use the Scroll Up/Down button to select the OFDM menu. Press the OK button to enter the OFDM menu. Use the Scroll Up/Down to select the OFDM 2K or 8K. Press OK to set. TS ID – Use the Scroll Up/Down button to select TS ID. Press the OK button to enter the TS ID menu. Use the Scroll Up/Down button to select the desired Stream ID ranging from 1 to 65535 then press the OK button to set. Network ID – Use the Scroll Up/Down button to select Network ID. Press the OK button to enter the Network ID menu. Use the Scroll Up/Down button to select the desired Network ID ranging from 1 to 65535 then press the OK button to set. HD-1605 Manual V1.0...
Page 16: Encoder Setup Menu
to select the HDCP menu. Press the OK button to enter the HDCP menu. Select Enable / Disable, and press OK to set. NOTE: It is the installers / property owner / integrator's responsibility to contract with the service provider regarding content authorization and the use of HDCP. Audio Output Use the Scroll Up/Down button to select Audio Output. Press the OK – button to enter the Audio Output menu. Use the Scroll Up/Down button to select the Audio Output option: MP2 (MPEG1 Layer2 Audio), AAC. Factory default: MP2. Press the OK button to set. HD-1605 Manual V1.0...
Page 17: Network Setup
Network Setup DHCP – Use the Scroll Up/Down button to select DHCP. Press the OK button to enter the DHCP menu. Use the Scroll Up/Down button to Enable/Disable. Press the OK button to set. IP Address – Use the Scroll Up/Down button to select IP Address. Press the OK button to enter the IP Address menu. Use the Scroll Up/Down button to enter the IP Address. Use the Scroll Up/Down menu to select the desired IP Address then press the OK button to set. Repeat the process until the IP Address is completed. Press the OK button to set. Note: If DHCP is enabled you will not be able to set an IP address. Select DHCP disabled if Static IP Address required. Subnet Mask – Use the Scroll Up/Down button to select Subnet Mask. Press the OK button to enter the Subnet Mask menu. Use the Scroll Up/Down button to enter the Subnet Mask. Use the Scroll Up/Down menu to select the ,irst number of the desired Subnet Mask then press the OK button to set. Repeat the process until the Subnet Mask is completed. Press the OK button to set. Gateway – Use the Scroll Up/Down button to select Gateway Address. Press the OK button to enter the Gateway Address menu. Use the Scroll Up/Down button to enter the Gateway Address. Use the Scroll Up/Down menu to select the ,irst number of the desired Gateway Address then press the OK button to set. Repeat the process until the Gateway Address is completed. Press the OK button to set. Select Back to Main to escape the Web Management Network Setup Back to Main- Menu. HD-1605 Manual V1.0...
Page 18: Hd-1605 Hd Encoder/Modulator Notes
HD-1605 HD Encoder/Modulator Notes PRODUCT NOTES: ITEM VALUE DEVICE NAME PURCHASE DATE INSTALLATION DATE SERIAL NUMBER FIRMWARE VERSION HD-1605 Manual V1.0...
Page 19 N N N N o o o o t t t t e e e e s s s s HD-1605 Manual V1.0...
Page 20 In the event of any warranty claim please contact your place of purchase and it will be forwarded it to the manufacturer. The manufacturer will then determine the extent of their liability. HD-1605 Manual V1.0...
