InnotechRV TPMS-400 Quick Setup Instructions

Charging

1. Before installing the InnoTechRV.com TPMS system first ensure the monitor is fully charged by
plugging it into a vehicle 12V adaptor for at least 6 hours
2. Turn the monitor on by pressing the middle button.

Programming Sensors (Alignment Mode)

1.
Slide a battery into each sensor
cap. Do not over tighten as this may damage the o-ring and/or cap.
2. Put the monitor into Tyre Alignment Mode by pressing and holding the left and right buttons
simultaneously until the monitor beeps.
3. Press the left or right button to select the tyre position you wish to install a sensor on.
4. Screw a sensor onto that wheel. The sensor will immediately align with the monitor, the LED will
light green and the monitor will show the current tyre pressure.
- -" still shows at the top of the monitor display then the sensor has not alligned. Remove the
sensor, remove and replace the battery and replace the sensor on the tyre.
5. Repeat steps 2 and 3 for all tyre positions.
6. When finished installing sensors, press and hold the left and right buttons again until the monitor
beeps.

Programming Individual Tyre Pressures

1. Once all sensors have been installed and aligned and you have taken the monitor out of alignment
mode, press and hold the middle button until the monitor beeps. The first programmed tyre
position will flash and the default pressure level will show.
2. Press the left or right buttons to decrease or increase the desired normal cold tyre pressure level
for that wheel position.
pressed but holding the button will rapidly increment the pressure level.
3. Press the middle button to move to the next tyre and repeat step 2 until the normal cold tyre
pressures for all wheels have been preset.
4. Once the pressures for all wheels have been set, the next press of the middle button will show
pressure units and by pressing the left or right buttons you can change between PSI and bar.
5. Pressing the middle button again will take you to temperature units and pressing the left or right
buttons you can change between F and C.
6. Pressing again will take you to the LoOFF function. Please refer to the New Features sheet.
7. Once you have set your temperature units, hold down the middle button for 5 secs until the monitor
beeps. You have now finished programming.
Australia
WiPath Communications Pty Ltd (ABN: 86 093 464 496)
Postal: PO Box 227, Chester Hill, NSW 2162, Australia
Street:13/10 Straits Ave, South Granville, NSW 2142, Australia
P: +61-2-8004 0535 F:+61-2-9681 4010 E:info@wipath.com.au
TPMS-4000 Tyre Pressure Monitoring System
Quick Setup Instructions
(UNDER the metal terminal with +ve side UP) and replace the
Note; the pressure will increment by 0.1 psi each time the button is
New Zealand
WiPath Communications Ltd
Postal: PO Box 8798, Symonds St, Auckland 1150, NZ
Street: 3/2 Haultain St, Eden Tce, Auckland, New Zealand
P: +64-9-302 1142 F:+64-9-302 1148 E:info@wipath.co.nz
If the red LED light stays on and "-
USA
WiPath Communications LLC
4845 Dumbbarton Court, Cumming, GA 30040
P: +1-770-844 6218 F:+1-770-844 6574
E: info@wipath.com
PTO....
