Summary of Contents for S:FLEX LEICHTmount 2.1 E/W
- Page 1 Photovoltaic Mounting Systems Assembly Instructions LEICHTmount 2.1 Aerodynamic flat roof system for east/west orientation © S:FLEX GmbH 02/2017/ Subject to technical modifications...
-
Page 2: Table Of Contents
LEICHTmount System User Agreement Warranty Warranty / Product Liability (Exclusion) • • S:FLEX GmbH Reinbeker Weg 9 21029 Hamburg Tel. +49-(0)40-68893170 Sasbacher Straße 7 79111 Freiburg Tel. +49-(0)761-888 56 08-0 © S:FLEX GmbH 02/2017/ Subject to technical modifications info@sflex.com www.sflex.com... -
Page 3: Introduction
(PES fleece, plasticizer-free) and all necessary small parts to ensure easy and safe installation. The LEICHTmount 2.1 E/W is designed for the installation of systems with an east/west orientation and a pitch angle of 10°. The system is configured for transverse module installation. It can be used for almost all commercially available modules with the following dimensions: module width 950 –... -
Page 4: Warnings
Richtschnur the quality of the roofing, adequate attachment of the roof covering to the substructure, and the maximum load- Die nachfolgend aufgeführten Dokumente sind Hinweise der S:FLEX GmbH und erheben nicht den bearing capacity of the roof covering). Anspruch auf Vollständigkeit. Jede Person, die S:FLEX PV-Befestigungssysteme montiert, ist verpfl ichtet sich selbständig über alle Regeln und Vorschriften für eine fachlich korrekte Planung und Montage zu... -
Page 5: Installation
1.5 Installation 1.5 Installation This installation guide is designed to assist the installation of the S:FLEX LEICHTmount 2.1 E/W system on flat roofs. It 1.5 Installation is intended for use by personnel who have been trained by the operator of the PV system and possess the appropriate Diese Montageempfehlung dient der Installation des S:FLEX LEICHTmount 2.0 S Systems auf Flachdächern. -
Page 6: Standards And Guidelines
All individuals who install S:FLEX PV installation systems are obliged to independently inform themselves about all relevant rules and regulations relating to proper planning and installation, and to adhere to them during the installation process. -
Page 7: Description Of The System
Introduction 1.7 System description The LEICHTmount 2.1 E/W system includes solutions to suit a range of different requirements. System properties Mounting angle: the LEICHTmount 2.1 E/W is available with a 10° mounting angle Edge spacing: roof areas F and G can be covered Module dimensions: 950 –... - Page 8 Introduction Row spacings LEICHTmount 2.1 E/W (18°): 464 mm (18.3 inch) ARRAY MEASUREMENTS E/W 18° irradiation angle 1985 - 2182 mm 2335 - 2532 mm Execution Class : allowable tolerances : Surface: Scale : 1 : 10 Weight: EXC3 DIN ISO 2768 -vL...
- Page 9 LEICHTmount 2.1 E/W is: 2 rows with 2 double modules (8 modules). 8 rows with 12 double modules (96 modules). 12 modules Example boundary conditions for module fields with the LEICHTmount 2.1 E/W. • • S:FLEX GmbH Reinbeker Weg 9 21029 Hamburg Tel. +49-(0)40-68893170 Sasbacher Straße 7 79111 Freiburg Tel.
- Page 10 Part: 821061 Aerocompact +/S10 LEICHTmount Front Part FrONTBrACkET - Part: 821011 • • S:FLEX GmbH Reinbeker Weg 9 21029 Hamburg Tel. +49-(0)40-68893170 Sasbacher Straße 7 79111 Freiburg Tel. +49-(0)761-888 56 08-0 © S:FLEX GmbH 02/2017/ Subject to technical modifications info@sflex.com www.sflex.com...
- Page 11 Once the installation is complete, the entire system can be grounded. One grounding terminal per module field is recommended (max. 40 modules). Positionierung nach den statischen The LEICHTmount 2.1 E/W system must be grounded in accordance with the applicable regulations of the country in Erfordernissen und Einbausituation which the installation is carried out.
- Page 12 Positionierung nach den statischen Erfordernissen und Einbausituation • • S:FLEX GmbH Reinbeker Weg 9 21029 Hamburg Tel. +49-(0)40-68893170 Sasbacher Straße 7 79111 Freiburg Tel. +49-(0)761-888 56 08-0 © S:FLEX GmbH 02/2017/ Subject to technical modifications Ausrichtung der Stehfalzklemmen info@sflex.com www.sflex.com mittels Richtschnur...
-
Page 13: Installation - Leichtmount 2.1 E/W
Building screen mat (PES) Ballast block (not included in delivery) • • S:FLEX GmbH Reinbeker Weg 9 21029 Hamburg Tel. +49-(0)40-68893170 Sasbacher Straße 7 79111 Freiburg Tel. +49-(0)761-888 56 08-0 © S:FLEX GmbH 02/2017/ Subject to technical modifications info@sflex.com www.sflex.com... -
Page 14: Installation - Racking And Modules
Die Auslegung und Planung des Systems LEICHTmount muss mit der S:FLEX-Planungssoftware The design and planning of the LEICHTmount system must be carried out using the S:FLEX planning software Die Montage des LEICHTmount 2.0 S Systems auf Flachdächern erfordert vom Verarbeiter umfassende Fachkennt- (Solar.Pro.Tool) erfolgen. - Page 15 S:FLEX GmbH Reinbeker Weg 9 21029 Hamburg Tel. +49-(0)40-68893170 Sasbacher Straße 7 79111 Freiburg Tel. +49-(0)761-888 56 08-0 info@sfl ex.com www.sfl ex.com © S:FLEX GmbH 02/2016 / Technische Änderungen vorbehalten © S:FLEX GmbH 02/2017/ Subject to technical modifications info@sflex.com www.sflex.com...
- Page 16 Der exakte Abstand wird bei der Modulmontage angepasst. Der exakte Abstand wird bei der Modulmontage angepasst. Diese Montageempfehlung dient der Installation des S:FLEX LEICHTmount 2 Die Montageempfehlung richtet sich an einen vom Betreiber der PV-Anlage eing Place the Front Parts, Top Parts and Bottom Parts at approximately the required horizontal distance sprechender Qualifikation.
- Page 17 At the end of the row, attach an end clamp and screw it tightly into position after aligning the last module. The clamps must be tightened with a torque of at least 15 Nm, up to a maximum of 20 Nm. Diese Montageempfehlung dient der Installation des S:FLEX LEICHT Die Montageempfehlung richtet sich an einen vom Betreiber der PV-An sprechender Qualifikation.
-
Page 18: Installation - Alpine Brackets
Position a Bottom part in the centre of the module using an end clamp and screw it tight. • • S:FLEX GmbH Reinbeker Weg 9 21029 Hamburg Tel. +49-(0)40-68893170 Sasbacher Straße 7 79111 Freiburg Tel. +49-(0)761-888 56 08-0 © S:FLEX GmbH 02/2017/ Subject to technical modifications info@sflex.com www.sflex.com... -
Page 19: Installation - Ballast Tray 880
Ballastwannen 1.5 Installation 2.4 Installation — ballast trays Diese Montageempfehlung dient der Installation des S:FLEX LEICHTmount 2.0 S Systems auf Flachdächern Die Montageempfehlung richtet sich an einen vom Betreiber der PV-Anlage eingewiesenen Personenkreis mit ent sprechender Qualifikation. The ballast trays must be used as soon as the specified ballast weight per bracket is exceeded. -
Page 20: Completing The System With Additional End Clamps
Front Part at the start and end of each row. • • S:FLEX GmbH Reinbeker Weg 9 21029 Hamburg Tel. +49-(0)40-68893170 Sasbacher Straße 7 79111 Freiburg Tel. +49-(0)761-888 56 08-0 © S:FLEX GmbH 02/2017/ Subject to technical modifications info@sflex.com www.sflex.com... -
Page 21: Installation - Ballast
Ballastblock Spezifi kation und das Gewicht zu kontrollieren. geforderte Ballastblock Spezifi kation und das Gewicht zu kontrollieren. • • S:FLEX GmbH Reinbeker Weg 9 21029 Hamburg Tel. +49-(0)40-68893170 Sasbacher Straße 7 79111 Freiburg Tel. +49-(0)761-888 56 08-0 © S:FLEX GmbH 02/2017/ Subject to technical modifications info@sflex.com www.sflex.com... -
Page 22: Terms Of Use
(Solar.Pro.Tool) shall not constitute a defect for which S:FLEX GmbH is responsible. In the case of faulty workmanship by the purchaser or third parties, the rights of the purchaser to assert claims due to a defect in the goods shall expire. -
Page 23: Warranty / Product Liability (Exclusion)
S:FLEX GmbH. The company S:FLEX GmbH shall not be liable for incorrect handling of the installed components. S:FLEX GmbH must be consulted directly regarding use of the system near the sea due to the increased corrosion risk. With proper handling,...
