Summary of Contents for U-Cube POLAR ICE TRAY

Page 1 POLAR ICE TRAY 極地冰盒 USER MANUAL 使用說明書...
Page 2: Table Of Contents
Contents 內容 What Makes Polar Ice 簡介 Unique? Warnings and Precautions 使用注意事項 Diagram 部品名稱 How to Make Polar Ice 製作透明冰 How to Extract Polar Ice 取冰的方法 Conditions Needed for 凍結情況 Solidification Freezer Temperature Setting 冷凍條件設定 Specifications 產品規格...
Page 3: What Makes Polar Ice Unique
What makes Polar Ice 簡介 Unique? Characters 特點 Easy to Use: Just add water and 使用簡單：只需要加 put it in the freezer to enjoy your 水，然後放入冰箱冷凍 very own crystal clear ice. 庫，就可以得到透明冰。 Convenient: Our unique, patented 取冰方便：專利設計的 design allows for easy removal of 製冰盒構造，可以輕易...
Page 4 The Concept behind Polar Ice 製冰原理 Mimicking the natural ice-forming 模擬自然界河川湖泊的凍結 patterns found in lakes and rivers, 模式，由水面開始結冰，而 Polar Ice allows ice on the surface 湖底仍然維持液體狀態。 of the tray to freeze, while the water below remains unfrozen. 極地冰盒利用隔熱材料包覆冰盒底部，只有水面接觸冷 We achieve this by using insulated 凍庫內的冷空氣。在由上而...
Page 5: Warnings And Precautions
Warnings & Precautions 使用注意事項 Please wash with soap and water 第一次使用前，請以中性 before first use. 洗潔精清洗後使用。清洗時請使用柔軟的抹 Please clean with a soft cloth or 布或海綿，避免刮傷製冰 sponge to avoid scratching. 盒的表面。 Please do not fill with hot water. 不要倒入熱水，製冰請使用放涼的開水。 Non-microwavable - keep away 不可以使用於微波爐。請...
Page 6 If the ice is not easily removed, 當冰塊難以取出的時 flush bottom of the plastic layer 候，可以在冰盒外層淋 with water or leave it at room 水，或在室溫下放置 1～ temperature for 1-3 minutes. 3 分鐘待稍微溶化之後慢 Then slide the ice out gently, as 慢地取出。如果勉強用力 brute force may crack the plastic. 取出，可能會造成冰盒破...
Page 7: Diagram
Diagram 部品名稱 Silicone Layer 矽膠層 Perforated Layer 有孔層 Plastic Layer 塑膠層 Heat Isolated Base 隔熱底座...
Page 8: How To Make Polar Ice
How to Make Polar Ice 製作透明冰 Place the 將有孔層放置於 perforated layer on 塑膠層上。 top of the plastic layer. The edges should fit 注意邊緣要緊密 as snugly as 結合，避免漏 possible to avoid 水。必要時稍微 leaking. Pinch the 施力壓合。 rims together to ensure full contact.
Page 9 Put the silicone 將矽膠層放置於 layer on top of the 有孔層上。 perforated layer. The edges should fit 注意邊緣要緊密 as snugly as 結合，避免漏 possible to avoid 水。必要時稍微 leaking. Pinch the 施力壓合。 rims together to ensure full contact.
Page 10 Pour water through 將冷開水由注水 the hole at the top 孔倒入冰盒，直 of the silicone layer, 到水滿出矽膠層 until water flows 的頂端氣孔。 out of the hole. 使用的水質基本 The clarity of the 上不會影響冰塊 ice is does not vary 的透明度，利用 based on water 自來水製冰同樣 quality. Tap water 可以得到透明冰...
Page 11 Put the ice 將冰盒穩固的置 compartments into 入隔熱底座內。 the insulated base. 完整組合後，將 After completing 整組冰盒置入冰 assembly, place the 箱冷凍庫。 components in freezer. 需經過約 12 小時以上的充分冷 It will take at least 凍。 12 hours for the ice to freeze 冷凍期間，儘量 sufficiently. 減少開闔冷凍庫...
Page 12: How To Extract Polar Ice
How to Extract Polar Ice 取冰的方法 When the water has 當冰塊充分凍 frozen, remove the 結後(請參考凍 ice components from 結狀況說明)， the insulated base. 將冰盒由隔熱底座中取出。...
Page 13 扳動矽膠層的 Flip the edge of 邊緣，可以將冰 silicone layer up, and 模直接剝離。 peel it away from the ice sphere. 繼續扳動有孔 Next, pull on the 層的邊緣，可以 edge of the silicone 接著將兩個冰 perforated layer. This 球與底層冰塊 will separate the 分離。 bottom of the ice sphere from the “white ice”...
Page 14 If you leave your tray 如果冰凍超過 in the freezer for over 24 小時，此時冰 24 hours, the “white 塊硬度高。扳動 ice” block from the 有孔層時，底層 plastic layer may stick 的白冰塊有時 to the perforated 候會一起脫 silicone layer. To 出。這時候可以 remove the white ice 使用湯匙將其...
Page 15 If the ice is not easily 如果取出塑膠 removed, flush 層內的冰塊有 bottom of the plastic 困難，請在盒底 layer with water or 淋水，或靜置 leave it at room 1~3 分鐘，待冰 temperature for 1-3 層稍許溶解即 minutes. 可順利脫離。 Avoid banging, 避免在低 hitting or dropping the 溫時，直接擠壓 plastic layer.
Page 16 To store your ball of 如須保存冰 ice, put it in a 球，可以置於夾 ziplock bag and 鏈袋中放入冰 keep it in the 庫。可以避免冰 freezer. This will 塊揮發，同時達 prevent 到冰塊時化的 volatilization. 效果。 The melting speed 晶瑩剔透的冰 of a crystal clear 球不僅美觀，融 ball of ice is slower 化速度也較...
Page 17: Solidification
Conditions of Solidification 凍結情況 BE CAREFUL – 完全凍結：注意冰面低溫，避免凍 Polar Ice freezes at 傷！ extremely low temperatures! 充分凍結 12 小時 It takes ~12 hours for 以上。 Polar Ice to fully freeze. 儘量避免以手直 To prevent frostbite, avoid touching the 接接觸冰面，防...
Page 18 Watch for sharp 未完全凍結：注意銳利邊緣，避免割 edges when the ice 傷！ is partially frozen! 凍結時間少於 8 Occurs when the 小時，或冰箱的 freezer temperature isn’t cold enough or the 冷度不足。 ice has been freezing for less than 8 hours. 冰盒打開後，會...
Page 19: Freezer Temperature Setting
Freezer Temperature 冷凍條件設定 Setting 一般來說冷凍庫設定在 -18°C Please set your freezer to a 是最佳的冷凍溫度，也就是溫 " " temperature range. 中度調節器『』的狀態。 At a “WARMER” temperature 設定在『弱』的狀態，需要充 setting, the ice will take longer to 分凍結的時間會加長。。設定 freeze. 在『強』的狀態，則冰塊底層 At a “COLDER” temperature setting, the ice may form 會有針狀氣泡。...
Page 20 A white cloud or 當冰球底部有 needle-like bubbles may 較多針狀氣 form on the bottom of 泡，可能是因為 the ice ball, when air 加水時有空氣 bubbles are trapped in 被困在底層或 the plastic layer and 小孔中。可以在 block the holes in the 加水後，用手指 perforated layer. After 輕彈矽膠層，震...
Page 21: Specifications
Specification 產品規格 Size: L108 x W108 x H108mm L108xW108 x108mm 尺寸外觀：直徑 6 cm 冰球 Ice: 6 cm diameter ice ball 冰球尺寸：外層 PU Outer: PU Material: 材質：內層 PP 與矽膠 Inner: PP & Silicone M a n u f a c t u r e r : U - C U B E D e s i g n s L L C P r o d u c t i o n : M a d e i n T a i w a n...
