- Page 1 Field Reference Guides GCS900 Scraper Version 13.13 SITECH Rocky Mountain www.sitechrockymtn.com...
- Page 3 SITECH TECHNOLOGY DEALER TRAINING CHECKLIST System: GCS900 Scraper Version: 13.1 Training Checklist Page # □ CB460 Control Box Layout Scraper Training Display Settings □ □ Check Blade Wear Load Design □ □ Verify System Accuracy □ Vertical Offset □ Horizontal Offset □...
-
Page 5: Table Of Contents
SITECH TECHNOLOGY DEALER TRAINING CHECKLIST System: GCS900 Scraper Version: 13.1 Training Checklist Page # □ CB460 Control Box Layout Scraper Training Display Settings □ □ Check Blade Wear Load Design □ □ Verify System Accuracy □ Vertical Offset □ Horizontal Offset □... -
Page 7: Cb460 Control Box Layout
SITECH TECHNOLOGY DEALER Field Reference Guide Table of Content GCS900 Scraper Version: 13.1 Field Reference Guide Page # CB460 Control Box Layout Scraper Training Display Settings Check Blade Wear Load Design Verify System Accuracy Vertical Offset Horizontal Offset Vertical Guidance... -
Page 11: Scraper Training Display Settings
SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Scraper Training Display Settings Version: 13.1 The Control Box must be in Manager’s Mode 1. Press “Menu” 2. Select “GNSS Accuracy” and Press “OK” 3. Press and Hold “F6 ” and Press “F2” Medium Mode 4. - Page 12 21. Press “F1” to select “Design Elev.(3D)”, “Design XSlope (3D)”, “Mainfall (3D)”, “Satellites (3D)” and ”V. GNSS Err (3D)” (select in order) Press “F6” Text View 2 23. Press “F1” and Uncheck each Item checked 24. Press “F1” to select “Northing (3D)”, “Easting (3D)”, “Elevation (3D)”, “Mainfall” and “Offline (3D)”...
-
Page 13: Check Blade Wear
SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Check Blade Wear Version: 13.1 1. Press “Menu” 2. Select “Blade Wear” and Press “OK” 3. Measure from Center of Cutting Edge Bolts to Bottom of Blade 4. Do not use Bolt at Blade Tip 5. -
Page 14: Load Design
SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Load Design Version: 13.1 1. Press “Menu” 2. Select “Select Design” and Press “OK” 3. Use Arrows to highlight Design and Press “OK” 4. Press “ESC” to return to the operating screen Page 7... -
Page 15: Verify System Accuracy
SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Verify System Accuracy Version: 13.1 Verify the system accuracy at the start of each work day using a Permanent Bench Point 1. Move machine to Bench Point with the Blade low to the ground 2. -
Page 16: Vertical Offset
SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Vertical Offset Version: 13.1 1. Press “F4” to enter Horizontal and Vertical Offset 2. Press “F6” until Vertical Offset is displayed at the top left of screen 3. Enter Vertical Offset and Press “F2”... -
Page 17: Horizontal Offset
SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Horizontal Offset Version: 13.1 1. Press “F4” to enter Horizontal and Vertical Offset 2. Press “F6” until Horizontal Offset is displayed at the top left of screen 3. Press “F1” Alignment: 4. Use Arrows to Select [Plan Line] if list is displayed and Press “OK”... - Page 18 6. Press “OK” and enter Offset distance 7. Press “F2” Select Offset to be Left or Right of the line (-3.00 is Left) 8. Press “OK” to return to operating screen 9. Horizontal Offset is highlighted in red 10. Press “F1” to change Blade Left or Right Page 11...
-
Page 19: Vertical Guidance
SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Vertical Guidance Version: 13.1 1. Press “Menu” 2. Press “Guidance Method” and Press “OK” 3. Change Adjust cut to avoid overcut: to “NO” 4. Press “F1” for Change Method 5. Select Method from list and Press “OK”... -
Page 20: Cut And Fill Site Map
SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Cut and Fill Site Map Version: 13.1 1. Press “Menu” and select “Mapping/Recording Settings” Press “OK” 2. Change “Mapping for the main screen views” to “Yes” scroll down list 3. Change “Blade tip mapping” to “Automatics on” and Press “OK”... -
Page 21: Lane Guidance
SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Lane Guidance Version: 13.1 1. Move Blade Tip with Focus over Lane to be Extended 2. Press “F3” for Lane Guidance 3. “F3” turns Lane Guidance Off and ON Page 14... -
Page 22: Sensor Calibration
SITECH TECHNOLOGY DEALER Field Reference Guide GCS900 Dozer Sensor Calibration Version: 13.1 1. Press “Menu” 2. Select “Calibrate Sensors” and Press “OK” 3. Select “Blade slope sensor (turn around) and Press “OK” 4. Following instructions 5. Press “F6” Finish 6. Press “ESC” twice to return to operating screen... -
Page 23: Connect To Wi-Fi
SITECH TECHNOLOGY DEALER Field Reference Guide 16 April 2015 Connect to WiFi GCS900 Version: 13.1 1. Press “Menu” 2. Press “F2” Installation 3. Select “Connectivity Settings” then press “OK” 4. Select “Wi-Fi Network” then press “OK” 5. Press “F1” New 6. -
Page 24: Tcc Settings
SITECH TECHNOLOGY DEALER Field Reference Guide TCC Settings GCS900 Version: 13.1 1. Press “Menu” 2. Press “F2” Installation 3. Select “Connectivity Settings” then press “OK” 4. Select “Connected Community Settings” then press “OK” 5. Enter “Device Password” then press “Next”... -
Page 25: Configure Remote Assistant
SITECH TECHNOLOGY DEALER Field Reference Guide Configure Remote Assistant GCS900 Version: 13.1 1. Press “Menu” 2. Press “F2” Installation 3. Select “Connectivity Settings” then press “OK” 4. Select “Remote Assistant Configuration” then press “OK” 5. Enter “Support Number” 6. Press “F1” Force Upgrade 7. -
Page 26: Wireless Data Sync
SITECH TECHNOLOGY DEALER Field Reference Guide Wireless Data Sync GCS900 Version: 13.1 1. Press “Menu” 2. Press “F2” Installation 3. Select “Connectivity Settings” then press “OK” 4. Select “Wireless Data Sync” then press “OK” 5. Press “F1” Start 6. When synchronization is complete Press “ESC”... -
Page 27: Start Remote Assistant
SITECH TECHNOLOGY DEALER Field Reference Guide Start Remote Assistant GCS900 Version: 13.1 1. Press “Menu” 2. Select “Remote Assistant” then press “OK” 3. Press “F1” Start 4. Once icon appears at the bottom of the screen the machine is connected 5. -
Page 28: Connect To Ibss Base
SITECH TECHNOLOGY DEALER Field Reference Guide Connect to IBSS Base Station GCS900 Version: 13.1 The Control Box must be in Manager’s Mode 1. Press “Menu” 2. Press “F2” Installation 3. Select “Connectivity Settings” then press “OK” 4. Select “GNSS Base Configuration” then press “OK”... - Page 29 Service and Support www.sitechrockymtn.com (866) 903-2335 Service Center Locations: SITECH Rocky Mountain 2420 Uravan Street Aurora Co 80011...
