INSTRUCTION MANUAL

2200W ELECTRIC

SAW BENCH WITH GUARD

MODEL NO: THSBENCH-G -- PRODUCT NO: 1938188001

EN - ORIGINAL INSTRUCTIONS

ASSEMBLY REQUIRED – TWO PERSON

SAVE THESE INSTRUCTIONS

SPARES & SUPPORT: 01793 333212

FOR YOUR SAFETY

Please read & understand this manual, paying attention to the safety instructions, before use.

Incorrect use of the product could put the operator or machine in danger.

Whilst every effort has been made to ensure the accuracy of information contained in this manual, our

policy of continuous improvement determines the right to make modifications without prior warning.

Images used are for illustration purposes only

01-11-2018

Table of Contents

Need help?

Do you have a question about the THSBENCH-G and is the answer not in the manual?

Questions and answers

Summary of Contents for The Handy THSBENCH-G

Page 1 INSTRUCTION MANUAL 2200W ELECTRIC SAW BENCH WITH GUARD MODEL NO: THSBENCH-G -- PRODUCT NO: 1938188001 EN - ORIGINAL INSTRUCTIONS ASSEMBLY REQUIRED – TWO PERSON SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 FOR YOUR SAFETY Please read & understand this manual, paying attention to the safety instructions, before use.
Page 2 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.
Page 3: Table Of Contents
CONTENTS SPECIFICATIONS IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS SET UP & PREPARATION FOR OPERATION ASSEMBLY KNOW YOUR MACHINE OPERATION MAINTENANCE STORAGE WIRING DIAGRAM TROUBLE SHOOTING PARTS DIAGRAM & LIST EC DECLARATION OF CONFORMITY WARRANTY ASSEMBLY IS REQUIRED – TWO PERSON This product requires assembly before use. See the “Assembly” section for instructions. Please check that all parts required for the assembly of this spreader are included.
Page 4: Specifications
SPECIFICATIONS The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Model Number THSBENCH-G Product Number 1938188001 Motor* (230VAC 50Hz) 2200W, S2 15min Short Circuit Rating 1 kA Protection Category IP 54 Blade Size Ø...
Page 5: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product.
Page 6 UNDERSTAND YOUR SAW BENCH Read and understand the owner’s manual and labels affixed to the log saw. Learn its application and limitations as well as the specific potential hazards peculiar to it. STAY ALERT Do not operate the machine while under the influence of drugs, alcohol, or any medication that could affect your ability to use it properly.
Page 7 AVOID INJURY FROM UNEXPECTED ACCIDENT Do not attempt to load or unload logs until the saw bench has stopped. To refrain from removing any off-cut or other part of the workpiece from the cutting area whilst the machine is running except by using a push stick. Keep hands out of the way of all moving parts.
Page 8: Set Up & Preparation For Operation
SET UP & PREPARATION FOR OPERATION The saw bench comes partially assembled. After all the parts have been removed from the carton, you should have the below components. If you believe you are missing any components, please contact us: 1. Motor 2.
Page 9: Assembly
ASSEMBLY This log saw was partially assembled at the factory. To assemble your machine follow the below instructions. SAW BLADE GUARDS Fig. A, illustration 1. Place back plate 1 against outside of the connecting part at the log carriage and align its two holes with the upper two holes of the connecting part.
Page 10 HANDLE Attach the handle to the back of the log carriage. Secure it with two M8×25 bolts and M5x20 (x1) lock nuts (Fig. B). Screw the wing bolt M5×20 into the hole at the upper right corner. M8x25 (x2) ON/OFF SWITCH Fix the switch to the motor plate with M4×58 bolts and nuts (Fig.
Page 11 CONNECTING PIVOTING LOG CARRIAGE AND BASE FRAME Lay the pivoting log carriage on the ground with legs inside the base frame, and put one end of the cross brace outside (Fig. E). Fasten them together with M8×40 bolts, washers and lock nuts on both sides. Fix the other end of the cross brace from the inner side of the base frame with M8×70 bolts, washers and lock nuts on both sides.
Page 12 SAW BLADE Fig. G, illustration 1 Slide the rear saw blade flange onto the motor shaft. Place the saw blade together with the front clamping flange onto the rear flange and secure it with nut M20×1.5. M20x1.5 (x1) ATTENTION The arrow on the saw blade has to point in the direction of the operating side! Fig.
Page 13 FIXING RETURN SPRING AND CHAIN Fig. I, step 1. Take the cotter pin and washer from the guiding pipe with spring. Fig. I, step 2. Push the log carriage to the base frame until the open end of the guiding pipe is inserted into the angle part at the base frame.
Page 14 LIMIT PLATE Mount the limit plate and fasten with two M5×10 screws and washers (Fig. J). M5x10 (x2) TOP GUARD Mount the top guard with four M5×10 bolts and lock nuts (Fig. K). M5x10 (x4)
Page 15: Know Your Machine
LOG CARRIAGE EXTENSION Loosen the wing bolt M5×20 on the back side of the log carriage until the log carriage extension can be inserted into the opening. Slide the log carriage extension into the channel and align it correctly. Then tighten it with the wing bolt.
Page 16: Operation
OPERATION STAKE ON LEVEL GROUND To secure your saw bench, use four bolts or stakes on level ground. Due to varying ground surfaces, these are not included. Choose the right type of bolt or stake for your surface type. SET THE LOG RULER Loosen the wing bolt M5×20 to allow the log ruler to be pulled out freely.
Page 17: Maintenance
MAINTENANCE WARNING Prior to any adjustment, maintenance or service work disconnect the mains power plug! GENERAL MAINTENANCE MEASURES Keep all safety devices, air vents and the motor housing free of dirt and dust as far as possible. Wipe the equipment with a clean cloth or blow it with compressed air at low pressure. We recommend that you clean the device immediately each time you have finished using it.
Page 18: Storage
7. Disassemble the nut M20×1.5 and the front clamping flange. Take down the old saw blade. M20x1.5 (x1) STORAGE Store unused equipment in a dry, locked place out of the reach of children. Before a longer period of storage carry out the following to extend the saw service life and ensure an easy operating. •...
Page 19: Trouble Shooting
TROUBLE SHOOTING PROBLEM PROBABLE CAUSE REMEDY SUGGESTED Saw blade gets loose after Fastening nut tightened Tighten fastening nut right-hand turning off the motor insufficiently thread. 1. Failure mains fuse 1. Check mains fuse 2. Extension cable defect 2. Replace extension cable Motor does not start 3.
Page 20 PARTS DIAGRAM – THSBENCH-G (1938188001)
Page 21 PARTS LIST – THSBENCH-G (1938188001) Item Item Part No Description Part No Description TH247-1 Screw M5x12 TH247-28 Washer 8 TH247-2 Washer 5 TH247-29 Locknut M8 TH247-3 Flat Washer 5 TH247-30 Saw Blade Guard 2 TH247-4 Inner Saw Blade Cover TH247-31...
Page 22: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Electric Circular Saw Bench with Guard Model(s): THSBENCH-G Product Number: 1938184001 Type/Serial No: As per rating label on machine Rated Input: 2200 S2 15min...
Page 23 GJ HANDY & CO LTD USER WARRANTY POLICY Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
Page 24 GJ HANDY & CO LTD USER WARRANTY POLICY Not covered by this warranty a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident. b) The warranty policy does not cover any costs necessary for the standard periodic maintenance services instructed by the operator’s manual, or service parts replacement which would include oil, filters, tyres, belts, brake linings, fuses, blades, seals and other service parts unless it can be proven that the item has...
Page 25 NOTES ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________...
Page 26 NOTES ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________ ________________________________________________________...
Page 28: Tel: 01793 333212
For spares or support of your handy product, please contact us: Tel: 01793 333212 Email: customerservice@handydistribution.co.uk (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
