Emblaze-VCON XPOINT User Manual page 2

Figure 1: Remote Control Layout
1
2
3
4
5
6
7
8
Joystick (#17)
Up
Volume
Down
(#20)
9
10
11
12
13
14
15
16
Status Display the call status
Data Initiate data sharing
Address Book Open address book
Help Open the system help
Control the position (PTZ) of
Far End
the camera at the far end
Configure the camera
Camera Control
settings
Recall a camera PTZ preset
Preset - Recall
position
Set a camera PTZ preset
Preset – Set
position
Back (#18)
Make call End call
(#22) (#23)
Toggle the position of the
PIP
PIP (5 positions)
Display the speed dial
Speed Dial
screen
Call Log Display the current call log
Mute Mic. Mute the microphone
Toggle the local and remote
Display
displays
Settings Open the settings menu
Temporarily disable the
Mute Video
video camera
Mute Speaker Mute speaker
Menu/OK
(#19)
In
Zoom
Out
(#21)
