Assembly Directions for
Danoma Fire Pit & Fire Table
Burner with Glass Beads
Glass Wind Guard
Poly Top
Stainless Steel Heat Barrier
Danoma Fire Table with Poly Top
Package Contents
1 Top
1 Base
1 Stainless Steel Heat Barrier (Poly
Top Only)
1 Propane Tank Carrier
1 Burner
1 Igniter
1 Flex Tube
1 Burner Assembly
1 Glass Wind Guard
2 Pkg Glass Beads
1 Cover
1 Control Panel
¼"x2 1/2" Allen Head Bolt
#DFPP2544, DRFT3644C
Base
Hardware Package
4
¼" x 21/2"" Allen Head Bolts
4
¼" Flange Nuts
4
3/4" Pan Head Screw
1
Allen Wrench
Pre-Drilled Holes
Fasten Firepit Top to Firepit Base by inserting ¼"x2 1/2"
Allen Head Bolts into pre-drilled holes in frame and base
Control Panel
(please note to keep bolt head on outside of base and fas-
ten frame opposite side of door first) and fasten with ¼"
flange nuts.
Fasten the control panel into routed out space in base pan-
el with 3/4" Pan Head Screws.
Burner with Glass Beads
Glass Wind Guard
Poly Top
Danoma Firepit with Poly Top
Frame Without Pre-Drilled Holes
STEP #1
Stainless Steel Heat Barrier
Base
Tools/Items Needed:
Hammer
7/16" Wrench
Allen Wrench (included)
1 AAA Battery (not included)
#2 Square Drive Bit
Cresent Wrench
Place Fire Pit Top on
Fire Pit Base. (please
note place section of top
without pre-drilled holes
in the aluminum frame
above the door of the
base).
STEP#2
Advertisement
Table of Contents
Summary of Contents for Danoma DRFT3644C
- Page 1 Assembly Directions for Danoma Fire Pit & Fire Table #DFPP2544, DRFT3644C Burner with Glass Beads Glass Wind Guard Poly Top Burner with Glass Beads Glass Wind Guard Stainless Steel Heat Barrier Poly Top Stainless Steel Heat Barrier Base Base Danoma Firepit with Poly Top...
- Page 2 (Poly Fire Pit Only) Place Stainless Steel Heat STEP #3 Barrier on top of aluminum frame located in the center of Fire Pit top. (please note keep the recessed edge of the Stainless Steel Heat Barri- er turned upward). Remove protective sticker from Stainless Steel Heat Barrier.
- Page 3 Outdoor Fire Pits Proper Care & Maintenance Poly Material:Poly Fire Pits are made from High Density Polyethylene (HDPE), a recyclable plastic that will never need to be painted or stained. It will not rot or splinter, and it contains an added UV protective agent to resist fading. Poly material is not affected by most corrosive substances, and will not promote bacterial growth.
- Page 4 OUTDOOR FIRE PIT WARRANTY Berlin Gardens, LLC (“Berlin Gardens”) extends the following warranty to the original purchaser of its outdoor fire pit. This warranty applies only to the original owner of the Product and is non-transferable. The warranty is effective starting on the date of purchase. Polyethylene Fire Pits with a Polyethylene Top are warranted to be free of original defects in workmanship and materials for a period of ten (10) years of residential use or two (2) years of commercial use.
