Summary of Contents for Ewattch TOOLBOX-ETH-GPRS
- Page 1 EWATTCH CONNECTED SOLUTIONS FOR ENERGY CONTROL TOOLBOX-ETH-GPRS Toolbox User Guide...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Hazards and Warnings Certifications and Conformities References Presentation Connection Toolbox configuration Technical specifications Contact TOOLBOX ETH-GPRS Technical Documentation wattch... -
Page 3: Hazards And Warnings
Disconnect all power supplies before servicing the equipment. CERTIFICATIONS AND COMPLIANCES • EN 61000-6-2 Immunity for industrial environments • EN 61000-6-3 Emissions for residential environments • EN 55022 Immunity IT equipment Radio • EN 300220 Sécurité • EN 60950 Information processing device www.ewattch.com wattch... -
Page 4: References
REFERENCES Products only : TOOLBOX-ETH Toolbox without accessories communicating via Ethernet only. TOOLBOX-ETH-GPRS Toolbox without accessories communicating via Ethernet and GPRS. Kits : KIT-TOOLBOX-ETH Kits with a TOOLBOX-ETH or a TOOLBOX ETH-GPRS, KIT-TOOLBOX-ETH-GPRS respectively, and all necessary accessories: a 5VDC power supply unit (ref: ALIM-BLOC-5V) and an... -
Page 5: Presentation
The TOOLBOX is a data concentrator, developed by our engineers, which receives the information sent by the wireless sensors on the LoRa® network. The TOOLBOX then transmits the data over the Internet, via Ethernet or the GPRS communication module, to the EwattchCloud server, or a third-party server. www.ewattch.com wattch... -
Page 6: Connection
CONNECTION Ethernet Power connector connector LoRa® antenna GPRS antenna connector connector (optional) TOOLBOX ETH-GPRS Technical Documentation wattch... -
Page 7: Toolbox Configuration
Type in your browser: http://ewattch_toolbox • (on Mac, click http://ewattch_toolbox.local). Alternative method: Connect the toolbox to a computer directly using an Ethernet cable. After configuring your computer’s network settings with a compatible address, type in your browser: 192.168.1.115 Unit information www.ewattch.com wattch... - Page 8 ToolBox on the EwattchCloud or third-party server. API KEY Security key that will be requested when configuring the product on the EwattchCloud or third-party server. Ewattch cloud Indicates whether the ToolBox is connected to the EwattchCloud or third-party server. Time zone Configures the time zone of the product.
- Page 9 IP Address, Gateway, Activate HTTP proxy If this box is checked, the ToolBox will use the proxy configured for its communications. This proxy must be one that does not require authentication. Restart the service Save and apply configuration changes. www.ewattch.com wattch wattch...
- Page 10 EwattchCloud or third-party platform From this page, you have the option not to send the toolbox data to the Ewattch servers, but instead to a server of your choice. Server Domain name of selected server Path Path that the toolbox should use to send data to the server Configure the server Save and apply configuration.
- Page 11 GPRS APN Network Allows configuration of the access point name. Username GPRS network username. Password GPRS network password Code SIM card PIN. www.ewattch.com wattch...
-
Page 12: Technical Specifications
TECHNICAL SPECIFICATIONS POWER SUPPLY WIRED COMMUNICATIONS VOLTAGE ETHERNET 5 VDC RADIO COMMUNICATION LoRa® FREQUENCY OUTPUT POWER 865MHz to 868MHz 25 mW or 7mW (depending on configuration) COMMUNICATION DISTANCE AERIAL CONNECTION from 50m up to 15km in open areas* SMA female NUMBER OF CHANNELS 1 short range, 4 long range GPRS... -
Page 13: Contact
CONTACT wattch 13, Rue Maurice Jeandon 88100 Saint-Dié des Vosges contact@ewattch.fr www.ewattch.fr www.ewattch.com wattch wattch... - Page 14 EWATTCH-SENSORS WE CREATE USEFUL PRODUCTS contact@ewattch.fr www.ewattch.com...
