- Page 1 INSTRUCTIONS & PARTS DIAGRAM Pittsburgh 16 Gauge LKF Pittsburgh 16 Gauge...
- Page 2 Pittsburgh 16 Gauge Instructions and Parts Diagram LKF Pittsburgh 16 Gauge...
- Page 3 Be sure that this Instruction Manual is kept near the machine so the operator can refer to it when • necessary. Keep this equipment properly maintained. • Always turn off power to the machine(s) at the main disconnect before performing any • maintenance or adjustments so accidental start-up or electrocution cannot occur. LKF Pittsburgh 16 Gauge...
- Page 4 The information contained herein is to be use as a general guide only. For further safety information obtain and read the ANSI bulletin entitled: ANSI B11.12-1996 Rollforming and Roll-Bending Machines safety. Requirements for Construction, Care and Use. CONTACT: American National Standards Institute 11 West 42nd Street. New York, New York 10036 LKF Pittsburgh 16 Gauge...
- Page 5 Remember that the information contained in this manual is only a portion of an adequate training program. It must be coupled with specific instructions for your application along with full information of national and local safety regulations that may apply. LKF Pittsburgh 16 Gauge...
- Page 6 (3) setting the “S” mark on the dial opposite the pointer on the cover. Example: If the dial is set for 16 ga. the lock is wide, When set for 24 ga. it becomes narrow, 3 3-1/16 far from rolls. closer from rolls LKF Pittsburgh 16 Gauge...
- Page 7 Standard Viscous #3 (Product of the Standard Oil Company) or equivalent. The slow speed shafts do not require additional lubrication. Grease gears periodically or as needed. If machine is to be used out of doors, an oil or grease film will prevent rusting of surfaces. LKF Pittsburgh 16 Gauge...
- Page 8 Sketch (1). When using the Drive Cleat Rolls the straight edge is placed along the entrance gauge and the measurement is made from the distance between the straight edge and the number one and seven roll stations. SKETCH No.1 LKF Pittsburgh 16 Gauge...
- Page 9 To install auxiliary opening roll holder remove rolls, from the number six roll station and bolts that straddle bottom six roll shaft (See Sketch 4 and 4A). Place opening roll holder onto machine and fasten with the two ½”-13 NC x 2” HHCS provided. LKF Pittsburgh 16 Gauge...
- Page 10 G. Combination 3-in-1 Rolls: (22-28 Gauge) Uses approximately 1-3/4” on “T” Section 1-1/8” on standing seam ½” on right angle flange. Three Step Entrance Gauge Top Step “T” Section Gauge setting………..2-1/16” Middle Step Standing Seam Gauge setting………………………………….1-1/2” Bottom Step Right Angle Flange Gauge setting………………………………….15/16” LKF Pittsburgh 16 Gauge...
- Page 11 6. Replace top cover and back plate 7. Hold material against gauge and feed into machine. LKF Pittsburgh 16 Gauge...
- Page 12 LKF Pittsburgh 16 Gauge...
- Page 13 LKF Pittsburgh 16 Gauge...
- Page 14 LKF Pittsburgh 16 Gauge...
- Page 15 Lockformer Pittsburgh 16 Gauge Parts List Please use New Number when ordering parts. Pieces Description Part No. per Unit 20003 Lower Front Plate 20004 Lower Back Plate 20001 Upper Front Plate 20002 Upper Back Plate 11001 16 Pitts T1 11002...
- Page 16 Idler Gear (Uses 1- #66090 Bearing) 14162 Main Idler Gear (Uses 2- #66100 Bearings) *62633 3/8 x 1 Dowel Pin *51900 Fibre Gear Assembly *52504 Opening Roll Bracket Assembly 14622 Saddle Washer 60450 ½-13 x 1 SHCS LKF Pittsburgh 16 Gauge...
- Page 17 Phone: (630) 964-8000 Use, publication or sale of any images or content without the expressed written Fax: (630) 964 5685 consent of Lockformer ® is strictly prohibited. www.lockformer.com © Copyright 2008. All rights reserved by Lockformer ® LKF Pittsburgh 16 Gauge...
