Rebar Locator DR 30000 PK

Table of Contents

1 Abstract ............................................................................ 4
1.1 Introduction .................................................................. 4
1.2 Fields of application ...................................................... 5
1.3 Technical Specifications ................................................ 5
1.5 Care and Maintenance .................................................. 6
1.6 Liability .......................................................................... 9
2 Introduction to Product .................................................. 10
2.1 Product Appearance ................................................... 10
2.2 Button Board Instructions .......................................... 11
2.3 Accessories Instructions ............................................. 12
3 Product Instructions ....................................................... 12
3.1 Boot Instructions ......................................................... 12
3.2 Operating Instructions ................................................ 12
3.2.1 Start Measuring ....................................................... 13
Models)...................................................................................... 21
DRC s.r.l. - info@drcitalia.it
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DR 30000 PK and is the answer not in the manual?

Questions and answers

Summary of Contents for DRC DR 30000 PK

  • Page 1: Table Of Contents

    Rebar Locator DR 30000 PK Table of Contents 1 Abstract ................4 1.1 Introduction ..............4 1.2 Fields of application ............5 1.3 Technical Specifications ..........5 1.5 Care and Maintenance ..........6 1.6 Liability ................9 2 Introduction to Product ..........10 2.1 Product Appearance ...........
  • Page 2 Rebar Locator DR 30000 PK 3.2.4 JGJ Measurement (Limited to Different Models) ... 21 3.2.5 Data Management (Limited to Different Models) .. 23 3.2.6 System Setting ............25 3.2.7 Power Off .............. 26 Appendix Ⅰ: On-site Notice ..........27 Appendix Ⅱ: Menu Quick Index ........28 Appendix Ⅲ...
  • Page 3 Rebar Locator DR 30000 PK The Operating Manual Instructions: 1. The symbol 【 】 in this manual represents a button on the product panel, such as【 】. 2. The symbol in this manual represents supplementary specifications. 3. In addition to the contents of this manual, there are some other prompts displayed automatically when operating, please follow the prompts.

  • Page 4: Abstract

    Rebar Locator DR 30000 PK 1 Abstract 1.1 Introduction The analyzes that can be performed on structures in order to obtain information on the armatures, the presence of irons or carpentry, is called the magnetometric or pacometric survey. The aim of this survey is mainly to locate the presence of bars and / or reinforcement brackets on structural elements.

  • Page 5: Fields Of Application

    Rebar Locator DR 30000 PK 1.2 Fields of application The fields of application are:  Rebars Identification;  Cover Measure;  Dimensions measurements of rebars in structural elements;  Localization of hidden metal objects. 1.3 Technical Specifications Items Technical Spec.

  • Page 6: Care And Maintenance

    Rebar Locator DR 30000 PK 61-120 ±6 Diameter Measuring Estimation of the diameter of the Modes investigated component rebar JGJ Measurement Possibility to re-measure the single point of each bar Data Storage Over 10.000 values Off Time Automatic Power Supply...
  • Page 7 Rebar Locator DR 30000 PK cause loss of test data or even damage to the product. Do not use other batteries or power supply for charging, otherwise it may cause the damage to the product, battery leakage, fire etc. If you have any problems, please contact us.
  • Page 8 Rebar Locator DR 30000 PK time, please keep charging for 3 hours or so, and do not charge the battery in an environment exceeding 50℃. It is recommended that you should use the manufacturer's standard charger and USB cable, or it may cause damage to the product.

  • Page 9: Liability

    Rebar Locator DR 30000 PK and clean the jack with a soft brush. 6. Fault and Handling Method Instrument cannot boot: please check the battery power whether it is sufficient or directly insert it into the charger, turn on the soft switch. If the above method is invalid, connect the charger to charge the battery for half an hour before switching on.

  • Page 10: Introduction To Product

    Rebar Locator DR 30000 PK 2 Introduction to Product 2.1 Product Appearance and buttons (a) Top View (b) Bottom View Fig. 2.1 General View Tips: The actual instrument may differ from the schematic, please in kind prevail. DRC s.r.l. – info@drcitalia.it...

  • Page 11: Button Board Instructions

    Rebar Locator DR 30000 PK 2.2 Button Board Instructions Each button is on the host panel and the function specifications are shown in the table 2.2. Table 2.2 List of Function Buttons Button Symbol Function Spec. Power On/Off, Confirm, Move Right 【...

  • Page 12: Accessories Instructions

    Rebar Locator DR 30000 PK 2.3 Accessories Instructions 1. USB Cable Micro USB cable is used to connect the instrument and the charger for charging as well as connect the instrument and the computer for data upload as shown in Figure 2.3.

  • Page 13: Start Measuring

    Rebar Locator DR 30000 PK enter the chosen function menu. 3.2.1 Start Measuring The start measuring menu mainly realized these functions such as measurement setting, rebar diameter setting, component name setting, stirrup spacing setting, JGJ scanning setting, instrument calibration setting, as shown in figure 3.2 (a, b, c, d, e, f).
  • Page 14 Rebar Locator DR 30000 PK c. Component Name Setting d. Stirrup Spacing Setting e. JGJ Measurement Setting f. Instrument Calibration Fig. 3.2 Start Measuring Menu Interface DRC s.r.l. – info@drcitalia.it Page 14...
  • Page 15 Rebar Locator DR 30000 PK In the start measuring interface, please operate the following buttons to select the function. 【▲】: Select the function upwards to set and adjust the value of parameters (recyclable used) 【▼】: Select the function downwards to set and adjust the value of parameters (recyclable used) 【...
  • Page 16 Rebar Locator DR 30000 PK Fig. 3.3 Rebar Diameter Size Setting Calibration: When the measuring environment is changed or error measurement result is appeared, you should perform zeroing, as shown in figure 3.4. In calibrating, keep the instrument away from ferromagnetic metal objects, just in the air.
  • Page 17 Rebar Locator DR 30000 PK Fig. 3. 4 The Instrument Calibration The parameters setting of each option as follows: (1) Rear Diameter A range of rebar specifications: 6, 8, 10, 12, 14, 16, 18, 20, 22, 25, 28, 32, 36, 40, 50.

  • Page 18: Rebar Position ＆ Thickness Measuring

    Rebar Locator DR 30000 PK parameter is set to ＞125. (4) JGJ Measurement (limited to different models) No: unused, Yes: used. 3.2.2 Rebar Position ＆ Thickness Measuring Select the Start Measuring (press 【Side Upper Button】if you want to select “second range” H) and move the instrument rightwards slowly and...
  • Page 19 Rebar Locator DR 30000 PK a. Measuring Interface b. Measuring Location Interface c. Measuring Location Interface(Second Range) Fig. 3.4 Rebar Position ＆ Thickness Measurement (a, b,c) As the instrument moves away from the rebar, the square-shaped frame moves away from the centerline again and gradually moves towards the edge of the screen.
  • Page 20 Rebar Locator DR 30000 PK page, and automatically increase or decrease in multiples of 600 each time. In the process of scanning, the system will automatically page if the display is beyond the scope, press the 【▼】 ＆ 【▲】 to view the previous screen data, the before and after data in every screen will change accordingly, except the middle data.

  • Page 21: Rebar Diameter Measurement(Limited To Different Models)

    Rebar Locator DR 30000 PK NOTE: For a quickly enter in the measuring interface Press the 【Side Upper Button】at the main menu. 3.2.3 Rebar Diameter Measurement Enter the measuring interface after detecting the position of rebar, press 【Side Upper Button】, the value of rebar diameter can be displayed as shown in figure 3.5.
  • Page 22 Rebar Locator DR 30000 PK In the JGJ measurement interface, please operate the following buttons to select the functions: 【▲】,【▼】: Switch the up and down cursor position and choose Yes or No (recyclable used). 【 】 、 【 】: Switch the left and right cursor position.

  • Page 23: Data Management (Limited To Different Models)

    Rebar Locator DR 30000 PK c. JGJ Measuring Interface b. JGJ Measuring Data Fig. 3.6 JGJ Measurement Setting 3.2.5 Data Management Data management is mainly to view data, upload data, delete data, etc., as shown in figure 3.7. 1. Data View Fig.
  • Page 24 Rebar Locator DR 30000 PK The data view interface mainly displays the following information: Component name  Set Rebar diameter(dXX)  Average cover thickness;  Minimum cover thickness  Maximum cover thickness  The total points of measuring thickness ...

  • Page 25: System Setting

    Rebar Locator DR 30000 PK 3. Data Delete Press【side lower button】to remove current data in the data view interface. Press 【 】 to delete the all data. Press other buttons to cancel the deletion, as shown in figure 3.8. Fig. 3.8 Data Delete Tips：The instrument contains is about two hundred thousand...

  • Page 26: Power Off

    Rebar Locator DR 30000 PK To configure the automatic shutdown time: press【▼】,【▲】 to select the system setting in the main menu, press 【 】to enter the system setting interface. In the system setting interface, please operate the following buttons to select the functions: 【▲】,【▼】: Switch the different off time (recyclable used).

  • Page 27: Appendix Ⅰ: On-Site Notice

    Rebar Locator DR 30000 PK (4). Low Power Shutdown The instrument in the state of power-on will display battery capacity. If the power is too low, the no gray icon representing enough battery capacity in the top right corner of menu will become the red frame.

  • Page 28: Appendix Ⅱ: Menu Quick Index

    Rebar Locator DR 30000 PK (2) During the measurement, keep the instrument parallel to the rebar investigated to avoid errors in the measurement of the concrete cover. (3) In the scanning process, try to keep the product moving slowly and evenly.

  • Page 29: Appendix Ⅳ: Relevant Standards

    Rebar Locator DR 30000 PK Set the component name and Name number Set stirrup spacing according to the Space actual component Remeasure the single point of each rebar Calibration Reset and perform zeroing Data View View measuring data Data Review...
