Line Tech LS700 User Manual

User Guide
1

Components

(1) Headset
(2) Mute
(3) Headset Port
(4) Configuration Switch
LS700
[ Top View ]
[ Bottom View ]
(7) Handset Port
(8) Telephone Port
(5) USB port(Micro 5pins)
(6) Lifter Port
2

Features

(1) Headset Button : When this button is lighted Green, the coversation is through
the headset. When it isn't lighted Red, the conversation is routed to your telephone handset.
(2) Mute Button : When this button is Lighted Red the Mute feature is active and your voice will not be
heard at the other end of the call. The Mute function is active when Red light.
(3) Headset Port : Plug the curly cord of your headset in here.
(4) Configuration Switch : Allows the Switch Box to operate with different telephone types.
(5) USB port : A USB cable with micro 5pins for power
(6) Lifter port : Connects the Lifter for which used the Lifter's data cord.
(7) Handset Port : Connects to your telephone handset via your telephone handset curly cord.
(8) Telephone Port : Connects to your telephone via the short cord provided.
(9) USB cable with micro 5pins : It connects Computer's USB port or Power supplier.
(10) Short Cord : Switch Box to Telephone
LINE TECH
(9) USB cable
(10) Short Cord
