Summary of Contents for MMcall HY-2613A
- Page 1 User Manual HY-2613A MMcall Wireless Calling &Service System Please read this manual before using the product! Keep it for future reference! If you have any questions, please contact us.
-
Page 2: Table Of Contents
Catalogue I Introduction…………………………………………………………3 II Basic function………………………………………………………3 …………………………………………………3 System appearance IV System parameter…………………………………………………4 Setup………………………………………………………………5 VI Notes ………………………………………………………………6 VII Appendix：Letter display………………………………………7 VII Setup signal enhancer……………………………………………7... -
Page 3: I Introduction
Introduction: This system is constituted by host (screen), requester (button) and remote controller. Basic function is when there is call from requester; the host will display the requester number and with a clear sound prompt. With so many advantages like high efficiency, good quality, long distance, etc. this system is common applied in hotels, restaurants, tea &... -
Page 4: System Appearance
III System appearance 1）Host: there are 4 requester numbers and 1 waiting number. 2)：Remote controller: There are 8 buttons on it. “1, 2, 3, 4” are cancel buttons. “ESC”,“ENT”“-/ALT”， “+/TAB”are multi-function buttons. There are 8 buttons on the remote controller. “1, 2, 3, 4” are cancel buttons. “ESC”“ENT”“-”，“+”are multi-function buttons. -
Page 5: System Parameter
IV System parameter Requester capability Number restriction 01-99, or A0-J9 Coverage of the requester 100m (open air) Requester frequency 433.500MHz Requester transmit power <30mW Requester power supply (2610N3 /2610E3) 4.5V, 3 No.7 batteries/ 12V, 1 No. batteries Host receiving sensitivity -105DB Host power reply AC 220V/DC 12V... - Page 6 means set up successfully, at the same time, the low digit-6 flashing, you can go on setting other requester numbers. e. After setting up all the requesters, cut off the power of the host and power on again or wait for20 seconds, the screen will back work mode, then you can use this system now. 2）Delete requester number: a.
-
Page 7: Notes
5）Set automatic delete number time a. On working mode, Press the “TAB/+” button on the host for 4 seconds without release, then the host displays 15 SESC, means to set automatic delete number state. b. After modify to suitable time, press “ENT” button means record successfully. c. -
Page 8: Setup Signal Enhancer
I： J： VII Setup signal enhancer HY2611D is used for enlarge system coverage. Add one signal enhancer; the coverage will enlarge to twice of the former distance. Remember the feature code of Requester The enhancer can remember 80 feature codes of Requester, when it receives information from Requesters, it will judge whether the information is in its control sphere, if so, it enhance the signal, if not, it won’t work. - Page 9 Delete all the feature code of Requester Delete all the feature code of Requester means back to the original state of the enhancer The delete process is as following: After entering the third step of the above, press the button of RX for 4 seconds, if RX light put out, it means delete successfully.
