關 隆 股 份 有 限 公 司
RFC remote functional spec. sheet
REV
D01
2009/07/31 Alvin
D02
2009/08/20 Alvin
D03
2009/8/21
D04
2009/8/24
1.
Specification:
Power Supply: AAA 1.5V *3
1.1:
1.2: RF module: 315 MHz
1.3: Remote Keys :
1.3.1: ON▲
1.3.2: OFF▼
1.3.3: TEMP(Left)
1.3.4: FUNC.(Righ)
1.4: Range: 12.7 meter radius
1.5: Certificate Require:
1.5.1: CSA
1.5.2: FCC
1.5.3: IC
Grand Mate Co.,Ltd
Revision Control
DATE
REV. BY:
Alvin
Alvin
Detail of Revision
New Rule
Change:(1.3.3) ;(1.3.4) ;(2.1.2.2)(2.1.2.3)
(2.2.2);(2.2.3);(2.3.1) ;(2.4.1)
Add: (2.8);(2.9);(2.10);(2.11)(3.0)
Change: (2.8.1);(2.9.1)
Change: (2.1.1);(2.8.1);(2.9.1);(3.4)
(ON▲)
(TEMP)
(OFF▼)
1
(FUNC.)
Advertisement
Related Manuals for Revo RFC
Summary of Contents for Revo RFC
- Page 1 關 隆 股 份 有 限 公 司 Grand Mate Co.,Ltd RFC remote functional spec. sheet Revision Control DATE REV. BY: Detail of Revision 2009/07/31 Alvin New Rule 2009/08/20 Alvin Change:(1.3.3) ;(1.3.4) ;(2.1.2.2)(2.1.2.3) (2.2.2);(2.2.3);(2.3.1) ;(2.4.1) Add: (2.8);(2.9);(2.10);(2.11)(3.0) 2009/8/21 Alvin Change: (2.8.1);(2.9.1)
- Page 2 關 隆 股 份 有 限 公 司 Grand Mate Co.,Ltd Function 2.1: Flame Adjustment: Adjust flame Hi and Low ICON: 2.1.1 Steps: 4 steps(include OFF) ON(Hi) Middle OFF(Shot off) 2.1.2 Flow Chat: 2.1.2.1: Press ON▲ → system will proceed ignition process 2.1.2.2: After ignited can use FUNC.
- Page 3 關 隆 股 份 有 限 公 司 Grand Mate Co.,Ltd 2.3: ℃ / °F Switch: the Temp. indicator icon can be change ICON: 2.3.1: Flow Chat: 2.3.1.1: Battery input→ the screen appear °F ICON 2.3.1.2: When ℃ / °F appear, use ON▲, or OFF▼ To chose ℃...
- Page 4 關 隆 股 份 有 限 公 司 Grand Mate Co.,Ltd 2.6 Back Light 2.6.1: When press any key, the back light will turn on 2.6.2: The back light will turn off without touch any key for 5 sec. 2.7 FUNC. Key: Functional Option 2.7.1: Flow Chat: 2.7.1.1: Press FUNC.
- Page 5 關 隆 股 份 有 限 公 司 Grand Mate Co.,Ltd 2.9 AUX function: ON/OFFF Add On Module ICON: 2.9.1 Switch:2 2.9.2 Flow Chat: 2.9.2.1: Press FUNC. Key ,Chose AUX ICON, then use ON▲, or OFF▼ to turn on or off the AUX function 2.10 ROOM TEMP Function: Indoor Temp.
-
Page 6: Lcd Display
關 隆 股 份 有 限 公 司 Grand Mate Co.,Ltd 3. LCD DISPLAY 3.1: Turn on: (ON): Appear use ICON and ROOM TEMP DISPLAY: 3.2: Turn off: (OFF): only appear ROOM TEMP Shut off all the icon after 3 minutes DISPLAY:... - Page 7 關 隆 股 份 有 限 公 司 Grand Mate Co.,Ltd 3.3: Children Lockout: Into Children Lockout mode, the display will only appear Children lockout ICON (will remain on until disarm) DISPLAY: 3.4: Standby Mode: 3.4.1 Shut Off: When system shut off after 3 min. into standby mode, the LCD will not appear any icon, press any key to wake up the system (Children lockout will be exceptional) 3.4.2 Turn On: When system turn on after 3 min.
