Summary of Contents for AMD AMD-2500
- Page 1 AMD-2500 General Examination Camera AMD Telemedicine 67 Middle Street, Lowell, MA 01852 800-742-1674/978-937-9021 www.amdtelemedicine.com AMD Telemedicine Version 1.0...
- Page 2 AMD General Examination Camera Contents Introducing the AMD General Examination Camera Using the Camera Setting Up the Camera Displaying an Object Adjusting the Image Sorting Out the Details Connectors and Controls Cable Connections Zoom Lens AMD-2500 Product Specifications Power Supply Safety Ratings...
-
Page 3: Introducing The Amd General Examination Camera
Introducing the AMD General Examination Camera The AMD General Examination Camera can be used during video-conferencing to examine objects in fine detail. This hand-held camera is compact and lightweight, with all the controls located on the camera; no auxiliary remote control is required. The camera is multi-purpose, and can be used for many applications, including dermatology and dentistry. -
Page 5: Using The Camera
External Video Input on the video-conference system. Plug the power adapter cord into an outlet. The AMD-2500 must only be used with the power supply that ships with the product to ensure labelled safety standards are met. This power... - Page 6 Move the Power switch to ON, move the Light switch to ON and verify that the green power indicator light is ON. The AMD-2500 should be inspected for proper operation daily. The AMD-2500 should be cleaned/ disinfected after each patient contact (at a minimum of daily).
-
Page 7: Displaying An Object
AMD General Examination Camera Notes: Displaying an Object Every time the Examination Camera is turned ON, adjust the White Balance. a) Turn ON the , using the Ring-Light switch on the back of the camera. b) Focus the camera on a white sheet of paper. - Page 8 AMD General Examination Camera The AMD-2500 should be inspected for Notes: proper operation daily. The AMD-2500 should be cleaned/ disinfected after each patient contact (at a minimum of daily). AMD Telemedicine Version 1.0...
-
Page 9: Adjusting The Image
AMD General Examination Camera Notes: Adjusting the Image If the image is affected by glare... If the image is affected by glare caused by light reflection off of the object, or if there is not much definition in the image:... - Page 10 AMD General Examination Camera Notes: If the image is too large... Zoom out by pressing the button on the top of the Examination Camera. AMD Telemedicine Version 1.0...
- Page 11 AMD General Examination Camera If the image is shaky... Notes: It may be difficult to maintain a still image on the screen due to the movement of the camera. To capture a freeze-frame of the image on the screen: Press the button on the top of the Examination Camera.
- Page 12 AMD General Examination Camera If the image is too pale... Notes: Turn OFF the using the switch Ring-Light on the back of the Examination Camera. If the image is still too pale, make sure that the Examination Camera is using Automatic Iris Control.
- Page 13 AMD General Examination Camera If the image is fuzzy... Notes: If you are using the Zoom Lens, position the object at the end of the flexible rod. Make sure that the Examination Camera is using Automatic Focus Control. The Focus switch should be set to...
- Page 15 50X Lens (provided) glare…” section. Allows for higher magnification viewing of Protective Lens image. Can be used with AMD-2505 Disposable For more details, refer to Tip Cover to prevent contamination page 19. Camera Camera−front view when the...
- Page 16 AMD General Examination Camera AMD Telemedicine Version 1.0...
- Page 17 AMD General Examination Camera Connectors and Controls AMD-XXXX A Power Indicator is illuminated (the green light is ON) when the camera is ON. B Power Switch turns the camera ON and OFF. The camera should be turned OFF when it is not being used.
-
Page 18: Cable Connections
CABLE FERRITE OPTIONAL POWER S-VIDEO CABLE ADAPTER RCA CABLE The AMD Examination Camera is attached with a to a DC/ VBS cable junction box There are two connections from the junction box; the plugs into the RCA cable External Video of the video-conference system, and the plugs into an outlet. -
Page 19: Zoom Lens
AMD General Examination Camera Zoom Lens The AMD General Examination Camera has two interchangeable lenses: The Protective Lens provides protection for the camera lens and the ring-light. The 50x Zoom Lens provides 50x magnification for a closer look at objects. This lens has a flexible rod that indicates the focal length of the lens. - Page 20 AMD General Examination Camera AMD Telemedicine Version 1.0...
-
Page 21: Amd-2500 Product Specifications
AMD General Examination Camera AMD-2500 Product Specifications There are no user serviceable or repairable parts inside the unit. The unit must be returned to AMD for repair. Magnification Zoom (14” screen) 1-50x (auto focus), 200x (optional) Light Polarization Pixels ½ inch; 410,000 pixels Resolution (horizontal) >430 lines... -
Page 22: Power Supply Safety Ratings
AMD General Examination Camera Power Supply Safety Ratings Type BF equipment Read all instructions provided with product Class II equipment Indoor use only AMD Telemedicine Version 1.0... -
Page 23: Amd-2500 System Configuration Diagram
AMD General Examination Camera AMD-2500 System Configuration Diagram AMD-2500 DC/VBS Cable Ferrite Junction Box TV/Monitor Ferrite AC Adapter Cable RCA Cable AMD Telemedicine Version 1.0...
