- Page 1 Manual UB20 / UB40 / UB50 / 2 EL. 6-40 Rev. 1.10 WiMo Antennen und Elektronik GmbH Am Gäxwald 14, D-76863 Herxheim Tel. (07276) 96680 FAX 9668-11 http://www.wimo.com e-mail: info@wimo.com...
- Page 2 Introduction Some UltraBeam models work in 30 and 40 meters band with folded elements, this allows you to work on 30 and 40 meters with full-size elements in the same mechanical dimensions of UltraBeam 6-20 models. This technique has been applied on 2 and 3 element Yagi models. In order to achieve that two curve models are applied to the ends of the elements, joined together by glass fiber tubes, this creates a corridor in which the copper tape can scroll to reach the required length for resonating up to 40 meters.
- Page 3 PVC GUIDE TUBES DRIVER 30-40 All UltraBeam models working in 30 and 40 meters with folded elements include the installation of internal guide pvc tubes to the left and right elements attached to the motor unit. MOTOR telescopic element The guide tube of folded elements is essential to allow the tape to slide within the curve and the side elements without bending.
- Page 4 INSTALLATION OF ELEMENTS ON MOTOR UNIT Before inserting the elements in the motor unit it is necessary to fix the PVC guide tube. During this operation it is necessary that the element remains aligned to the engine, if your set-up assembly does not allow this, the help of a second person is absolutely needed to support the element during the insertion of the guide tube.
- Page 5 CURVES ASSEMBLY AND SIDE TUBES “ T ” side tube side tube 1 x 800 mm. 3 x 1400 curve coupling as above as above UB-50 2 elements 6-40 Only after inserting all the elements to the motor units you can install the curves and the lateral elements.
- Page 6 2 ELEMENTS YAGI 6-40 To apply the thermo shrinking a heat gun is needed (1500-2000W) The heating time varies depending on the outside temperature, and in any case the correct temperature is reached when the inner glue comes out, creating a ring all around the edges. Insert the side tube and the ends of the elements in the curves up to the maximum insertion (fig, 1).
- Page 7 Combine the 1400 mm pipes placing the 10 cm small tubes exactly at half junction (fig.4-5). Slide the sleeves on joints and heat up to the correct temperature (Figure 6) Drill a small 2-3 mm hole on the same axis in the center in both junctions (fig.7) NOTE: It’s important to check that the holes are facing down before heating conduits that hold whole side element to the curves Fig.4...
- Page 8 UB20-MX / UB40-MX The models UB20 and UB40 differ from UB50 MX in size of the elements and boom, and how they work in a configuration 2 elements moxon on the lower frequency. With regard to the assembly instructions of the curves and side elements, they are absolutely identical to those of UB50 described in this manual.
- Page 9 TELESCOPIC ELEMENTS LENGTH TELESCOPIC MODEL ELEMENTS 2 EL. 6-40 5,4 m. UB20-MX 3,5 m. UB40MX 7,4 m. UB-50 5,4 m. SIDE PIPES / GUIDE TUBES LATERAL TUBES PVC TUBES MODEL LENGTH LENGTH 2 EL. 6-40 1 x 0,8 m. 2 x 1,5 = 3 m.
- Page 10 ANTENNAS DIAGRAM 2 ELEMENTI 6-40 Director 1,62 m. 1 x 162 cm Sez. 60 x 60 159 cm 124 cm The position of the Mast / Boom plate in models with 3 elements is always at the center boom, in cases where it is necessary you can move it towards the director.
- Page 11 269 cm 231 cm 289 cm 242 cm Note: UB20 - UB50 - UB40 are models with double driver, download the manual “Switch” WiMo Antennen und Elektronik GmbH Am Gäxwald 14, D-76863 Herxheim Tel. (07276) 96680 FAX 9668-11 http://www.wimo.com e-mail: info@wimo.com...
