Summary of Contents for Hermann Schmidt TRANSP
- Page 1 Instructions for Operating TRANSP Transporter...
-
Page 2: Table Of Contents
® Hermann Schmidt - Model: TRANSP TABLE OF CONTENTS 1. MODEL: TRANSP , TRANSPORTER ..................... 3 1.1 W ............................4 ARRANTY 2. ASSEMBLY INSTRUCTIONS ......................... 5 2.1 A ............................5 SSEMBLY 2.2 D ............................8 ISASSEMBLY 3. OPERATING INSTRUCTIONS ......................... 9 3.1 O... -
Page 3: Model: Transp, Transporter
® Hermann Schmidt - Model: TRANSP MODEL: TRANSP, Transporter NOTE: It is important that you read and fully understand this manual before using your Transporter. If you have any questions contact your distributor or the manufacturer. GENERAL DATA Transporter ... -
Page 4: Warranty
® Hermann Schmidt - Model: TRANSP OPERATIONAL SAFETY The ergonomic design of the Transporter is by itself an active factor of operational safety. Other factors of security and technical features are as follows: The movement of the load platform will stop should an object be placed in-between the lift frame and the load platform or if other jamming occurs. -
Page 5: Assembly Instructions
® Hermann Schmidt - Model: TRANSP Assembly Instructions 2.1 Assembly Assembly instructions for a partly assembled Transporter (Intermediate section with legs and brake rod assembled) Place the Transporter base on the floor. Items include: 1) Leg - Right Hand 1) Leg – Left Hand... - Page 6 ® Hermann Schmidt - Model: TRANSP Assembly instructions for a completely disassembled Transporter Place the Transporter base components on the floor. Items include: 2) Leg - Right Hand 2) Leg – Left Hand 2) Intermediate Section-Lower (with lift motor) 2) Intermediate Section-Upper (with mast slide) 1) Brake Rod Note: Rear casters should be delivered with the wheels in the braked position.
- Page 7 ® Hermann Schmidt - Model: TRANSP Ease off the two nuts on the Mast Slide mounting bracket located at the rear of the Upper Intermediate Section above the Brake Rod but do not remove them. Pick up the lift mast and carefully insert the mast onto the mast slide on the Upper Intermediate Section and slide it down over the mounting slide.
-
Page 8: Disassembly
® Hermann Schmidt - Model: TRANSP Follow the instructions from 2.1 Assembly for a partly assembled Transporter. 2.2 Disassembly To disassemble the Transporter, refer to item 2.1 above and reverse the order. Disposal after useful life When the Transporter has provided many years of use and is ready to be disposed of, it should be recycled. -
Page 9: Operating Instructions
® Hermann Schmidt - Model: TRANSP 3. Operating instructions 3.1 Operating In order to prevent and avoid work injuries it is important that the Transporter be operated in a proper manner. 3.1.1 Charging NOTE: DO NOT OPERATE TRANSPORTER WHEN CHARGING BATTERIES Gel-Cell batteries cannot withstand total discharging and need to be recharged after use. -
Page 10: Handlebar
® Hermann Schmidt - Model: TRANSP 3.1.2 Handlebar The height of the handlebar can easily be adjusted by loosening the quick disconnect handles and sliding the handlebar to the desired position. After adjustment, tighten the quick disconnect handles. To obtain the best working conditions it is important to adjust the handle to a comfortable level. -
Page 11: Troubleshooting
The Transporter has been designed to operate safely and effectively provided that maintenance procedures are followed according to the instruction manual. A guide for trouble-shooting is provided as listed below should any problems arise. If the problem remains after referring to the troubleshooting guide below - contact Hermann Schmidt Co. Symptom Action... -
Page 12: Maintenance
® Hermann Schmidt - Model: TRANSP 3.3 Maintenance Regular maintenance is important to protect the continued use of the Transporter. Daily maintenance If the Transporter is fitted with a scale - make sure that power to the scale is off when not in use. -
Page 13: Enclosures
® Hermann Schmidt - Model: TRANSP Enclosures 4.1 Electrical Schematics 17102 Qty Description Part No. Qty Description Part No. Charger (24VDC/110VAC) 2403SRL Aux. Card 20001-10 Plug 17327 Motor Controller 20001-01 Battery Indicator 17102 Fuse 30A Battery 12V R7104 2 Button Controller... -
Page 14: Lift Mast
® Hermann Schmidt - Model: TRANSP 4.2 Lift Mast Description Part No. Qty Description Part No. Wedge 3x3 L=18 17531 Spacer L=15 17568 Connector-Slide 17567 Spacer L=5 17569 Sleeve 17529 Washer 17580 Bearing 7201 BE 17520 Spring 17581 Bearing Holder... -
Page 15: Lower And Upper Intermediate Sections
® Hermann Schmidt - Model: TRANSP 4.3 Lower and Upper Intermediate Sections No. Qty Description Part No. No. Qty Description Part No. Lower Intermediate 20030-01 Upper Intermediate 20030-03 Motor 404.311 17344 Mast Bracket 20030-04 Motor Bracket 16014 Locking Plate 19134... -
Page 16: Legs -Low Profile (20300 And 20500)
® Hermann Schmidt - Model: TRANSP 4.4 Legs-Low Profile Description Part No. Legs 20020 End cover 13004 20011-01 Front Wheel 56mm 17557 Rear Wheel 100mm Washer Screw K6s m8x12 10.9 Screw Mc6s m10x20 8.8 Washer 10.5... -
Page 17: Handlebar
® Hermann Schmidt - Model: TRANSP 4.5 Handlebar Description Part No. Handle 17280-03 Remote Bracket 17201A 19228 Locking Knob 19166 Washer 8.4 hb 200 End Cover 19169-03... -
Page 18: Declaration Of Conformity
® Hermann Schmidt - Model: TRANSP Declaration of Conformity Referring to Directive for machines 89/392/EEC with addendum - appendix 2A Hermann Schmidt Co, 26 Sea Pave Road, South Windsor, CT 06074 Supplier: Address Model: TRANSP Transporter Description: Regulations:AFS 1993:10 (89/392/EEG) AND (91/368/EEG) -
Page 19: Test Protocol
® Hermann Schmidt - Model: TRANSP TEST PROTOCOL Proof Loaded – the overload protection operates. The slide stops correctly when it goes to the top end position with and without load. The break function in the slide works at the lower end position, and if the load platform is hold and is moving downward.
