Iron Air Charge 2510-SXT Installation
& Start-Up Guide
Thank you for purchasing a Clean Water System! With proper
installation and a little routine maintenance your system will be
providing iron free water for many years.
Please review this start-up guide entirely before beginning to install
your system and follow the steps outlined for best results.
MEDIA CONTAINS DUST. USE PAPER MASK AND VENTILATE TO
AVOID BREATHING DUST.
1.0 Cubic Foot 2510 SXT Air Charger:
2806-A Soquel Ave Santa Cruz CA 95062
For assistance call: 1-831-462-8500
Email us:
office@cleanwaterstore.com
More information online:
www.cleanwaterstore.com
Advertisement
Table of Contents
Summary of Contents for AIO 2510-SXT
- Page 1 Iron Air Charge 2510-SXT Installation & Start-Up Guide Thank you for purchasing a Clean Water System! With proper installation and a little routine maintenance your system will be providing iron free water for many years. Please review this start-up guide entirely before beginning to install your system and follow the steps outlined for best results.
- Page 2 Packing List by Model Each system comes with the following: Fleck 2510-SXT Backwash Control Valve with Pipe connector kit (either 1”or ¾”)* Fleck 2510-SXT Bypass valve Enpress filter tank with distributor tube installed Media funnel * We include two extra red clips with the pipe connector kit.
- Page 3 “air pocket” in the top of the tank while the system is in service. As the water passes thru the air pocket, iron and Iron are oxidized. Additionally, dissolved oxygen is added to the water. The Air Charger AIO filter media bed then removes the iron and Iron from the water.
- Page 4 Iron Air Charge 2510-SXT Installation & Startup Guide Pre-Installation 1. If you are going to be turning off the water to the house and you have an electric water heater, shut off the power to the water heater before beginning installation in case water heater is accidentially drained.
- Page 5 Iron Air Charge 2510-SXT Installation & Startup Guide Fig 2 - AIO 2510 SXT Control Valve, Back View Insure the brine line check valve with screen is installed on the brine valve (See Fig. 2) This is the AIR DRAW point of entry.
- Page 6 Media Loading Guide Place the media tank on a level surface in an area with adequate ventilation. Proper precautions should be taken to cover your eyes, mouth and nose before pouring the media into the tank. After removing the control valve, center the riser tube in the tank and place the PVC cap on the riser to prevent media from entering the tube.
- Page 7 Iron Air Charge 2510-SXT Installation & Startup Guide Bypass Assembly The system must be backwashed once upon startup. First, put the system into service mode. Normally the system ships in the bypass position. Once the system is properly plumbed in, make sure to turn both of the bypass valve knobs 90 degrees into service mode.
