INSTALLATION AND USE OF THE
17-0104-EN MINI HF GPRS MODULE
This mini HF GPRS module (17-0104-EN) can be used to manage car park access via two
dry contacts operated by remote control devices or "Mobile Keys". A free-access time
range can be set from the website
Car park access:
Two car park doors can be operated by remote controls from the Intratone range. You will
be able to manage up to 10,000 remote controls per Mini HF GPRS module.
Ex-factory, this equipment requires no configuration in order to open car park doors. Its "ex-
factory test" mode enables opening with any Intratone remote control, making it easier to
carry out checks during the installation phase.
After the first update, authorisation for opening will be restricted solely to remote controls
configured on the website.
Operating warranty:
-
The GPRS Module is guaranteed to work at temperatures of between -20°C and
+70°C and in relative humidity that does not exceed 70%.
The detachable casing must be fitted to protect the module against water damage.
-
The top and bottom of this module are to be positioned as indicated in these
-
instructions.
End of life product recycling:
The GPRS Module and its accessories must not be disposed of with unsorted waste,
but must be collected for recycling as Electrical and Electronic Waste.
EN-V233 – 5017 – AB
GENERAL POINTS
www.intratone.com
Installation and Use of the Intratone Mini HF GPRS Module
under the "management site" tab.
Page 1 / 6
