Product Code: RLATJ20T
OWNER'S MANUAL
PRODUCT CODE: RLATJ20T
20,000kg AIR ACTUATED GARAGE JACK
Lifting
Adjustment
Maximum
Minimum
Nett Weight
Package Size
Capacity
Height
Height
Height
20,000kg
80mm
465mm
210mm
40kg
660x360x280mm
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
Advertisement
Summary of Contents for RED LABEL RLATJ20T
- Page 1 Product Code: RLATJ20T OWNER’S MANUAL PRODUCT CODE: RLATJ20T 20,000kg AIR ACTUATED GARAGE JACK Lifting Adjustment Maximum Minimum Nett Weight Package Size Capacity Height Height Height 20,000kg 80mm 465mm 210mm 40kg 660x360x280mm Made in China to TQB Brands Pty Ltd specifications...
-
Page 2: Table Of Contents
Product Code: RLATJ20T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. -
Page 3: Safety Instructions
Product Code: RLATJ20T SAFETY INSTRUCTIONS WARNING FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL INJURY • Support load by appropriate means after • Only lift areas of the vehicle designated by lifting the vehicle manufacturer. • Do not exceed the jacks rated capacity •... -
Page 4: Assembly, Operation, Preventitive Maintenance
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES The Red Label air-actuated 20,000kg Garage Jack has a powerful air motor to lift heavy loads. The compact design easily fits between dual tandem axles. Ideal for lifting axles, farm vehicles, heavy-duty machinery, industrial equipment and more. - Page 5 Product Code: RLATJ20T Refer to picture when performing this step. Take off the screw located on handle piece 1; attach handle pieces 1 and 2 making sure to align the holes on both sections. Reinsert the screw and tighten. Check that handle is in perfect alignment with internal lowering valve mechanism.
- Page 6 Product Code: RLATJ20T 3. BEFORE USE Prior to each use conduct a visual inspection checking for abnormal conditions, such as cracked welds, leaks, and damaged, loose, or missing parts. • Consult the vehicle owner’s manual to determine the location of lift points.
- Page 7 Product Code: RLATJ20T When the saddle reaches minimum lift height, use a flat blade screwdriver to push the oil filler plug slightly to the side to purge trapped air from system. Close the release valve by turning the handle knob clockwise until firm resistance if felt.
- Page 8 Product Code: RLATJ20T 4. OPERATION 4.1. Raising the Jack Note: The jack is equipped with a handle position lock. To adjust the handle, release lock device by pulling the lever up, lever is spring loaded and will lock into desired position.
- Page 9 Product Code: RLATJ20T Before raising the vehicle double check and verify the saddle is centred and also has full contact with the lifting point. Squeeze air trigger to lift until saddle contacts load. (To stop air operation, simply release the grip on the lift control valve.) Continue to pump...
- Page 10 Product Code: RLATJ20T 5. INSPECTION • Prior to each use conduct a visual inspection checking for abnormal conditions, such as cracked welds, leaks, and damaged, loose, or missing parts. • The Jack should be maintained in accordance with the maintenance instructions (Section 7).
- Page 11 Product Code: RLATJ20T Rust Prevention: • Check rams and pump plungers on the power unit assemblies daily for any signs of rust or corrosion. • Without load lift the equipment as high as it goes and look under and behind the lifting points.
- Page 12 Product Code: RLATJ20T To Replace Oil: Position the jack on level ground and lower saddle. Open release valve by turning handle counter clockwise. Remove oil filler plug and the handle. Turn the jack on its side so that old oil will drain from the oil fill hole.
- Page 13 Product Code: RLATJ20T Fill the oil case until oil level is just beneath the lower rim of the oil fill hole. Replace oil plug. Lubrication: Periodically check the pump piston and ram for signs or rust or corrosion. Clean as needed and wipe with an oil cloth. NEVER USE SANDPAPER OR ABRASIVE MATERIAL ON THESE SURFACES.
-
Page 14: Troubleshooting
Product Code: RLATJ20T TROUBLESHOOTING JACK JACK JACK POOR JACK WILL CAUSE & SOLUTIONS WILL WILL WILL JACK NOT LIFT TO LIFTING FULL LIFT HOLD LOWER EXTENSION LOAD LOAD Release valve is not completely closed (turn handle clockwise) Air Supply inadequate Weight capacity exceeded Air is in the hydraulics. - Page 15 Product Code: RLATJ20T Made in China to TQB Brands Pty Ltd specifications Page 15 Visit us at www.tqbbrands.com.au...
-
Page 16: Parts List
Product Code: RLATJ20T PARTS LIST Part # Description Part # Description Snap Ring 2-23 Sealing Ring Wheel 2-24 Nylon Gasket Bolt 2-25 Copper Bush Spring Washer 2-26 Gland Nut Frame Right 2-27 Spring Bolt 2-28 Bolt Washer 2-29 Front Cover... - Page 17 Product Code: RLATJ20T Part # Description Part # Description 2-12 Valve Seat Lock Lever 2-13 Spring 2-14 O-ring Bolt 2-15 Bolt 4-9-1 Control Rod B 2-16 Block 4-9-2 Control Rod A 2-17 Still Ball 4-10-1 Convey Rod B 2-18 Release Valve Rod...
-
Page 18: Warranty
Product Code: RLATJ20T WARRANTY Red Label products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
