Summary of Contents for Base aire AirWerx 90X
- Page 1 AirWerx 90X Installation & Operations Manual Patented Tel: 888-641-8862 Web: www.baseaire.com E-mail: sales@baseaire.com Specification subject to change without notice.
-
Page 3: Table Of Contents
Table of Contents ........Warranty Registration ........... Safety Notes ........... Identification ..........Electrical Supply ........Principle of Operation ............Installation ..........Key Functions ..........Indicator Lights ..........Remote Control ........Operating Instructions ............Diagram ........... Maintenance ........Dehumidifier Storage ......... Ducted Applications ............ -
Page 4: Warranty Registration
Warranty Registration Congratulations on purchasing a new AirWerx 90X Dehumidifier. Your new dehumidifier comes with an extensive warranty plan. To register, simply fill in and return the warranty c provided in y dehumidifier box. Be sure to note your dehumidifier serial number as you will need it for registration. -
Page 5: Identification
Identification For future reference, write down the model, serial number, and date of purchase for your dehumidifier. This is extremely helpful if you need to seek assistance in the future. The data label on the side of your unit has the key characteristics of your specific unit. Model number: AirWerx Serial Number: ______________ Date of Purchase: _____________... -
Page 6: Key Functions
To switch back to normal humidistat operation, simply move the setpoint above 36%. 4. Central Control · This mode is not applicable on the AirWerx 90X. -
Page 7: Indicator Lights
5. Manual Drain Button · For extended storage or movement of the machine, press the "Drain" button to remove water from the integral pump’s reservoir. 6. Pump Trouble Warning · When the pump reservoir water level is too high, the high water sensor will activate to prevent overflow. -
Page 8: Remote Control
4. Compressor Light ·When the compressor light glows red, it indicates the compressor has been initiated but is currently warming up. ·Once the compressor light switches to green, it indicates the compressor is in working status. Remote Control Instructions AirWerx Dehumidifiers can be controlled using an optional remote accessory. The AirWerx Remote Control connects to your Airwerx Series Dehumidifier via a 25' CAT 5 cable. -
Page 9: Operating Instructions
NOTE: Do not disconnect the power cord to force the unit to stop. Always use the power button. 4. Water Drainage The AirWerx 90X has both automatic and manual draining. During normal operation, the AirWerx 90X will automatically drain as required. If you would like to move or store the machine, you may press the drain button to drain the water from the pump reservoir. -
Page 10: Maintenance
WARNING: Always unplug the unit before doing any maintenance. Condensate Pump Your AirWerx 90X is equipped with an integral condensate pump designed to pump water from your dehumidifier out to the desired drain. This pump requires routine maintenance that is nor covered by your 1-year parts warranty. -
Page 11: Dehumidifier Storage
4. Pour solution into the drain tray at the base of the coils. If any cleaning solutions gets on coils, flush with water. 5. Allow solution to soak for 15 minutes. 6. Reconnect the dehumidifier to power. 7. Fill the reservoir with water and flush/cycle the pump at least two times. 8. -
Page 12: Spare Parts
Flex Duct Installation Flex Duct Removal Rotate the flex duct counter-clockwise. Rotate flex duct clockwise or remove wire tie. AirWerx 90X Spare Parts All AirWerx Models-Parts AirWerx 90X-Parts Part# Description Part#... -
Page 13: Troubleshooting
Troubleshooting Symptom Cause Solution Verify that there is power to the outlet and Power Supply that the plug is properly installed in outlet. The unit id outside the operating Machine Won’t Run Room Temperature Over temperature range. Modify the room 105℉... -
Page 14: Warranty Information
Limited Warranty All warranty benefits apply to the original owner only. Warranty cannot be transferred or assigned. 1 YEAR ( FROM DATE OF PURCHASE): BaseAire warrants the dehumidifier will operate free of defects in workmanship and materials. At its discretion, BaseAire will repair or replace any malfunctioning components, free of charge (excluding transportation costs) 3 YEARS (FROM DATE OF PURCHASE): BaseAire warrants the refrigeration circuit (compressor, condenser and evaporator) will operate free of defects in material or workmanship. - Page 15 Limited Warranty Exclusions EXCLUSIONS: DAMAGE DUE TO THE FOLLOWING IS NOT COVERED UNDER WARRANTY 1. ACTS OF NATURE- INCLUDING BUT NOT LIMITED TO: ● FLOODING ● FIRE ● WATER DAMAGE ● HURRICANE STORM DAMAGE 2. IMPROPER USAGE-INCLUDING BUT NOT LIMITED TO: ●...
- Page 16 Warranty/Registrate by scanning...
