Summary of Contents for SIIG CE-H23P11-S1
- Page 1 Dear Valued Customer ( JUST WANTED YOU TO KNOW ) WE REALLY APPRECIATE YOUR PURCHASE ~thank you~...
- Page 2 Features • Supports video resolution outputs up to 4K2K@60 4:4:4 8bit, HDR 10bits, 12bits, 16bits • Built-in 3 video patterns • Both HDMI input and output support up to HDMI 2.0 Video bandwidth 18Gbps • Fundamental HDMI feature analysis up to 4K2K@60 4:4:4 8bit HDMI 2.0 input •...
-
Page 3: Package Contents
Notes • Not supporting 4K2K60 DVI mode • 4K60 (YUV 4:2:0) 10bits is common resolution • Pattern will be different under different resolution • Before using, please plugging the power adapter to switch off the shipping mode • Device will automatically enter battery saving mode after 1 minute idle. - Page 4 Layout 1. Button (ENTER) 2. Button (DOWN) 3. Button (UP) 4. LCD Display 5. OUTPUT: HDMI output 6. Micro-USB: Firmware update / Recharge 7. INPUT: HDMI input 8. Power Switch: Power ON/OFF Switch...
-
Page 5: Source Mode
Source Mode When device is treated as a source, it can gener- ate different test patterns to the display under test. 1. Make sure the connection between the device HDMI output port and the display. 2. Use buttons to select MODE category and enter SOURCE mode. - Page 6 Sink Mode When device is in sink mode, it can read the HDMI source information and in addition, the input HDMI can be passed through to HDMI capable display if needed 1. Connect the device between HDMI source and HDMI display. 2.
- Page 7 Sink Mode In this mode, device offers a link quality estima- tor following the Character Error Detection mechanism from HDMI 2.0 specification. The estimator can provide a basic link quality evalu- ation regarding the cable or any other HDMI link connected to device. Please notice that the evaluation result can provide an insight into the link quality under testing, but not always reflects the real robustness of HDMI 2.0 full bandwidth...
- Page 8 between the device and the cable. 2. Use buttons to select MODE category and enter CABLE mode. 3. Keep pressing ENTER button for about 5 seconds to start the link test. The device will evaluate the HDMI signal quality based on HDMI 2.0 specification and provide a result, PASS or NG.
- Page 9 HDMI 2.0 connection. Support For more info or tech support http://www.siig.com/support Aug, 2018 Copyright © 2018 by SIIG, Inc. All rights reserved.
- Page 10 HDMI 2.0 4K HDR Installation Gear User Manual 04-1146A P/N: CE-H23P11-S1...
