Pond Boss FP1250UV Manual

Pressurized filter up to 1250 gallons
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
REMINDER
CALL 1-888-755-6750
BEFORE RETURNING TO STORE.
PACKAGE CONTENTS
Part
A
Tank with UV clarifier
B
C
D
E
Bio media balls
F
Coarse filter
G
H
I
J
Locking ring
K
Small adapter
L
Small gasket
WARNINGS AND CAUTIONS
WARNING
•
DO NOT SUBMERGE THE LIGHT ASSEMBLY.
•
WARNING – Improper connection of the appliance-grounding conductor can result in a risk of electric
shock. Check with a qualified electrician or service representative if you are in doubt whether the
appliance is properly grounded. Do not modify the plug provided with the appliance; if it will not fit the
outlet, have a proper outlet installed by a qualified technician.
•
If the appliance falls into water, DO NOT reach for it! First, unplug it and then retrieve it. If electrical
components of the appliance get wet, unplug the appliance immediately.
•
Do not operate any appliance if it has a damaged cord or plug, or if it is malfunctioning or if it is
damaged in any manner.
•
Always unplug the appliance from the outlet before putting on or taking off parts, before cleaning or
when not in use.
•
Connect only to a circuit that is protected by a ground-fault circuit-interrupter (GFCI).
•
Risk of Electric Shock - Do not use the UV filter if the quartz tubing around the lamp is broken.
Immediately unplug and seek an authorized repair service or discard the unit.
PLEASE CALL 1-888-755-6750 BEFORE RETURNING TO THE STORE.
WWW.THEPONDBOSS.NET
Pressurized Filter
Up to 1250 gallons
Description
O-ring
Cover
Lid
Fine filter
Adapter
Gasket
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-888-755-6750, 8 a.m.-6 p.m., EST, Monday-Friday, or
email us at customercare@thepondboss.net. Or visit our
website www.thepondboss.net.
Quantity
1
1
D
1
1
12
C
1
1
B
2
2
2
1
1
ITEM #FP1250UV
A
H
I
J
K
E
F
G
H
I
J
L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FP1250UV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pond Boss FP1250UV

Summary of Contents for Pond Boss FP1250UV

  • Page 1 Pressurized Filter Up to 1250 gallons ITEM #FP1250UV Questions, problems, missing parts? Before returning REMINDER to your retailer, call our customer service department at CALL 1-888-755-6750 1-888-755-6750, 8 a.m.-6 p.m., EST, Monday-Friday, or BEFORE RETURNING TO STORE. email us at customercare@thepondboss.net. Or visit our website www.thepondboss.net.

  • Page 2: Important Notes

    • GROUNDING INSTRUCTIONS – This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. This appliance is equipped with a cord having an appliance-grounding conductor and a grounding plug.
  • Page 3 ASSEMBLY INSTRUCTIONS 1. If using 3/4 in. ID tubing, proceed to step 2. If using 1 in. ID tubing, cut the adapter as shown using a hacksaw. Fig. 1 Cut ring Fig. 1 2. Assemble the locking ring, adapter and gasket. Fig.
  • Page 4 4. Place the fine filter pad inside the tank. Then place the coarse filter pad over the fine filter pad. Fig. 4 NOTE: The coarse filter pad is black. The fine filter pad is blue. Fig. 4 5. Connect the small adapter to the adapter using the locking ring. Be sure to place the gasket between adapter and tank, place the small gasket between the small adapter and adapter.
  • Page 5 8. Place the cover (with the o-ring attached) over the top of the tank. Fig. 8 Fig. 8 9. Screw the lid onto the top of the tank. Make sure that it is secure, or the filter will leak. Fig. 9 Fig.
  • Page 6 12. Connect a length of tube from the outlet of a pump to the inlet of the filter (upper hole). Connect a length of tubing from the outlet of the filter (lower hole) to a water feature. Fig. 12 NOTE: Pump and tubing is NOT INCLUDED. The adapter is compatible with 1 in.
  • Page 7 3. Carefully remove the old bulb by firmly pulling on the base. Carefully install the new bulb. Fig. 15 Lamp holder NEW Bulb OLD Bulb Fig. 15 4. Reinstall the lamp holder and locking ring. Fig. 16 NOTE: This clarifier has a safety feature that only allows the UV Locking light to turn on if the lamp holder is fully seated into the lamp ring...

  • Page 8: Important Note

    CARE AND MAINTENANCE – Pressure Filter • Occasional cleaning of the filter pads will be necessary to ensure the proper functioning of the system. The top filter pad is a coarse pad (black) and will catch larger particles. The bottom filter pad (blue) is a fine pad designed to trap smaller debris.

  • Page 9: Replacement Parts List

    REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-888-755-6750, 8 a.m.-6 p.m., EST, Monday-Friday. Part Description O-ring Cover Adapter Gasket Locking ring Small adapter Small gasket Tank Lamp housing Lamp holder gasket Bulb holder Glass tube holder O-ring 1 Glass tube gasket Glass tube...

  • Page 10: Limited Warranty

    This warranty period begins on the date of purchase by the original purchaser. Unless otherwise specified all pond boss® electrical products are warranted to the user against defective material and workmanship, under normal working conditions for 1 year from the date of purchase.
