Summary of Contents for Huvitech B12HD-HD
- Page 1 B12HD-HD 3.5 inch Wide Full Touch BLACKBOX...
-
Page 2: Table Of Contents
Contents 1. Safety Precautions 16. How to display Front / Rear screen 2. Before Use 17. To save video file on your PC 3. Product Feature 18. How to separate video 4. Package 19. SD card format & Set breaking voltage 5. -
Page 3: Safety Precautions
1. Safety Precautions Caution on Operation and Storage Do not operate the product during driving. It may cause Do not exert excessive force to the product (especially to LCD accident. buttons and to bracket) as it may cause breakdown. The product must be installed at a point which would not Operate the product for 3-5 minutes to check for correct obstruct the driver’s view. - Page 4 Caution on SD Card Because an SD card is consumables, if it is used for a long After turning on the power, make sure that it is in normal time, you may lose the data or may not record due to an operation.
-
Page 5: Before Use
Please read carefully before use. current state of the product, and may contain typographical errors or omissions. B12HD-HD is an auxiliary product to alert users for safe driving and prevent accidents, by recording Contents of this User Manual may be modified, video during driving. -
Page 6: Product Feature
3. Product Feature High Quality Lens and High Image Quality High Quality Voice Record and Voice Resolution support Guidance ㆍ Front 2mega pixel image sensor ㆍ Operating instructions service by voice guidance ㆍ Wide angle mega lens ㆍ Voice recording On/Off function and speaker output On/Off ㆍ... -
Page 7: Package
Package Standard Package Power Cable for Hardwire Cable Rear Camera Cable Clip rear camera B12HD-HD Body Micro SD Card & Adaptor Bracket 별매품 Cigar Lighter External GPS ㆍ The packaged product picture of the user manual may differ from the actual product. -
Page 8: Product Parts
5. Product Parts Power Button SD Card Slot DC-IN Rear Camera Front Camera GPS LED STATE LED POWER LED Security LED REC Button by manual... -
Page 9: Installation
6. Installation 1. Front Camera Installation 1. Insert Micro SD card to SD card slot of 2. Remove the protective tape from the 3. Connect the cigar jack cable to DC-IN the device. bracket. of the device. (Check the defection of SD card.) 4. - Page 10 2. Rear Camera Installation 1. Shutdown a car battery and power 2. Install a rear camera 3. Adjust a rear camera angle P l ease power off a car and Dashcam R emove the protective tape from the rear A djust the camera angle and fix it. before installation.
- Page 11 3. Fuse Cable Installation 1. How to install a Fuse Cable Fuse cable has 3 lines. (When use constant power discharge protection function) Battery Line ( Yellow ) : Connect to Emergency light ACC Line ( Red ) : Connect to Fuse Power Ground Line (Black) : GND...
-
Page 12: External Gps Installation
7. External GPS Installation Connect the external GPS to GPS Fix the external GPS into appropriate connection on the device. place, and tidy up the cable. Caution on GPS Installation ㆍ This feature may not be available in some countries. ㆍ... -
Page 13: How To Record
8. How to record 1. Record : Winner is automatically boot at power on, and a constant(normal) recording starts as an initial recording mode. 2. Recording Mode : it is classified into driving recording mode and parking (motion) recording mode. 3. -
Page 14: Rec Time
3-5. 녹화 시간 9. REC Time ▶ Default Setting 16GB 32GB 64GB 128GB Video Camera Normal Motion Event Normal Motion Event Normal Motion Event Normal Motion Event Quality (50%) (20%) (30%) (50%) (20%) (30%) (50%) (20%) (30%) (50%) (20%) (30%) 1402 Super High Front 1683... -
Page 15: Led Operation Guide
10. LED Operation Guide Item Security LED Booting Blue ON FW update Blue ON Continuous / Event REC Standby (N) ON 1 sec / OFF 1 sec In detect a Shock (E) ON 0.5 sec / OFF 0.5 sec Parking REC (P) ON 0.25 sec / OFF 0.25 sec Parking REC Standby 5 LED flashing interval 0.5 sec to right and left... -
Page 16: Voice Guide
11. Voice Guide Situation Voice Guide Remove SD card / SD card Error “ Please check your SD card. ” Constant (Normal) Recording Start (In booting) “ Constant Recording will start. ” * Event Recording Start (In booting) “ Event Recording will start. ” Parking Recording start “... -
Page 17: Lcd Configuration
12. LCD Configuration Menu Function Menu Function Night Vision Set More Bright under nighttime parking mode Live Image Live Front Video Quality Set Front Video Quality Setting Menu Menu Rear Video Quality Set Rear Video Quality Voice REC ON/OFF Mute REC Mode Continuous / Shock Voice Guide... -
Page 18: Pc Viewer Program Installation
13. PC Viewer Program Installation 1. System Requirements Windows XP(32bit), Windows Vista(32bit), Windows7(32/64bit), Windows8(32/64bit), Windows10(32/64bit) Display monitor resolution: 1024 X 768 DirectX Support (WPF) -
Page 19: How To Use Pc Viewer
14. How to use PC Viewer 2 3 4 5 6 7 13 14 15 16 19 20... - Page 20 Item Function Item Function 1CH / 2CH View Rewind 5 sec Viewer Configuration Playback or Pause System Configuration Stop Print Forward 5 sec Screen Capture File Skip Zoom Control Volume Split Image Total File Time / Playback Time Brightness / Contrast Play List / Map Button GPS Signal Condition File Location Search...
-
Page 21: Playback
15. Playback 1. Vehicle Drive Recorder Item Display Description Playback Icon Display REC List Normal / Event / Motion Tab Each REC file list display tab REC File list List REC File list that is selected tab Playback REC Window REC video playback window LIVE Button Back to list... - Page 22 2. Video Player 1) Remove the SD Card from the device 3) Playback Open a SD Card slot cover and press Open a removal disc, you can see each folders. softly, then a SD Card can be removed And click files to playback which is stored in easily.
- Page 23 3. PC Viewer Program 1) Connect TV Out cable 4) Playback ※Click N : Constant(normal) REC file list E : Event REC file list 2) PC Viewer Program P : Parking REC file list Click the icon to operate the viewer program.
-
Page 24: How To Display Front / Rear Screen
16. How to display Front / Rear screen When you touch in the upper-right-hand corner of the screen (1/4 of whole screen), LCD Screen will change automatically Front/Rear, only Front, only Rear. Only LCD Screen looks different, 2CH images will be recorded when rear camera is connected. Rear Front Front/Rear LCD Screen... -
Page 25: To Save Video File On Your Pc
17. To save video file on your PC 1) Enter to removal disc after insert SD card to your PC. 2) Go to the folder where recorded video files are stored. 3) Create the new folder in same location. 4) Drag the particular file to the new file to copy. (If you drag a folder, the whole folder will be copied.) -
Page 26: How To Separate Video
18. How to separate video 1. Press “Front & Rear Extract” button on the original PC viewer program. 2. Select a video file to separate and click “OK” button. Stored separated file in “C:\Program Files\BlackBoxViewer\BlackBoxViewer\Video” C:\Program Files (x86)\MDA\AtomGold\Video C:\Program Files (x86)\MDA\AtomGold\Video... -
Page 27: Sd Card Format & Set Breaking Voltage
19. SD card format & Set breaking voltage 1. Format on the device Format the Micro SD card on the device. (Menu > Others > SD Card Format) ※ Please back up data before formatiing the memory card. Once you format memory card, all data will be deleted and cannot be restored. -
Page 28: Specification
20. Specification Item Specification Item Specification Allwinner V3 (ARM Cortex A7 core) G-Sensor 3D Shock Sensor Flash Memory 1Gb Serial NAND Video Format 256 MB DDR ADAS Built-in high sensitive Recording Channel Voice Recording microphone Front : Omnivision 9732 Camera Voice Guidance Built-in speaker Rear : Clairpixel HDX11... -
Page 29: Faq
21. FAQ 1. Power is not turned on. ※ Check once again if the power cable is properly connected. If the problem is not solved, please contact manufacture. 2. The map is not shown when a video is played on a PC original viewer program. ※... - Page 30 3. If the warranty period has passed, we will repair by paid charge. 4. Please take this “Warrantee” when you request repair. 5. Please keep this “Warrantee” because we will not be able to re-issue this warrantee note. Model Name B12HD-HD Product Vehicle Drive Recorder / Rear Camera Serial No...
- Page 31 www.huvitech.com...
