USASPEC BSM 200 Product Manual

Blind spot monitoring & rear cross traffic alert system

Advertisement

Quick Links

BSM 200
Blind Spot Monitoring &
Rear Cross traffic Alert
System
Product Manual
www.usaspec.com
167 Mason Way, A-2
City of Industry, CA 91746

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BSM 200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for USASPEC BSM 200

  • Page 1 BSM 200 Blind Spot Monitoring & Rear Cross traffic Alert System Product Manual www.usaspec.com 167 Mason Way, A-2 City of Industry, CA 91746...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Product Overview ................1 Product Warranty Notice ..............1 Operation Precaution & Notes ............2 Package Content ................3 Functions ................... 3 Blind Spot Monitoring (BSM) Detection Zones ......3 Rear Cross Traffic Alert (RCTA) Detection Zone ......4 Installation ..................
  • Page 4: Product Overview

    USA SPEC reserves the right to only offer technical support or warranty services for products purchased through authorized USA SPEC dealers. Please refer to our website www.usaspec.com for a list of authorized dealers.
  • Page 5: Operation Precaution & Notes

    OPERATION PRECAUTION & NOTES Warning • The Blind Spot Monitoring (BSM) and Rear Cross Traffic Alert (RCTA) system is to be used as an auxiliary tool only and is not a substitute for careful driving. It is the driver’s responsibility for the safety of lane changing, backing up, and other maneuvers.
  • Page 6: Package Content

    PACKAGE CONTENT 1 x BSM200 Control Module 2 x BSM200- Sensors 1 x Buzzer (Speaker) 2 x LED Indicators (L & R) 1 x 7-pin Main Harness 1 x 6-pin Harness 1 x 5-pin OBD Cable 2 x Bracket 4 x Short Bracket Arms 2 x Tall Bracket Arms 1 x Angle Ruler 1 x Bag of Mounting Screw/Washer Sets...
  • Page 7: Rear Cross Traffic Alert (Rcta) Detection Zone

    Rear Cross Traffic Alert (RCTA) Detection Zone Detection zone • When the vehicle is put in reverse, the detection zone will increase to 98ft (30m). The detection zone starts from the radar sensors located inside the rear bumper of the vehicle. •...
  • Page 8: Installation

    INSTALLATION Mounting the Radar Sensors Follow the below illustrations and steps carefully. The sensors must be mounted correctly for the BSM-200 system to function properly. 1. Assemble the sensors to the provided adjustable mounting brackets. 2. Use all the provided hardware (screw sets) to ensure that the sensor/bracket assembly is secure and will not loosen over time due to vibration.
  • Page 9 Sensor & brackets Vehicle body 1’ -1.5’ (30-45cm) Vehicle side view Rear bumper Figure 1 (A) Correct sensor positions Sensor Sensor cable cable Car body Sensor Sensor (B) Incorrect positions Car body   Sensor Sensor (C) Incorrect positions  ...
  • Page 10 Correct angle Incorrect angle Vehicle body line Vehicle body line Figure 3...
  • Page 11: Connecting The Cables

    4. Connect the BSM200 OBD-II harness into the vehicle’s OBD-II port located underneath the dashboard 5. Connect all three BSM200 harnesses to the BSM 200 Control Module’s corresponding ports. See Fig. 7. 6. Connect power: connect the RED wire from the main harness to the vehicle’s ignition or ACC +12v source.
  • Page 12: Testing The System

    TESTING THE SYSTEM Before putting the bumper back on, run the below system test steps first. 1. Keep your eyes on the LED indicators on the A-pillars and start the vehicle 2. If the indicator lights up for 3-5 seconds then turns off, it means the system is ready to go.
  • Page 13: Installation Illustrations

    INSTALLATION ILLUSTRATIONS BSM200 BSM200 SENSOR SENSOR (driver side) (passenger side) Green/white wire  right turn signal +12v Green wire  left turn signal +12v Black wire  ground Red wire  ignition or ACC +12v 7-pin plug Figure 4. Main harness wire connection Control Module Speaker...
  • Page 14 6-pin harness port (sensors, reverse/ turn signals, (speaker & LED indicators) & power/ground) Figure 7. Control module ports For assistance with product features and installation please call tech support at 626.336.3836. Mon-Fri 9am-5pm PST. Or email us with your questions at info@usaspec.com...
  • Page 15: Limited Warranty

    LIMITED WARRANTY Thank you for choosing a USA SPEC product. USA SPEC, Inc., is committed to providing high quality defect-free products. All USA SPEC products are tested before leaving the factory and warranted against defects in materials and work- manship for a period of one year to the original owner. The one-year warranty period begins at the date of purchase from an authorized dealer.
