Telaire AAS-AQS-UNO Quick Start Manual

Quick Start Guide

Air Quality Evaluation Board
AAS-AQS-UNO(-RH(-CO2))

What is in the package:

AAS-AQS-UNO Evaluation Kit Includes:

1 Arduino compatible board with preloaded software
1 AAS-AQS-UNO sensor evaluation board (shield)
1 USB data line
1 OLED screen
Arduino Board, Display, and
1 SM-PWM-01C Dust Sensor
Sensor Shield
USB Data Line
Dust Sensor

AAS-AQS-UNO-RH-CO2 Kit Includes:

T6713-6H
1 AAS-AQS-UNO
1 T9602-3-D-1 Humidity & Temp Sensor
1 T6713-6H CO2 Sensor Module
T9602-3-D-1
The Sensor Shield (Connection board) is despatched attached to the Arduino compatible board. The Arduino
compatible provides power to the sensors and processes the sensor data and displays the values. The display will by
default show the dust sensor value, and will display the optional sensors if they are fitted. The Arduino compatible is
®
freely user programmable to send values to a connected PC, accept other sensors using the Arduino IDE program.
The dust sensor value is calculated as a 2 minute rolling average and updated every 5 seconds.
The Evaluation kit can be powered from any standard USB source.
