USAPRO SECURITY AS62UG Installer's Instructions

Hide thumbs Also See for AS62UG:
Table of Contents

Advertisement

Quick Links

Download this manual
AS62UG
INSTALLERS
INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS62UG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for USAPRO SECURITY AS62UG

Summary of Contents for USAPRO SECURITY AS62UG

  • Page 1 AS62UG INSTALLERS INSTRUCTIONS...
  • Page 2 Dealer Mode Programming: 1. Turn the ignition key On, Off, On, Off, and back On. (Key On 3 times) 3 seconds later the horn will honk 3 times. 2. Press and hold the Override switch for 5 seconds. The horn will honk 5 times. The LED will illuminate.

  • Page 3: Entering System Programming

    Adding/Replacing Optional 2-way LCD Transmitters When adding a 2-Way LCD transmitter to the system, follow these steps: 1. Turn the ignition key On, Off, On, Off, On, Off, and back On. (Key On 4 times) 3 seconds Later the siren/horn will chirp 4 times. 2.

  • Page 4: Default Reset

    Default Reset : Following this procedure will set all System Programming Parameters to factory default settings. 1. Enter System Programming. 2. Press Transmitter Button 3. (In Factory Upgrade Mode turn ignition switch Off then back On 3 times) · The siren will chirp 6 times indicating that the reset signal was received. ·...

  • Page 5: Programmable System Options

    Programmable System Options: The following is a description of the programming options. Some program branches control more than one option, and may require accessing a particular branch number twice in order to program all desired features. 1. Arm Mode: Selects one of two modes: Manual Arming (with remote only) or Passive Arming (arms 30 seconds after key is turned off and all doors closed.
  • Page 6 14. Auxiliary 1 Mode: Selects from momentary, 10 second timed, or latched operation for Auxiliary 1. Momentary operation provides an output for as long as the transmitter button is pressed. Timed operation provides an output that turns on for 10 seconds each time the transmitter button is pressed.

  • Page 7: Tamper Alert

    Tamper Alert If the system was triggered while away, the LED will flash to indicate which zone triggered the system after disarming and turning on the ignition. The LED indication will repeat 8 times. LED Flashes: 1 flash Internal Impactl sensor 2 flashes Optional Plug-In sensor 3 flashes...
  • Page 8 Pin 4 LIGHT GREEN WIRE: Sensor 3 Input (-) for extra pin switches, sensors or separate door triggers. Pin 5 GREEN/WHITE WIRE: Dome Light Activation Output (-) 500mA. Connect to LOW Current door switch or Dash light dimmer/dome light switch or an optional relay for a HIGH Current dome light circuit.

  • Page 9: Shock Sensor

    Shock Sensor The AS62UG is equipped with an On Board Shock Sensor that is adjustable through an adjustment knob that is located on the side of the Main Control Unit. Turn knob counter-clock wise for Minimum Sensitivity. Turn knob clock wise for Maximum Sensitivity.
  • Page 10 AS62UG...
