35000 RENNES 6. Image retention (also called burn in, ghosting or France sticking) is not cover under Innes warranty, we advise that you follow the recommendations listed in this document. Technical support: Product failure occurring as the result of factors that do Email: support@innes.fr...
In case the power cord is damaged, please order a new one to sales@innes.fr. o In case SMT210 is powered by PoE supply, the supply device need to be « Limited Power Source (LPS) » (refer to EN60950-1: 2006).
1.3 Block diagram RFID Side leds Speaker Connector GPIO4 or infrared Power supply connector USB connectors GPIO connector SD-Card Network LEDs Antenna location for connector connector WWAN or WLAN...
2 Identification with serial number The « SMT210 » device embeds « Gekkota » software. A serial number stamp permits to identify the device. Note: In case technical support is requested, this serial number could be required to go ahead on technical analysis.
4 LED behaviour (version Gekkota_os 3.12.15 or above) LED POWER behaviour (power on device) : State/behaviour Information « POWER » Power OK : power supplied Error : power supply issue (*1) LED LAN behaviour (power on device) : LED «...
Page 9
(*2) Error (*1) (*1) If the problem persists despite of appropriate power-supply, contact INNES technical support (*2) If the problem persists, it is advised to find out the media not supported yet by the system and remove it from playout.
5 Connectors pin-out and electrical features 5.1 Pin-out Power supply connector: 12VDC, 830mA. Pin-out Network connector: Ethernet RJ-45. Compatible with PoE technology (Power over Ethernet). 10/1000 BaseT. It is recommended to use shielded cables GPIO connectors: Connector pin-out: Pin N# Function Type PIN1...
5.2 GPIO electrical features Vin min Vin max VOH min VOH max IOH max VOL max IOL max VIH min VIL max GPIO2 -0.5V 6.5V 0.4V 10mA 1.17V 0.63V GPIO3 -0.5V 6.5V 0.4V 10mA 1.17V 0.63V GPIO4 -0,5V 3.8V 3.1V 3.3V -100µA 0,6V...
7 How to use the SMT210 relay 7.1 Relay : flow diagram Relay flow diagram GPIO1 will control opening /closing relay (write ‘1’ : closed, ‘0’ : open). There is no direction on relay contact. Contact connection can be for example invert on the following flow diagram (supply could be...
Note: this only freewheel diode (D1), mounted in parallel of the electromagnetic strike/sucker (L1) ensure electrical protection against overvoltage, several Volt which can destroy part of SMT210 when the relay is opened, making it unusable. Example of visual flow diagram of electromagnetic strike/sucker with its freewheel diode (not...
8 RFID/NFC The SMT210 device has a RFID interface permitting to read cards with two types of technology: RFID This table just below is listing the common card manufacturers (the last column is showing whether the cards are supported or not by the device SMT210).
9 Technical specifications Type Specifications Model SMT210 Supported formats The list of supported formats are detailed on website www.innes.pro Processor CPU : DM3730 1 GHz Peripherals 2x USB2 host 1x USB client 1x Jack 3.5 for GPIO (or infra-red) 1x GPIO output (controlled by a relay)
10 Appendix 10.1 Use of WIFI key WPA-PSK & WPA2-PSK on Innes devices The use of WPA-PSK key imply for the Innes devices the TKIP encryption protocol : pairwise=TKIP group=TKIP key=psk The use of WPA2-PSK key imply for the Innes devices the CCMP encryption protocol : ...
