BZ2000-ANT
High Gain Panel Antenna for Blitz 2000
1 x Panel Antenna
1 x Receiver Mounting Bracket
1 x Stand Mount Bracket
1 x Stand Mount Brace
5 x NJWC to SMA Coaxial Cable Connectors
4 x M3 Mounting Screws
4 x M4 Mounting Screws
www.ikancorp.com
support@ikancorp.com
© 2015 ikan Corpora tion.
713.272.8822
All rights Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Blitz BZ2000-ANT and is the answer not in the manual?

Questions and answers

Summary of Contents for Ikan Blitz BZ2000-ANT

  • Page 1 1 x Receiver Mounting Bracket 1 x Stand Mount Bracket 1 x Stand Mount Brace 5 x NJWC to SMA Coaxial Cable Connectors 4 x M3 Mounting Screws 4 x M4 Mounting Screws www.ikancorp.com 713.272.8822 © 2015 ikan Corpora tion. support@ikancorp.com All rights Reserved...
  • Page 3: Product Description

    Product Description The Blitz BZ2000-ANT is a directional high-gain antenna compatible with the Blitz BZ1000 receiver. The five antenna ports connect to the panel antenna which can increase the maximum distance from 1000 ft to 2000 ft under the same conditions. This panel antenna will increase distance as well as signal strength for shorter distances.
  • Page 4: Performance Parameters

    Performance Parameters Specifications BZ2000-ANT Model Frequency Range 5.0-5.9GHz Gain 14±0.5dBi ≥25dB (F/B Ratio) ≥26dB Isolation Horizontal Beam Width 40±5º Vertical Beam Width 40±5º ≤2.0 V.S.W.R Polarization 5 ports: 3 ports vertical,2 ports±45º Maximum Power 100W Impedance 50ohm -40°C to + 55°C Working Temperature Connector Type 5*N-K...
  • Page 5: Packing List

    Packing List 1 x Receiver 1 x Stand Mount 1 x Panel Antenna Mounting Bracket Brace 4 x M4 Mounting 4 x M3 Mounting 5 x NJWC to SMA coaxial Screws Screws cable connectors...
  • Page 6 Installation Guide...
  • Page 7 Place the BZ1000 receiver on the receiver bracket and line up the 4 holes from the Ikan Quick Mount system on the front of the unit to the 4 holes on the receiver bracket. Use the included 4 x M4 screws to then attach the receiver to the bracket.
  • Page 8: Installation Diagram

    Installation Diagram Top view 45° Transmitter Receiver Side view TX & RX Must Face Each Other The receiver should be at least 2 meters off the ground. Ground...
  • Page 9: Troubleshooting

    Troubleshooting (1) If there is no video signal within 10 to 30 ft, then check the video input source and output. (2) If you experience poor video quality from 1000 to 2000 ft please check whether the transmitter and receiver are set up as outlined in this manual. If they are setup correctly, then check if the coaxial cables on the antenna are connected properly, damaged, or if the port is dirty.
