Warnings & Attention Please avoid aiming the lens at extreme high temperature radiation source, such as the sun, molten steel or laser in any situation; otherwise the detector may be damaged. Please do not touch the lens to avoid contaminating and damaging. Please pay attention to protect the lens to avoid causing abrasion, scratches even breaches, otherwise, it will affect the device performance badly, even damage the device.
CONTENTS 1 OVERVIEW............................3 1.1 F ............................3 EATURES 2 ELECTRICAL CONNECTIONS ...................... 4 2.1 C ........................4 ONNECTING POWER 2.2 E ........................4 THERNET CONNECTION 3 QUICK START OF THE IVMS SOFTWARE ................. 5 3.1 S VMS C ....................5 TARTING LIENT OFTWARE...
1 Overview 1.1 Features 1. Provider good image quality in total darkness. 2. Multiple optional lenses for thermal camera, meet different requirements of surveillance distance 3.2MP high-resolution visible light camera, 20X optical zoom. 3. Easy integration into IP network, support multiple network and PTZ control protocols, video transmission over Ethernet.
2 Electrical connections 2.1 Connecting power The camera itself does not have an on/off switch. Connect AC24V power supply, if power is supplied to it, the camera will be Powered On. Note: Generally the camera will be connected to a circuit breaker and the circuit breaker will be used to apply or remove power to the camera.
3 Quick Start of the IVMS software 3.1 Starting VMS Client Software Note: This chapter only introduce some basic function, more specifics and functions, pls check “VMS- Client software User Manual”(refer to chapter 3.2:click help, and open user manual). Install the VMS- software on your PC according to the prompts. For the first time to use the VMS software, you need to register a super user for login.
Page 7
Wizard If this is not the first time, you use the client software, the wizard does not pop up, and you can use the wizard, click Help and Open Wizard (or user manual if necessary). Open wizard and User Manual Click [Entering Guide] to start the wizard, or click Cancel to exit the wizard.
Page 8
2. Create a nickname for the device, enter the IP address and the port number of the remote device, enter the user name, and the password of the device. Note: Default IP address marked on the rear of camera Default user name: admin Default password: 123456...
Page 9
3. Click Add icon to add the device. You can also click Show online device to show the device connected to the same Local Area Network. Adding the active online devices Steps: 1) Select the device in the device list, and the information of the device such as the MAC address the software version and the serial number is shown in the left part.
Page 10
4.) Adding Camera Group When adding a device, you can check the Export to group checkbox to export the device you added to certain camera group. By default, the name of the group is the same with the name of the device you just added. If you want customize the camera choosing for the group and the group name.
Page 11
Click the on Group dialog box. Edit the name of group and then click OK to save your settings. The added group will be displayed in the list. 5). Import Channels to Group In the left area on the Camera Import interface, click to select the channels and then click Import button to import the selected channels to the Group on the right.
3.3 Live view Entering the Live View Interface: Click the main view icon on the control panel, or click View -> Main View on the toolbar to enter the live view interface. The main view interface is shown in the following figure: To view the live video, drag the camera from the list to the display window, or double click the camera name after you select one screen.
3.4 Camera control A. How to set camera control configuration Click the icon on the toolbar on the screen for camera or click the right button of the mouse to pop up the menu. Camera setting option...
Page 14
On the PTZ parameters configuration page, you can specific the camera connection parameters, such as baud rate, data bit, PTZ protocol and PTZ address. The info (including IP address) marked on the rear of the housing. Note: The default setting (Baud rate: 2400; Protocol: PELCO-D; PTZ address: 2) Click save button to save the changes PTZ parameters configuration B.
Page 15
PTZ control option PTZ control toolbar PTZ control panel display on the left side of the main view...
Page 16
ZOOM Toolbar FOCUS Tool bar IRIS Toolbar Camera control board PTZ control board Button Description Zoom: N/A Zoom-: Digital zoom(shortcut key) Zoom+: Alarm switch(shortcut key) Focus: N/A Focus-: When there is a menu, modify the option or reduce the value Focus+: When there is a menu, modify the option or increase the value Iris: N/A...
Page 17
The image in calibration procedure C. Pop up the thermal camera configure menu: Select a PTZ preset number from the preset list, and double click preset 100 or click call preset 100, the camera configure menu display on the image. PTZ preset setting...
4 Thermal camera configuration menu 4.1 Main menu After pop the menu via call preset 100, the menu display on the bottom of the image: Press key “IRIS-” move the cursor,Press key “FOCUS+” or “FOCUS-” to change the value where the cursor is. Auto save when exit 1、Auto: XXX Display the current image auto mode.
Page 19
Black hot White hot 5、ZOOM:Y/N Zoom status N:no zoom(default) Y:Zoom 2 times No zoom Zoom 2 times 6、Level: X show the level of alarm:From 1 to 6, default is 4.Alarm feature was invalid in this system 7、Setting: Press key “FOCUS+” or “FOCUS-”,show the password dialogue Press “FOCUS-、FOCUS+、FOCUS-、FOCUS+、FOCUS-、FOCUS+”...
4.2 Sub menu In the main menu, move the cursor to “Settings “option ,press ”Focus+”or “Focus-” show the password dialogue, input the password “FOCUS-、FOCUS+、FOCUS-、FOCUS+、FOCUS-、 FOCUS+” to enter. Password dialogue Sub menu Press key “IRIS-” move the cursor , Press key “FOCUS+” or “FOCUS-” to change the value where the cursor is 。Auto save when exit...
Page 21
COM option: Press key “FOCUS+” or “FOCUS-” show the password dialogue,Input the password “FOCUS-、 FOCUS+、FOCUS-、FOCUS+、FOCUS-、FOCUS+” enter the “COM” option In the menu “COM”,Press key “IRIS-” move the cursor ,Press key “FOCUS+” or “FOCUS-” to change the value where the cursor is 。Auto save when exit (1) ID:XXX ADD:0~254。...
Page 22
In the menu “Mode”, Press key “IRIS-” move the cursor , Press key “FOCUS+” or “FOCUS-” to change the value where the cursor is 。Auto save when exit (1) Gain:XXX Range: 0~255。 (2) Bright:XXX Range: 0~255。 (3) Exit: Press key IRIS+ to exit Default:G:32 B: 188 Alarm Valve:...
Page 23
Setup as H: Calibrate 1 time during the 1 minute if working time less than 10 minutes. Calibrate 1 time during 2 minutes if working time between 10 and 30 minutes. Calibrate 1 time during 5 minutes if working time between 30 minutes and 1 hour. Calibrate 1 time during 10 minutes if working time more than 1 hour.
