Herzan WaveCatcher Quick Manual

Acoustic, vibration, and emi isolation specialists
Hide thumbs
1
2

Advertisement

Table of Contents

WaveCatcher Quick Guide
How to Setup WaveCatcher Hardware

Overview

Setting up the WaveCatcher hardware is intentionally designed to be intuitive, reinforcing the
WaveCatcher's capability as an efficient and effective site survey tool. The following steps
highlight how to correctly setup the WaveCatcher hardware and the various sensors available.

Standard WaveCatcher Hardware

1. QTY 1: Netbook Computer and Power Supply
2. QTY 1: WaveCatcher Analog-to-Digital Converter (ADC), Power Supply, D Sub Extender Nuts,
and Connection Cable (USB Type B to USB Type C Cable)
3. QTY 1: Custom Sensor Cable (D Sub to 3 BNC Cable) and BNC Cable Adapter
4. QTY 1: Carrying Case
1
3
WaveCatcher Quick Guide | How to Setup WC Hardware | www.herzan.com
Acoustic, Vibration, and
EMI Isolation Specialists
2
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WaveCatcher and is the answer not in the manual?

Questions and answers

Summary of Contents for Herzan WaveCatcher

  • Page 1 How to Setup WaveCatcher Hardware Overview Setting up the WaveCatcher hardware is intentionally designed to be intuitive, reinforcing the WaveCatcher’s capability as an efficient and effective site survey tool. The following steps highlight how to correctly setup the WaveCatcher hardware and the various sensors available.
  • Page 2 Figure 2: Acoustic Microphone Connected to WaveCatcher ADC Power on the WaveCatcher ADC by using the on/off switch on the front panel. Step 3: Turn On The Netbook Computer and Load the WaveCatcher Software Once the hardware and measurement sensor(s) Power Button are connected, power on the netbook computer by pressing the Power button.
