Operating Manual
Operating Manual
of the ORTNER Combustion Control V2.2
LED
WLAN
DISPLAY
ORTNER control installed on:
Serial number

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ABS Combustion Control V2.2 and is the answer not in the manual?

Questions and answers

Summary of Contents for ORTNER ABS Combustion Control V2.2

  • Page 1 Operating Manual Operating Manual of the ORTNER Combustion Control V2.2 WLAN DISPLAY ORTNER control installed on: Serial number...
  • Page 3: Table Of Contents

    Table of contents One control, three display options ���������������������������������������������������������������������������������4 General function ���������������������������������������������������������������������������������������������������������5 Important information �������������������������������������������������������������������������������������������������6 Initial start-up �������������������������������������������������������������������������������������������������������������6 LED variant ����������������������������������������������������������������������������������������������������������������8 Visualization of the combustion phases with LED ����������������������������������������������������������8 Combustion phases and colour description ��������������������������������������������������������������������8 Display variant �������������������������������������������������������������������������������������������������������� 10 Visualization of the combustion phases with glass display �������������������������������������������� 10 Indications on the display of each heating phase ����������������������������������������������������������...
  • Page 4: One Control, Three Display Options

    • ORTNER control with LED display • ORTNER control with LED display and WLAN • ORTNER control with display (black or white) The ORTNER combustion control. Simple and elegant. Fig. 1: LED variant, Fig. 2: Display black, Fig. 3: WLAN view on smartphone...
  • Page 5: General Function

    4� Embers phase 5� Standby phase The ORTNER Combustion control ensures an optimal sequence of the burn-off phases of the furnace installation� Components such as the sensor and the combustion air flap ensure accurate control, which not only ensures ease of operation, but also maximum efficiency�...
  • Page 6: Important Information

    The ORTNER combustion control safeguards the optimal energy yield with a maximum degree of safety�...
  • Page 7 Page 7...
  • Page 8: Led Variant

    LED variant The LED variant is the most basic of the ORTNER control range. This visualization of the ABS displays the different combustion levels in the most simplest manner. Visualization of the combustion phases with LED Light purple Blue Orange...
  • Page 9 The masonry heater switches to the heating phase: Heating state • Is activated from a temperature of >250 °C • The combustion air register is open • The maximum temperature is stored • Determination of the optimal transition temperature to embers The masonry heater switches to the heating phase >600°C: Heating state •...
  • Page 10: Display Variant

    Display variant All important data is presented on the display during the combustion� In this manner, you can continuously see the temperature and the status of the heating process� When the control switches into the embers phase, the display will dim� Only when a new combustion is begun will the display light up again brightly and all status messages will be displayed�...
  • Page 11 Door open for heating up: • The stove door is opened for heating up • The heating up phase begins with the closing of the door • The combustion air register opens Line 2 on the display (= continuous text): Status: Door open –...
  • Page 12: Wlan Variant

    WLAN variant Easily monitor the combustion of your masonry heater via a smartphone, tablet or PC In combination with the LED display, the WLAN module provides you with the option to also visualize the current status of the combustion on mobile devices� Visualization of the combustion phases with LED Light purple Blue...
  • Page 13: Installation Of The Wlan Module With Mobile Devices

    2� Set the switch on the WLAN module to the LEFT POSITION 3� Switch the control on 4� Activate your WLAN on your telephone or tablet and connect with ORTNER-… (e�g� ORTNER-lower) 5� Launch your web browser (Internet) and enter http://1�2�3�4 in the search bar Congratulations, you have successfully connected with the WLAN module and can now access all data online.
  • Page 14: Integration In An Existing Personal Network

    1 second� 5� Using a device with wireless connectivity (notebook, smartphone, tablet, etc�) search for the “ORTNER” WLAN and connect to this� 6� Open a web browser and enter http://1�2�3�4 in the address bar�...
  • Page 15 7� Press “Refresh List” in order to receive a list with the available networks� 8� Select the desired network and enter the password of your personal network in “Pass phrase”� The settings are saved by pressing “Save Configuration”� 9� Switch the control off and back on after approx� 5 seconds� Page 15...
  • Page 16: Integration Has Failed� Now What

    Try to locate teh module‘s IP assress, under the following possibilities: 1� Windows Use the SoftPerfect Network Scanner application http://www�softperfect�com/download/freeware/netscan�zip 2� First press “Auto Detect IP Range” and then “Start Scanning” 3� Search the MAC address that is noted on the module’s mounting, e�g�...
  • Page 17 4� Enter the corresponding IP address in the web browser http://<IP-Adresse>/� In this example 192�168�1�116 http://192�168�1�116/� 5� Android and iPhone The free app “Fing” is available for Android and iPhone: https://play�google�com/store/apps/details?id=com�overlook�android�fing&hl=de https://itunes�apple�com/at/app/fing-network-scanner/id430921107?mt=8 6� Search the MAC address that is noted on the module’s mounting, e�g�...
  • Page 18: Error Messages And Their Correction

    Error messages and their correction Heating up errors LED lit and flashing Heating up errors Display text of the glass display TEMP1 230°C Heating error – Door closed – Heating error – Register open – Heating error – Heating time = 61 min - Heating error –...
  • Page 19: Defective Sensor

    Defective sensor LED flashing Sensor error Display text of the glass display Sensor error – Door closed – Sensor error – Register open – Sensor error – Heating time – 100 min – Sensor error – (Temp2 = 29 °C) Possible cause •...
  • Page 20: No Power Supply

    No power supply LED not lit No power supply The LED is not lit and no motor sounds are audible when the door is opened. Display text of the glass display No display text present� Possible cause • The LED cable is defective •...
  • Page 21: Door Closed, Although The Door Is Open

    Correction Check the contact point of the door for contamination or residue and if necessary, remove this with fine sand paper� Additionally, check the axial position of the magnet at the door sensor� The distance between the door sensor and the magnet should not be greater than 5 mm� Also check the compression fittings on the control�...
  • Page 22 Notes...
  • Page 23 Concept, text & layout: ORTNER GmbH Picture credits: title page, Page 2, 4, 5, 7: Andreas Zapfe, Page 13: Fotolia_76103803_M, Page 6: Luis Steinkellner, Page 4, 8-12, 14-17: ORTNER GmbH Changes and misprints reserved. No responsibility is accepted for the correctness of this information. The simultaneous use of the male and female form is avoided in order to ensure increased readability.
  • Page 24 ORTNER GmbH Hürmer Straße 36 A-3382 Loosdorf/Melk T +43 (0) 2754 2707 F +43 (0) 2754 2708 technik@ortner-cc.at www.ortner-cc.at...
