AXIOMET AX-C709 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1. Introduction
Warning
Read"Safety Information"before using the meter. ProcessMeter ( referred to as "the meter ")is a handheld,
battery-operated tool for measuring electrical parameters. It has all the features of a digital multimeter, it
could also output signals of direct voltage, current and frequency as well.
If the meter is damaged or something is missing, contact the place of purchase immediately. Contact a
distributor for information about DMM (digital multimeter) accessories.

2. Safety Information

The meter complies with IEC61010.1-93 Overvoltage CategoryII.Use the meter only as specified in this
manual, otherwise the protection provided by the meter may be impaired. A Warning identifies conditions
and actions that pose hazard(s) to the user; a Caution identifies conditions and actions that may damage
the meter or the equipment under test; an Attention identifies symbols of the operation and explanations
of the features. International symbols used on the meter and in this manual are explained below.
Warning
To avoid possible electric shock or personal injury:
• Do not use the meter if it is damaged. Before using the meter, inspect the case. Look for cracks or
missing plastic. Pay particular attention to the insulation surrounding the connectors.
• Make sure the battery door is closed and latched before operating the meter.
• Remove test leads from the meter before opening the battery door.
• Inspect the test leads for damaged insulation or exposed metal. Check test leads before using the
meter.
• Do not use the meter if it operates abnormally. Protection may be impaired. When in doubt, have the
meter serviced.
• Do not operate the meter around explosive gas, vapor, or dust.
• Use only type AAA batteries, properly installed in the meter case to power the meter.
• When servicing the meter, use specified replacement parts.
• Use caution when working above 30V ac rms, 42V ac pk, or60V dc. Such voltages pose a shock hazard.
• When using the probes, keep fingers behind the finger guards on the probes.
• Connecting the common test lead before connecting the live test lead. When disconnecting test leads,
disconnect the live test lead first.
AX-C709

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AX-C709 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AXIOMET AX-C709

Summary of Contents for AXIOMET AX-C709

  • Page 1: Safety Information

    AX-C709 1. Introduction Warning Read“Safety Information”before using the meter. ProcessMeter ( referred to as “the meter ”)is a handheld, battery-operated tool for measuring electrical parameters. It has all the features of a digital multimeter, it could also output signals of direct voltage, current and frequency as well.

  • Page 2: Measuring Electrical Parameters

    • Do not touch the charging connector when the test lead is connected. Caution! To avoid possible damage to meter or to equipment under test: • Disconnect the power and discharge all high-voltage capacitors before testing resistance or continuity. • Use the proper jacks, function, and range for the measurement or sourcing application. International Electrical Symbols AC Current DC Current...

  • Page 3: Testing Diodes

    5. Ranges A measurement range determines the highest value and resolution at which the meter can measure. Most meter measurement functions have more than one range (see “Specifications”). Make sure the correct range is selected: - If the range is too low, the display shows OL (overload). - If the range is too high, the meter will not be displaying its most precise measurement.

  • Page 4: Output Function

    9. Measuring Frequency, Duty Cycle Ratio Press <Hz> to show Frequency, Duty Cycle Ratio and Voltage (Current) in sequence when measuring voltage (DC mV voltage excluded) and current. 10. Measuring TC • Insert the one end of the test lead into the Hi (MEASURE) and COM jack and connect the other end to the TC output.

  • Page 5: Dc Voltage Output

    Using: Do not append voltage to the output jack; otherwise the internal circuit would be damaged for impropriety. 13. Simulate Output of Resistance or RTD Caution! Resistance-simulation: The simulator produces the simulation resistance up to 400Ω at its output termi- nal (Ohms/RTD).

  • Page 6: Frequency Output

    15. Simulating output from thermocouple (TC) • Insert one end of the test lead into the Hi (OUTPUT) jack and COM jack of the meter and connect the other end to the input of the user’s instrument. • Set the rotary function switch to TCmV, and press the blue button to select TC function and displays unit “°C”...

  • Page 7: Dc Current Output

    17. Simulating Transmitter output (absorption current) XMT refers to simulate a current loop circuit transmitter with the meter. Do this when you get external dc voltage (5-28 V) or have current loop in series. Caution! Set the rotary button in one of the mA output before connecting the testing leads with current loop circuit. Otherwise, low impedance from other parts of rotary will occur in the circuit and caused 35mA current in circuit.

  • Page 8: Replacing A Fuse

    To avoid electrical shock or personal injury: • Remove test leads from the meter before opening the battery door. • Close and latch the battery door before using the meter. Note • The new and old Batteries can not be mixed. •...

  • Page 9: Technical Specifications

    21. Technical specifications 21.1. All the speculations apply to +18℃to +28℃, 10% to 70%RH unless stated otherwise. All speculations assume a 5- minute warm- up period. Standard speculation is valid for one year. Note “Counts” refers to the number of increments or decrements of the least significant digit. 21.2.
  • Page 10 1 - Range 2- Resolution 3 - Accuracy Measuring Impedance: 10 MΩ(nominal) Overvoltage protection: 600Vp 21.4. TC Measurement 1 - Range 2 - Set Range 3 - Resolution 4 - Accuracy...
  • Page 11 By using ITS-90 temperature scale Note: The accuracy does not include the error of internal temperature compensation caused by a sensor. The range of the internal temperature compensation sensor is + 2℃. 21.5. AC Voltage Measurement 1 - Range 2- Resolution 3 - Accuracy Specifications are valid from 5% to 100% of amplitude range 400mV is only confined to manual range...
  • Page 12 1 - Range 2- Resolution 3 - Accuracy Overload protection: 0.5A,250V fast-blow fuse Measuring Impedance: 1Ω 21.7. AC current measurement 1 - Range 2- Resolution 3 - Accuracy Specifications are valid from 5% to 100% of amplitude range Overload protection: 0.5A,250V fast-blow fuse Measuring Impedance: 1Ω...
  • Page 13 1 - Range 2- Resolution 3 - Accuracy Open circuit voltage:0.4v Guide lead resistance is excluded in the accuracy Overvoltage protection: 600Vp-p 21.9. RTD Measurement 1 - Range 2 - Input range 3 - Resolution 4 - Accuracy By using Pt100-385 temperature scale Measuring current 1 mA Note: attached lead resistance is excluded 21.10.
  • Page 14 1 - Range 2- Resolution 3 - Accuracy Display updates 3 times/second (at >10Hz) 21.11. Diode Test and Continuity Test • Diode test indication: Displays voltage drop across device, open circuit voltage: 1.1v-1.6v; short circuit current :<0.2mA (typical value). Accuracy± (2%reading +1count) •...

  • Page 16: General Specifications

    1 - Function 2 - Range 3 - Set Range 4 - Resolution 5 - Accuracy 6 - Remark Maximum voltage applied between any output jack and earth ground :30 V DC Fuse-protection for output jacks: 63mA,250V fast-blow fuse 22. General Specifications •...
  • Page 17 • Maximum Voltage:600Vp-p(Maximum Voltage between all input jacks and earth ground) 30V DC (Maximum Voltage between all output jacks and earth ground) • Operating temperature: 0℃-50℃ • Operating relative humidity:≤ 80% RH • Storage temperature: -10 ℃-55 ℃ • Storage humidity:≤ 90%RH •...
