Installer Manual
03925
4-button flat device with 2.4 GHz Bluetooth® technology Low
Energy standard radiofrequency transmitter, energy harvesting sup-
ply powered by built-in electrodynamic generator, to complete with
Eikon 20506 or 20506.2, Arké 19506 or 19506.2 or Plana 14506 or
14506.2 buttons - 2 modules.
HOME AUTOMATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 03925 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vimar 03925

Summary of Contents for Vimar 03925

  • Page 1 Installer Manual 03925 4-button flat device with 2.4 GHz Bluetooth® technology Low Energy standard radiofrequency transmitter, energy harvesting sup- ply powered by built-in electrodynamic generator, to complete with Eikon 20506 or 20506.2, Arké 19506 or 19506.2 or Plana 14506 or 14506.2 buttons - 2 modules.

  • Page 3: Table Of Contents

    1.1 Basic functionality …………………………………………………………………………………………………………………………………………………………………… 4 1.2 Technical data ……………………………………………………………………………………………………………………………………………………………………… 4 1.3 Environmental conditions …………………………………………………………………………………………………………………………………………………………… 4 2. Functional information ………………………………………………………………………………………………………………………………………………………………… 5 2.1 03925 Device Overview …………………………………………………………………………………………………………………………………………………………… 5 2.2 Basic Functionality …………………………………………………………………………………………………………………………………………………………………… 5 2.3 User Interface ………………………………………………………………………………………………………………………………………………………………………… 5 3. Telegram transmission ………………………………………………………………………………………………………………………………………………………………… 6 3.1 Radio channel parameters …………………………………………………………………………………………………………………………………………………………...

  • Page 4: General Description

    03925 pushbutton transmitters are self-powered (no batteries) and fully maintenancefree. They can therefore be used in all environments including locations that are difficult to reach or within hermetically sealed housings. The required energy is generated by an electro-dynamic energy transducer actuated by an energy bow located on the left and right of the module.

  • Page 5: Functional Information

    2.3 User Interface 03925 devices provide four button contacts. They are grouped into two channels (Channel A and Channel B) each containing two button contacts (State O and State I). The state of all four button contacts (pressed or not pressed) is transmitted together with a unique device identification (48 Bit device ID) whenever the energy bow is pushed or released.

  • Page 6: Telegram Transmission

    03925 transmits Bluetooth technology Low Energy (BLE) advertising telegrams within the 2.4 GHz radio frequency band (2402MHz … 2480MHz). By default, 03925 will use the three BLE advertising channels (BLE Channel 37, 38 and 39) defined for transmission. The transmission of a radio telegram on these three advertising channels is called an Advertising Event.
  • Page 7 CH_REG2 and CH_REG3. The 03925 telegram will in this mode be transmitted on the radio channel selected by CH_REG1 first, immediately followed by a transmission on the radio channel selected by CH_REG2 and a transmission on the radio channel selected by CH_REG3.

  • Page 8: Telegram Format

    The structure of 03925 static addresses is as follows: ■ The upper 2 bytes of the source address are used to identify the device type and set to 0xE215 for all 03925 devices. These two bytes cannot be changed. ■ The lower 4 bytes are uniquely assigned to each device. They can be changed using the NFC configuration interface as described in chapter 6.7.3 Figure 10 below illustrates the static address structure used by 03925.

  • Page 9: Check Sum

    4.4.2 Private resolvable source address mode For some applications it is desirable to modify (rotate) the source address used by 03925 in order to prevent tracking of its radio transmissions. At the same time, each 03925 device must remain uniquely identifiable by the receiver.

  • Page 10: Payload

    4. Calculate security signature In 03925, the type of action (Press Action or Release Action) is indicated by Bit 0 (Energy Bar). If a button contact has been actuated during Press Action or Release Action then this is indicated by the according status bit set to ‘1’.
  • Page 11 03925 and only accepts messages with higher sequence counter values (i.e. not accepts equal or lower sequence counter values for subsequent telegrams). 4.8.1 Authentication implementation 03925 implements telegram authentication based on AES128 in CCM (Counter with CBC-MAC) mode as described in IETF RFC3610. At the time of writing, the RFC3610 standard could be found here: https://www.ietf.org/rfc/rfc3610.txt The 13 Byte CCM Nonce (number used once –...

  • Page 12: Commissioning

    ■ Device identification The receiver needs to know how to uniquely identify this specific 03925 device. This is achieved by using a unique 48 Bit ID (Source Address) for each 03925 device as described in chapter 4.4. In addition, up to 4 byte of Optional Data can be configured as described in chapter 6.7.6.
  • Page 13 Figure 18 – Button sequence to enter radio-based commissioning mode To enter commissioning mode, start by selecting one button contact of 03925. Any button of 03925 (A0, A1, B0, B1) can be used. This button is referred to as Button_X in Figure 18 above.

  • Page 14: Factory Reset

    03925 can be reset to its default settings by means of a factory reset. This ensures that 03925 can be reset to a known configuration in case the PIN for the NFC access has been lost or NFC access is not possible for other reasons.

  • Page 15: Nfc Interface

    6. NFC interface 03925 implements NFC Forum Type 2 Tag functionality as specified in the ISO/IEC 14443 Part 2 and 3 standards using an NXP NT3H2111 Mifare Ultralight tag. This NFC functionality can be used to access (read and write) the 03925 configuration memory and thereby configure the device as described in the following chapters.
  • Page 16 NFC interface 6.2.2 IDLE state IDLE is the waiting state after a Power-On Reset (POR), i.e. after the NFC tag has been introduced into the magnetic field of the NFC reader. The NFC tag exits the IDLE state towards the READY 1 state when either a REQA or a WUPA command is received from the NFC reader. REQA and WUPA commands are transmitted by the NFC reader to determine whether any cards are present within its working range.

  • Page 17: Configuration Memory Organization

    ■ Public data ■ Protected data In addition to that, 03925 maintains a private configuration memory region used to store default parameters and confidential information which is not accessible to the user. Figure 24 below illustrates the configuration memory organization used by 03925.

  • Page 18: Memory Address Map

    Product ID and Manufacturer ID can be configured by the customer as required to identify his 03925 based product, see chapter 6.6.5 ■ 03925 Static Source Address This is a 4 byte field used to identify the static source address used by 03925, see chapter 4.4.1. Each 03925 is pre-programmed with an individual staticsource address.

  • Page 19: Protected Data

    6.6.3 Source Address Write register The Source Address Write register is 4 byte wide and can be used to modify the lower 32 bit of the 03925 Static Source Address. The upper 16 bit of the 03925 Static Source Address are always fixed to 0xE215 to identify the device type.
  • Page 20 4. Actuate (press and release) the energy bar of 03925 03925 will determine that it should modify the security key based on the setting of the Update Security Key flag and copy the value of the Security Key Write register to the Security Key register in private memory.
  • Page 21 NFC interface 6.6.8 Custom Variant register The Custom Variant register is 1 byte wide and allows selection of the custom radio transmission modes as described in chapter 3.3. Table 3 below shows the supported custom radio transmission settings. Setting Meaning Commissioning and data telegrams in standard Advertising Mode (Default configuration).

  • Page 22: Private Data

    6.6.10 Customer Data 03925 allocates 64 pages (256 byte) for customer data that can be read and written via the NFC interface in protected mode. The main intention is to enable storing OEM-specific information such as product type, revision, date code or similar. There is however no restriction (other than the maximum size of 256 byte) on the type of content that can be stored in this memory region.

  • Page 23: Application Information

    (for how long will the receiver scan within each scanning cycle). 03925 transmits the advertising events with a pause interval of 20 ms between two transmissions. The transmission of the advertising event itself requires approxi- mately 1 ms per radio channel (meaning approximately 3 ms in total when using 3 radio channels) which means that the total time between the start of two advertising events is approximately 23 ms.

  • Page 24: Installation Rules

    Standards EN 60950-1, EN 301 489-17, EN 300 328, EN 62479. Vimar SpA declares that the radio equipment complies with Directive 2014/53/EU. The full text of the EU declaration of conformity is on the product sheet available at the following Internet address: www.vimar.com.
  • Page 26 Viale Vicenza 14 36063 Marostica VI - Italy 03925IEN 01 1806 www.vimar.com...
