Summary of Contents for Dust Networks SmartMesh IA-510 D2511

  • Page 1 Dust Networks SmartMesh ® IA-510 D2511 Manager Guide Industrial...
  • Page 2 Dust Networks to use such products or services or a warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the third party, or a license from Dust Networks under the patents or other intellectual property of Dust Networks.

  • Page 3: Table Of Contents

    Contents About This Guide Related Documents ............iii Conventions Used ............... iii Revision History ..............iv 1 Introduction What is a SmartMesh Network? .........1 SmartMesh Network Features ..........2 SmartMesh Manager’s Role............2 Manager Packing List ............2 Manager Overview ..............3 10/100Base-T Ethernet Interface ...........3 Serial 1 Interface ..............4 Serial 2 Interface ..............6 2 Specifications...
  • Page 4 ABLE OF ONTENTS Connecting the Manager Directly to a Computer ... 14 Installing the Manager on the LAN ........15 A Configuring Serial 1 Operation Configuring the Serial 1 Interface ........17 Using Admin Toolset to Configure Serial 1 ......17 Using Linux Commands to Configure Serial 1 ......

  • Page 5: About This Guide

    About This Guide ® Thank you for purchasing the SmartMesh IA-510 D2511 manager. This guide provides an overview of the hardware and software resources of the D2511 manager in addition to detailed specifications. Related Documents This guide is a part of a documentation suite for the IA-510 family of products. The following documents contain important information for software and firmware development with an IA-510 manager: •...

  • Page 6: Revision History

    BOUT UIDE Revision History Revision Date Description 040-0075 rev 1 8/5/2009 Final (product release). 040-0075 rev 2 11/18/2009 040-0075 rev 3 8/10/2010 IA-510 D2511 M MART ANAGER UIDE...

  • Page 7: Introduction

    Introduction The SmartMesh IA-510 D2511 network manager combines Dust Networks’ robust intelligent networking and industry-leading low-power radio technology to achieve the high data reliability, lower latency, and deterministic power management required for condition monitoring applications. The D2511 acts as both a gateway and network manager for up to 250 SmartMesh IA-510 motes (DN2510 or M2510), creating a self- configuring, reliable wireless mesh network.

  • Page 8: Smartmesh Network Features

    1 - I What is a SmartMesh Network? HAPTER NTRODUCTION • Motes are ultra low-power wireless transceivers that receive serial data from attached sensors and use an onboard radio to send the packets to neighboring motes. These motes pass the packet on to other motes—and, in a series of “hops” deliver the data to the SmartMesh manager.

  • Page 9: Manager Packing List

    Manager Packing List 1 - I HAPTER NTRODUCTION Manager Packing List The components shipped with the D2511 manager are listed in Table 1. Table 1 Packing List for the D2511 Manager Component Amount Description D2511 manager Controls and monitors the network. Power cable Connects the manager to an AC outlet.

  • Page 10: Manager Overview

    1 - I Manager Overview HAPTER NTRODUCTION 10/100Base-T Ethernet Interface The 10/100Base-T Ethernet interface is a standard RJ45 connector which provides users with access to manager’s XML-RPC API and the Admin Toolset utility. Table 2 Ethernet Port Hardware Specifications Port Description Signaling Ethernet...

  • Page 11: Serial 1 Interface

    Manager Overview 1 - I HAPTER NTRODUCTION Serial 1 Interface The Serial 1 interface (RJ45 connector) provides programmatic access for configuration, management, and data access to the manager. The interface can be used for one of two functions: • To access the manager using Point-to-Point Protocol (PPP) •...

  • Page 12: Serial 2 Interface

    (CLI) through RS232. The CLI can be used to set the configuration of the Serial 1 interface and for troubleshooting with the assistance of Dust Networks support. Appendix A provides instructions on using the CLI to set the Serial 1 configuration.

  • Page 13: Specifications

    Specifications This chapter provides specifications, mechanical drawings, and certification information for the D2511 managers. Detailed Radio Specifications Table 7 D2511 Radio Specifications Parameter Units Comments Operating frequency 2.4000 2.4835 Number of channels Channel separation Occupied channel At –20 dBc bandwidth Frequency accuracy –40 Modulation...

  • Page 14: Antenna Specifications

    2 - S Antenna Specifications HAPTER PECIFICATIONS Antenna Specifications The antenna provided on the D2511 manager meets the specifications in Table 8. For optimum performance, position the antenna vertically when manager is installed. Table 8 D2511 Antenna Specifications Parameter Value Frequency range 2.4-2.4835 GHz Ω...

  • Page 15: Mechanical Drawings

    Mechanical Drawings 2 - S HAPTER PECIFICATIONS Mechanical Drawings Figure 7 Dimensions of D2511 Manager IA-510 D2511 M MART ANAGER UIDE...

  • Page 16: Regulatory And Standards Compliance

    CE Compliance Declaration of Conformity We, Dust Networks, of 30695 Huntwood Ave, Hayward CA 94544, USA, declare under our sole responsibility that our products, SmartMesh IA-510 D2511, and in combination with our accessories, to which this declaration relates is in conformity with the...

  • Page 17: Normal Operating Conditions

    Normal Operating Conditions 2 - S HAPTER PECIFICATIONS Normal Operating Conditions Table 9 D2511 Normal Operating Conditions Parameter Units Comments Operating °C temperature range IA-510 D2511 M MART ANAGER UIDE...
  • Page 18 2 - S Normal Operating Conditions HAPTER PECIFICATIONS IA-510 D2511 M MART ANAGER UIDE...

  • Page 19: Installing The D2511 Manager

    Installing the D2511 Manager The D2511 manager can be connected directly to a computer or installed on your local area network (LAN). The computer must have the following: • Windows Internet Explorer 7 (or later) or Firefox 2.0 (or later) •...

  • Page 20: Connecting The Manager Directly To A Computer

    3 - I D2511 M Connecting the Manager Directly to a Computer HAPTER NSTALLING THE ANAGER Connecting the Manager Directly to a Computer The D2511 manager is preconfigured with the static IP address 192.168.99.100 for connection directly to a computer. You will temporarily set the computer IP address to a static IP address that enables the computer to communicate with the manager.

  • Page 21: Installing The Manager On The Lan

    Installing the Manager on the LAN 3 - I D2511 M HAPTER NSTALLING THE ANAGER Click to close the dialog boxes. Note: When you are finished using the manager, you can switch your computer IP address back by selecting “Obtain an IP address automatically” on the General tab in the Internet Protocol (TCP/IP) Properties window.
  • Page 22 3 - I D2511 M Installing the Manager on the LAN HAPTER NSTALLING THE ANAGER C Establish a HyperTerminal connection to the manager using the following settings: • Bits per second: 115200 • Data bits: • Parity: None • Stop bits: •...

  • Page 23: A Configuring Serial 1 Operation

    Configuring Serial 1 Operation The Serial 1 interface on manager can be used for a PPP, manager serial API, manager CLI, or Linux shell connection. Refer to the SmartMesh IA-510 Manager Serial API Guide for information on how to log in to these processes. This appendix provides instructions for configuring the Serial 1 interface using the Admin Toolset utility on manager or Linux commands.
  • Page 24 A - C Configuring the Serial 1 Interface PPENDIX ONFIGURING ERIAL PERATION secure). D Enter “system” as the username and the password. E Click the Interfaces link. F In the area, change the serial port settings (if Interfaces: Serial Port Settings necessary).

  • Page 25: Using Linux Commands To Configure Serial 1

    Configuring the Serial 1 Interface A - C PPENDIX ONFIGURING ERIAL PERATION Using Linux Commands to Configure Serial 1 To configure Serial 1 for PPP using Linux: A Connect your computer serial port to the serial 2 port on the manager. Connect your computer to the LAN if the manager is installed on the LAN.
  • Page 26 A - C Configuring the Serial 1 Interface PPENDIX ONFIGURING ERIAL PERATION IA-510 D2511 M MART ANAGER UIDE...
  • Page 27 Assembling a 9-pin D-SUB Adapter for Serial 1 If you are connecting the Serial 1 interface on manager to a 9-pin D-SUB RS232 port on a PC or control device, you need to use an RJ45 to 9-pin D-SUB RS232 adapter (see Figure 8).

  • Page 28: B Assembling A 9-Pin D-Sub Adapter For Serial

    B - A D-SUB A PPENDIX SSEMBLING A DAPTER FOR ERIAL IA-510 D2511 M MART ANAGER UIDE...

  • Page 29: C Restoring Manager Factory Default Settings

    Restoring Manager Factory Default Settings Use the following procedure if you need to restore the factory default settings to the manager. The following factory default settings are restored: • IP address • PPP settings • Serial port settings • User name and password •...
  • Page 30 C - R PPENDIX ESTORING ANAGER ACTORY EFAULT ETTINGS B To view the default settings, follow these steps to log onto the Admin Toolset utility on the manager: Open Internet Explorer Firefox In the browser’s address box, enter the default manager IP address, 192.168.99.100.
