Summary of Contents for Auricsound A7
- Page 1 User Guide...
-
Page 2: Table Of Contents
Contents Contents RISK OF ELECTRIC SHOCK Dimensions DO NOT OPEN Front panel layout CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT Back panel layout REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. Operating environment REFER TO QUALIFIED AUTHORIZED SERVICE PERSONNEL FOR SERVICING. -
Page 3: Dimensions
Specifications Dimensions • 193mm • 150 watt per channel RMS at 4 ohm • 80 watt per channel RMS at 8 ohm • Frequency response : 5Hz ~ 120KHz(-3dB) • S/N Ratio : > 85db • Total harmonic distortion : <0.05%( 20KHz / 8ohm) •... -
Page 4: Front Panel Layout
Front panel layout 5 - Volume status LED The Volume status LED can be set to either high or low from minimum 00 to maximum 99, by rotating the Knob, and Show the L1 or L2 Audio input status LED. When press once the Konb and flash LED in so i t is in a Volume Mute status. -
Page 5: Back Panel Layout
Back panel layout 5 - DC Power socket The supplied power adaptor is connected to this socket and to a power outlet in order device. 6 - USB jack The USB interface to provide wireless subwoofer dongle power and upgarde service only 7 - Right speaker output terminals The right speakers for audio output can be connected to these terminals 8 - Left speaker output terminals... -
Page 6: Operating Environment
Operating environment Connecting and wiring XLR 4pin XLR 4pin Balanced Balanced Audio Input Audio Output the following conditions occur: • Direct exposure to sunlight • High dust volume environments • Places where mechanical vibrations may occur • On an unstable surface •... -
Page 7: Remote Controller
Remote Controller AP Index A7 RM-1 Remote Mute L1 Audio Input L2 Audio Input Volume control P.S. Please install the battery inside before using the remote controller. Battery model “CR2025 Lithium Battery”...
