  • Page 1 Built-in Filtered Water Dispenser INSTALLATION, CARE & USER MANUAL...

  • Page 3: Table Of Contents

    10. Wiring Diagram ......17 (630) 574-8484 Elkay Manufacturing Company 1000005232 (Rev. A - 04/19)

  • Page 4: General Information

    This manual contains step-by-step installation, adjustment, and maintenance instructions for the Built-in Water Dispenser. Followed carefully, these instructions will result in an easy, trouble-free installation of this Elkay Manufacturing Company (Elkay) product. Additional use and care documents can be found on the Elkay website at http://www.elkay.com/support.

  • Page 5: Models Covered In Manual

    1.6 Models Covered in Manual 1.8 Warranty This product is covered by a Limited Warranty and Elkay LBWD00XXC will not be held responsible for damage of any kind in LBWD06XXK connection with the installation of the product. 1.7 Radio Frequency Compliance Refer to the Elkay website http://www.elkay.com/warranty...

  • Page 6: Safety

    If a tool, installation procedure, or work power tools. method that is not specifically recommended by Elkay is Always wear ear protection, such as used, you must be satisfied that it is safe for yourself and earmuffs or earplugs, when using power others.

  • Page 7: Property Damage

    2.4 Property Damage NOTICE Inspect Before Cutting Make sure no electrical wiring or plumbing is present before cutting into a wall. (630) 574-8484 Elkay Manufacturing Company 1000005232 (Rev. A - 04/19) Built-in Filtered Water Dispenser...

  • Page 8: Installation

    Additional 3/4 inch drain hose if the installation requires — Filter Unit a longer drain hose than the supplied 13-inch long hose. C) 6-5/8" (169 mm) high. D) 2-3/8" (61 mm) deep. Elkay Manufacturing Company (630) 574-8484 Built-in Filtered Water Dispenser 1000005232 (Rev. A - 04/19)

  • Page 9: Mounting Height Dimensions

    If the electrical connection is placed under the unit, a user-supplied removable wall cover will be required to access the junction box. (630) 574-8484 Elkay Manufacturing Company 1000005232 (Rev. A - 04/19) Built-in Filtered Water Dispenser...

  • Page 10: Installing The Filter Box

    1. If the filter unit is being installed in the wall opening under the water dispenser, replace the front cover of the water dispenser to help locate and align the filter box under the water dispenser. Elkay Manufacturing Company (630) 574-8484 Built-in Filtered Water Dispenser 1000005232 (Rev. A - 04/19)

  • Page 11: Connecting The Water Lines

    3. Replace the filter unit cover and check the gap between the two covers. Adjust the filter box to create an even gap all the way across the units. (630) 574-8484 Elkay Manufacturing Company 1000005232 (Rev. A - 04/19) Built-in Filtered Water Dispenser...

  • Page 12: Connecting The Optional Catch Basin Drain

    Note: Elkay also recommends installing a shutoff valve at the source of the water supply for the water b. If the filter is installed in a remote location, attach dispenser. an installer supplied length of 1/4 inch tubing to the 1/4 inch tubing from the water dispenser using a 3.
  • Page 13 6. Install the O-ring over the strainer threads. Note: Do not use a 1-1/8 inch hole saw as this will make the opening too large. (630) 574-8484 Elkay Manufacturing Company 1000005232 (Rev. A - 04/19) Built-in Filtered Water Dispenser...

  • Page 14: Remote Filter Location

    The drain adapter is designed to be glued into a 1-1/4 inch PVC pipe. Elkay Manufacturing Company (630) 574-8484 Built-in Filtered Water Dispenser 1000005232 (Rev. A - 04/19)

  • Page 15: Remote Water Chiller

    This temperature can vary greatly depending on the location of the incoming water line. (630) 574-8484 Elkay Manufacturing Company 1000005232 (Rev. A - 04/19) Built-in Filtered Water Dispenser...

  • Page 16: Cleaning

    5. If there are no leaks and the unit is functioning For care of the outside surfaces of the water dispenser correctly, install the water dispenser cover and then refer to the Elkay website http://www.elkay.com/ install the filter box cover using the flathead screws drinking-products-care and a 3/32 inch Allen wrench.
  • Page 17 6. Twist the filter counterclockwise until it is disengaged. Remove the filter and quickly hold it upright. 11. Restore power to the unit at the circuit breaker. (630) 574-8484 Elkay Manufacturing Company 1000005232 (Rev. A - 04/19) Built-in Filtered Water Dispenser...

  • Page 18: Troubleshooting

    Blinking red and blue light. Filter wire disconnected. Check filter cable connections. 9. Frequently Asked Questions (FAQ) For FAQ questions refer to the Elkay website elkay.com/ezh2o-liv Elkay Manufacturing Company (630) 574-8484 Built-in Filtered Water Dispenser 1000005232 (Rev. A - 04/19)

  • Page 19: Wiring Diagram

    RS232 comm NFC filter board Extension cable for NFC board: Electrical Line IN Can be 18 inches for local use  OR 18 ft for remote use.  (630) 574-8484 Elkay Manufacturing Company 1000005232 (Rev. A - 04/19) Built-in Filtered Water Dispenser...
