EVEREST™ Network Solutions
INSTALLATION GUIDE
AP1004WRi Wireless
Access Point
Model Number: AP24I612

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP1004WRi and is the answer not in the manual?

Questions and answers

Summary of Contents for Everest AP1004WRi

  • Page 1 EVEREST™ Network Solutions INSTALLATION GUIDE AP1004WRi Wireless Access Point Model Number: AP24I612...
  • Page 2 Release Number: 1.4...
  • Page 3: Table Of Contents

    Table of Contents C h a p t er 1 : O v e r v i e w ......................1 D e p e n de n cie s ..........................1 AP 1 0 0 4WR i Package Conte n ts ....................1 A d di ti o na l Item ..........................
  • Page 4 The installation of the power switch must be performed by a certified technician. The power switch is not supplied with the AP1004WRi Wireless Access Point. The power cord must be assembled by a certified technician, and the final assembly must comply with related requirements.
  • Page 5: Chapter 1 : Overview

    Chapter 1 : Overview This document provides information and procedures required to install and configure the AP1004WRi Wireless Access Point (model number AP14E612) into a WLAN installation and is intended for certified system installers, system administrators, and network operators. The WLAN system is designed for high density deployments. It comprises of the following main components: •...
  • Page 6: Item Identification

    Item Identification The following figures show top and bottom view of the AP1004WRi Wireless Access Point. Figure 1: AP1004WRi Wireless Access Point - Top View Figure 2: AP1004WRi Wireless Access Point - Bottom View Related Documentation • AP1004WRe Installation Guide •...
  • Page 7: Chapter 2 : Installing Ap1004Wri

    Tembo Systems, Inc. and the third-party installer. AP1004WRi Wireless Access Point has two sets of mounting holes at the bottom of the chassis for attaching third-party mounting systems: • The inner set of mounting holes are 75 mm apart in both the horizontal and vertical directions and are tapped with a M4 x 0.7 mm thread pattern to a depth of 10 mm.
  • Page 8 M6 x 1.0 mm thread pattern to a depth of 10 mm. Third-party systems must be capable of safely supporting the AP1004WRi Wireless Access Point. The exposed screw length (exclusive of mounting bracket thickness and any washers or locking devices) cannot exceed 10 mm so as to avoid any damage to the chassis.
  • Page 9: Connecting Ap 1004Wri

    Perform this procedure to connect the AP1004WRi Wireless Access Point to the network. 1. For Access Points powered from a Network Switch with PoE+ capabilities, Attach the two cables directly to the Eth0 and ETH1 RJ45 receptacle on the back side of the AP1004WRi Wireless Access Point chassis.
  • Page 10: Chapter 3 : Configuring Ap1004Wri

    Protocol. 2. Connect the AP1004WRi Access Point to a POE+ source. Once powered up, the AP1004WRi Access Point requests an IP address from the DHCP server. This process may take up to 90 seconds. 3. Verify if the AP1004WRi was assigned an IP address by doing one of the following: •...
  • Page 11 AP1004WRi, the Access Controller verifies the country code of the AP1004WRi before allowing it to join the network. • If the country code registered in the non-volatile memory of the AP1004WRi and the country code locked into the Access Controller software match, the AP1004WRi is allowed to join the network.
  • Page 12: Configuring Ap1004Wri To Work With Discovery Protocol

    AP1004WRi, if PoE+ power is interrupted. Even a single port losing PoE+ power may result in an overload on the port. 1. In the BaseCamp Access Point menu, set the Passive POE selection to flag the AP1004WRi Wireless Access Point to ignore the POE+ status.
  • Page 13: Chapter 4 : Ap1004Wri Coverage

    Chapter 4 : AP1004WRi Coverage This section provides information on deployment options for optimal coverage from the AP1004WRi Wireless Access Point. AP1004WRi Radiation Pattern The AP1004WRi has a patented, fully-integrated, software-adjustable antenna system with following characteristics: band-optimized, tightly- controlled radiation patterns, polarization and pattern diversity, as well as beam angle and shape configurability.
  • Page 14 The following figure shows fixed and reconfigurable coverage options for AP1004WRi. Figure 5: AP1004WRi Coverage Options Page | 10 AP1004WRe Installation Guide...
  • Page 15: Regulatory Declarations

    The 802.11bgn/Scanning WiFi Radio Module/FCCID:2AGMRTRM989DB and 802.11ac WiFi Radio Module/ FCCID:2AGMRTRM9995G are intended for OEM integrator only and are certified to be compliant when installed into, but not limited to, an end product with model name, AP1004WRi and model number, AP24I612.
  • Page 16 The OEM integrator is still responsible for the FCC compliance requirement of the end product, which integrates these modules. Important Note: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator &...
  • Page 17 IC Statement: This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
  • Page 18 Modules 802.11bgn/Scanning WiFi Radio Module/IC:21218-TRM989DB and 802.11ac WiFi Radio Module/IC:21218-TRM9995G are intended for OEM integrator only and are certified to be compliant when installed into, but not limited to, an end product with model name, AP1004WRi and model number, AP14E612.
  • Page 19 Japan Statement: 5GHz band (W52 & W53): Indoor only “ 電波法により 5.15-5.35 GHz 帯は屋内使用に限ります ” (5GHz band 5.15-5.35 GHz, indoor use only.) VCCI Statement: Page | 15 AP1004WRe Installation Guide...
  • Page 20: Appendix: Technical Specifications

    Appendix: Technical Specifications This section provides technical specifications of the AP1004WRi Wireless Access Point. Mechanical Specifications The following table provides mechanical specifications of the AP1004WRi Wireless Access Point. Table 1: Mechanical Specifications Height Width Depth Weight 261 mm 261 mm 84 mm 3.4 kg...
  • Page 21 Some frequency bands may not be operational in power limited operations. Page | 17 AP1004WRe Installation Guide...
  • Page 22: Environmental Requirements

    Environmental Requirements The following table provides environmental requirements of the AP1004WRi Wireless Access Point. Table 3: Environmental Requirements Condition Requirement Operating Temperature 0 °C to 45 °C (32 °F to 113°F) Storage temperature -40 °C to 85 °C (-40 °F to 185 °F)
  • Page 23 © Copyright 2015 - 2018 by Tembo Systems, Inc., USA. All Rights Reserved. Statement of Conditions In the interest of improving internal design, operation function, and/or reliability, Tembo Systems, Inc. reserves the right to make changes to products described in this document without notice. Tembo Systems, Inc. does not assume any liability that may occur due to the use or application of the product(s) described herein. DOC-000023-000 Document Number: Revision: May 2018 Date: Page | 19 AP1004WRe Installation Guide...
