Summary of Contents for Encore ENNPOE-I
- Page 1 Gigabit PoE Injector...
- Page 2 Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein. All trademarks and brand names are the properties of their respective holders. © 2013 Encore Electronics, Inc. All rights reserved. ENNPOE-I...
- Page 3 Encore’s ENNPOE-I PoE Injector is a single-port Power-over-Ethernet (PoE) injector device. The ENNPOE-I is designed for 10/100/1000 Mbps Ethernet network and supply power using a single Ethernet cable. This equipment injects DC power and stream network data using CAT5, CAT5e and CAT6 Ethernet cable to any PoE compliant devices, increasing flexibility in using a PoE enabled device to a non-PoE Ethernet switch.
- Page 4 Encore PoE Injector Connection Diagram Connect the ENNPOE-I PoE Injector as seen in the diagram below. A PoE compliant power device VOIP phone in this example is added to an existing non-PoE network with a non-PoE Ethernet switch. AC 100-240V power outlet Non-PoE Compliant Switch To “Data”...
