SSPT724A Timer Quick Start Guide
Open timer enclosure and remove mounting parts and instructions.
When ready to program the timer, plug in timer to 120 Volt Ac power receptacle
Press the SET button to reach the "Press Enter to Set Time" then press Enter
Pressing Enter begins the curser scrolling the positions available for entry.
Set the Date and the current time—NOTE: All times need to be expressed in
Military 24 hour time (i.e. 3PM is 15:00)
Press the Set button to reach the "Press Enter to Set BK (Block)" then press Enter
Pressing Enter begins the curser scrolling the positions available for entry.
Set the Block for the days of the week you need the timer to sound the horn (i.e.
Monday and Friday for Monday through Friday—make sure your first day begins
your week and follows to the end of your week—do not set the Block for Saturday
and Sunday for instance because that is ONLY Saturday and Sunday. A full 7 days
should be Monday and (through) Sunday. Time=DS simply allows for Daylights
saving time adjustment and can be left at DS if desired.
Press the Set button to reach the "Press Enter to Set Evnt (Event)" then press Enter
Pressing Enter begins the curser scrolling the positions available for entry.
Event numbers begin at 01 and move up during subsequent event programming.
The entry position to the right of the ^ MUST be set for PL (pulse) for all events
you set.
The position further to the right is the duration the horn will sound—you can set
this from 1 to 15 seconds.
The next position is the Day of the week—this MUST be SET for BK to refer the
timer back to the Block of days you set above.
And finally the time for the event, Must be set in Military time as necessary. (i.e.
Lunch at 1:30 PM should be set in Military time as 13:30)
Continue this process to set all of your time events.
When finished press SET or leave the timer alone and it will return to the main screen.
The screen reports the current status of the RELAY and generally it will always say Relay
OFF until the vent time is reached and the Relay changes for that short period of time (1
to 15 seconds depending on your event setting).
Once programming is complete, your Electrical Professional can connect the horns, etc.
using acceptable practices as per the NEC.
Advertisement
Table of Contents
Summary of Contents for SignalGuys SSPT724A
- Page 1 SSPT724A Timer Quick Start Guide Open timer enclosure and remove mounting parts and instructions. When ready to program the timer, plug in timer to 120 Volt Ac power receptacle Press the SET button to reach the “Press Enter to Set Time” then press Enter Pressing Enter begins the curser scrolling the positions available for entry.
- Page 2 Overview: The SignalGuys.com Start/Stop Work Timer SSPT724A is an extremely versatile 24 Hour 365 Day Event Timers designed to support a wide range of applications. Such applications include: Start/Stop Work Time, Home and Building Automation, Security, Lighting Control, Etc. The PT724A timer board is equipped with an independently controlled form “C” relay contact that provides many latching and/or momentary operations during a program schedule of your choice.
- Page 3 The four (4) output relay modes consist of: Relay OFF - De-energizes the relay until a relay ON event is detected Relay ON - Energizes the relay until a relay OFF event is detected. Disable - Used to cancel an existing programmed event. **Start/Stop Work Applications*** PULSE - Momentarily energizes the relay for a selectable time period of 1 sec.
- Page 4 Programming Instructions: A. Setting Clock/Calendar: Upon initial power up RLY OFF will appear in display. SU 01:01 Depress SET ENTER to will appear in display. SET TIME Depress ENTER 01/01/01 will appear in display. SU/01:01 Enter the current date, day of week and time (military) by depressing UP and DWN to make the selection then depress ENTER to accept.
- Page 5 C. Setting Block Events (weekly repeat): Depress SET until ENTER to SET BK Depress ENTER BK=SA/SU TIME=DS Flashing cursor will appear at the location of the first day of the week desired. Depress UP and DWN to select day. Depress ENTER to confirm selection, then cursor will appear at the location of the last day of the week desired.
- Page 6 G. Delete All Events: All previously programmed events can be deleted by depressing SET until ENTER to CLR MEM Depress ENTER CLEAR MEMORY? Depress ENTER PRESS UP & ACCEPT Depressing UP push button will now clear all events previously programmed. If you wish to escape from this selection depress any of the other push buttons: SET, ENTER and DWN.
