Storpia M7 User Manual

Mobile ssd drive
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Mobile SSD Drive
Storpia M7 User Guide
(firmware ver.2.1)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Storpia M7

  • Page 1 Mobile SSD Drive Storpia M7 User Guide (firmware ver.2.1)

  • Page 2: Fcc Caution

    Mobile SSD Drive, Storpia M7 User Guide For a Class B digital device or peripheral, the instructions furnished the user shall include the following or similar statement, placed in a prominent location in the text of the manual: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 3: Chapter 1. Product Information

    Mobile SSD Drive, Storpia M7 User Guide Chapter 1. Product Information Storpia M7 PACKAGE USB3.0 Cable Micro 5pin cable Network Cable Quick Guide for PC connection for charging DEVICE FEATURES...
  • Page 4 Mobile SSD Drive, Storpia M7 User Guide BUTTON & LED LIGHTS Button Description Push the power button for 3 seconds by using pin till Power LED blinks to indicate set initialization. The device reboots when set initialization Reset is done.

  • Page 5: Specification

    Mobile SSD Drive, Storpia M7 User Guide SPECIFICATION ITEM Description 1XWireless 802.11 b/g/n 2.4G Radio / 2T2R Wireless Network 1.5dB Hidden antenna 300Mbps transfer rate Security-auto WPS, WEP and WPA-PSK 1XMicro USB3.0B type 1XUSB 2.0 Host Interface 1XSD card 1XMicro SD card...

  • Page 6: Supported Formats

    Connect the other end of the cable to the power adapter or the USB port in your PC or Laptop. ② On the top left, Battery Charging LED light will turn BLUE and charging has begun. ③ Storpia M7 charging is complete when Battery Charging Complete LED light turns GREEN. ④...
  • Page 7 ② Wireless connection to Storpia M7 is possible while being used as a Power Bank for mobile. ③ Output provided is 500mA while Storpia M7 is in use, and up to 1.5A when Storpia M7’s power is off. ④ CAUTIONS You should regularly backup of your data to avoid data loss.

  • Page 8: Chapter 2. Using The Mobile Application

    Chapter 2. Using the Mobile Application RUNNING MOBILE APPLICATION Installing the Mobile Application is required to run Storpia on a mobile device. Install Storpia on form the Google Play Store or from the Apple App Store. Now, you will find Storpia app on your mobile device.
  • Page 9 You can use data when you modify the application setting information or by accessing My Device/Download. You should change your ID and password for security protection. If your mobile device is not connected to the Storpia M7 Wi-Fi properly, you will not be able to see the Storpia...
  • Page 10 <Storpia M7 is not connected to Wi-Fi> <Storpia M7 is connected to Wi-Fi> When your mobile device is not connected to Storpia M7 Wi-Fi, and you want to navigate to the Storpia M7 tab, Wi-Fi Setting it will show warning message. It will redirect you to the Wi-Fi setting page if you click the button.

  • Page 11: Play Files

    ① The slide menu appears when you slide the ② You can access storage devices which are mobile app from left to right. You can choose attached to Storpia M7 by selecting Storpia. You the menu you want. can choose the desired device from the list.
  • Page 12 ④ You can set View mode from the <App Settings>- <Basic Settings> menu. Audio Play Product Information Storpia M7 provides a dedicated music player for playing music. Please refer to >...
  • Page 13 Mobile SSD Drive, Storpia M7 User Guide Supported Formats section to check list of supported formats. ① Select the music file which you want to play and it Menu will start playing. Or Click the icon from file Playlist list then select the icon to add the music file to the playlist.
  • Page 14 Delete button will pop up on the right side. Then Delete click button. * (Android) Music files stored on your Storpia M7 device will have the icon, Music files stored in mobile device will have the icon. * If you want to delete files from the playlist, click the icon.
  • Page 15 Using Video Player app Storpia M7 doesn’t provide a specific Video Player. Play video with video players that are installed on your mobile device. For subtitles, a free application, Dice Player, on the Samba Server is provided for Android devices. But a pay application, AVPlayer or Nplayer on the WebDAV Server is provided for iOS devices.
  • Page 16 Mobile SSD Drive, Storpia M7 User Guide WebDAV server Now, Storpia M7 is added to ⑥ Click Storpia M7 that is added to WebDAV server list. It ⑦ should be connected to the Storpia M7 Wi-Fi. You can check the Storpia M7 directory.

  • Page 17: File Transfer

    Mobile SSD Drive, Storpia M7 User Guide FILE TRANSFER Upload Photos and Videos Storpia You can upload photos and videos from your mobile device to your Storpia M7 device. Select from slide menu. ① Navigate to the target folder where you want to upload files.
  • Page 18 Auto Upload (iOS) Disk provides an <Auto Upload> feature to upload photos and videos from your mobile device to your Storpia M7 device automatically. To do this, you have to activate the <Auto Upload> function on your Storpia M7.
  • Page 19 Auto Upload ② Set up Auto Upload path. It is recommended to choose a hard disk folder on Storpia M7 rather than to choose one from an SD card or a USB memory. ③ Activate Auto Upload when all settings are complete.
  • Page 20 ⑤ Activate Auto Upload when all settings are complete. Auto Upload will start in according to your settings. File/Folder Download ① You can download files from your Storpia M7 Storpia device to your mobile device. Select from slide menu.
  • Page 21 Mobile SSD Drive, Storpia M7 User Guide Menu ② Click the icon located next to the file/folder you want to download. Download ③ Click the icon to download file/folder. ④ If you want to download 2 or more files/folders, Select click the icon located at the top.
  • Page 22 Mobile SSD Drive, Storpia M7 User Guide Up/Download Manager Upload/Download You can check the file transfer status from the section of the slide menu. ① You can check status of the file transfer or stop and resume the file transfer.

  • Page 23: File Management

    Move list and select the option. Done ② Select the destination folder and click button. ③ Moving a file is possible only between your Storpia M7 device and a Mobile device. Create New Folder Action Create folder ① Click the icon and select button.
  • Page 24 Mobile SSD Drive, Storpia M7 User Guide ② Enter the new folder name and click the button. ③ In case of Android version 4.4+ (kitket) users, you can’t create the file/folder from external SD card due to Android security policy.
  • Page 25 BACKUP Smart Backup Storpia M7 provides "Smart BackUp" so that you can backup automatically on the Storpia M7 SSD drive as well as an SD card, Micro SD card or USB. If you have 'Auto Backup' turned on, backup happens automatically once you connect a portable storage device to Storpia M7.
  • Page 26 Mobile SSD Drive, Storpia M7 User Guide After the Smart Backup set up is completed. ⑥ Auto Backup will be carried out once the backup ⑦ setting is completed. Backup happens automatically once you connect the corresponding memory to M7.
  • Page 27 Mobile SSD Drive, Storpia M7 User Guide backup will be done in that order. When backing up, you can cancel the backup ⑥ process. When on 'standby', you can cancel 'standby'. You can check backup status through icons. Remove Backup Setting [Method 1] Select 'Remove Backup' on the folder ①...

  • Page 28: Chapter 3. Use With A Pc/Laptop

    Chapter 3. Use with a PC/Laptop Your Storpia M7 device can be used as an external storage device not only with a mobile device but also with PC or Laptop. You can use Storpia M7 as an external Hard disk or an SD reader while connecting to a PC. You can use stored data such as Samba, FTP and WebDav when you connect a wire/wireless network, not a USB.

  • Page 29: Connect To Wireless Network

    Mobile SSD Drive, Storpia M7 User Guide CONNECT TO WIRELESS NETWORK You can use M7 as well as SAMBA, FTP and WebDAV when you connect M7 wired/wireless. You should know the M7 IP address to be able to do this.
  • Page 30 ① Select on the left slide. Then select Internet Connection ② Select Wi-Fi signal to connect Storpia M7. ③ Wi-Fi can be disconnected when Storpia M7 reboots. Reconnect Storpia M7 Wi-Fi. ④ Make sure the internet is connected normally from Internet Connection section.

  • Page 31: Connect To Wired Network

    Connect Storpia M7 to a wired/wireless router, cable modem or xDSL modem using a network cable. Checking IP address of Storpia M7 You can check the IP address of M7, if you connect a router to the WAN port on the back of M7. You should check the IP address of M7 when you connect M7 to a wired network in contrast to a wireless network connection that has a fixed IP <10.10.10.254>.
  • Page 32 Mobile SSD Drive, Storpia M7 User Guide Storpia Settings Information ② Select > menu from the slide menu. Network ③ Check the IP address from a Section.
  • Page 33 Mobile SSD Drive, Storpia M7 User Guide SAMBA(Network Drive) You can use data on Window Explorer(Windows) or Finder(Mac) by using Samba Protocol on wired/wireless connected M7. Windows [Method 1] Enter IP address in Search the web and ① Windows box. When connecting to the internet wirelessly, the IP address is it becomes <10.10.10.254>.
  • Page 34 Mobile SSD Drive, Storpia M7 User Guide The Storpia M7 directories will be available as shown above. Each partition will be listed as sda 1, sda2 or ④ partitions name. Command + K Press which will open the Connect to ①...
  • Page 35 Mobile SSD Drive, Storpia M7 User Guide You will be able to see your Storpia M7 device’s folders when it is connected properly. Also, you will ③ be able to see details of the files/folders on the right panel.
  • Page 36 Mobile SSD Drive, Storpia M7 User Guide FTP is a standard file transfer protocol over the internet. By enabling this feature, you can transfer files/folders from/to your Storpia M7 device using FTP protocol. This guide's explanation is based on the FTP program called 'Filezilla'.
  • Page 37 WebDAV doesn't support uploading files but it's only available to download files. When you see that M7 is connected through WebDAV, you can download files in any folder. (Uploading is not provided on WebDAV). Refer to <Chapter 3. Use with a PC/Laptop> - <Connect to Wired Network> section of this manual.
  • Page 38 Mobile SSD Drive, Storpia M7 User Guide ACCESSING THE ADMIN SETTING Storpia M7 enables a Desktop or Laptop to access the network as well as a mobile device. Storpia M7’s Admin Setting page provides basic settings and a BitTorrent Transmission Function.
  • Page 39 Transmission icons on the main page or through the website. ※ Downloads from "Transmission" are stored in <Storpia_Down> folder on the equipped SSD. ※ You don't need new settings for M7 with a wired connection but new internet settings are required when connecting wirelessly.
  • Page 40 Mobile SSD Drive, Storpia M7 User Guide You click the 'file selector' button and register ③ Torrent files that are already stored in your PC, You can also type the Magnet URL. (Except for tablets, you can only type Magnet URL on the mobile application.)

  • Page 41: Chapter 4. Environment Settings

    This manual explains options based on Android environment. Auto Upload Photos and videos captured from your mobile device can be uploaded automatically to your Storpia ① Please refer to chapter 2. <Auto Upload> section of this manual for more details.
  • Page 42 Storpia M7 Setting Select the option from slide menu. If you want to set the Storpia M7 environment from the Web instead of the Mobile App, please refer to <Chapter 3. Use with a PC/Laptop> - <Accessing the Admin setting> section of this manual. .
  • Page 43 Wi-Fi password. Password must contain 8~63 alphanumeric characters. If you don’t want to allow others to access to your Storpia M7, you should set minimum security in Storpia M7 Wi-Fi. We recommended you to use Wi-Fi security to protect your private data.
  • Page 44 It may take approximately 1 minute to restore your system’s settings. 2) Reset Settings You can reset all settings of your Storpia M7 device. When you reset, it will delete all system settings made by the user but will not delete any data from the HDD or any storage device.
  • Page 45 Mobile SSD Drive, Storpia M7 User Guide Storpia M7’s battery must be at least 50% charged to prevent power shut off during the upgrade. System ① Select on the main screen, then select Firmware upgrade Upload ② Click , and choose the firmware file(.trx) that was downloaded on your PC.
