- Page 1 Smart Switch Model: PC069 www.axaet.com Notice: Please be sure to read user manual carefully before installation. The manufacturer is not responsible for any product damage cau sed by irregular operation not in accordance with instructions.
-
Page 2: Special Notice
Special Notice: 1. Installation when powered on is prohibited. Be sure to wire stri ctly according to wiring sketch map. 2. The total load of the switch should be below 1000W. 3. The junction box is "86" standard type. 4. If the first touching test is done when the glass panel was take n down, please power off first after the test. -
Page 3: Installation Diagram
Installation diagram Open the screwdriver follows the instructions to wire and tighten the screws Use two screws to fix Cover the glass panel, power on... - Page 4 Switch wiring diagram...
- Page 5 Mobile APP download installation instructions Scan QR code to download Android...
- Page 6 AHomeMain Interface Function Introduction...
- Page 7 Switch connection instructions Use the Bluetooth version of the switch, need to bind the device connection switch. Bind the device steps: Step 1: Open the Bluetooth function on your phone, log in to AHome, select "Bluetooth Mode", click the "Add Device" button on the interface to enter the binding device interface.
- Page 8 Note: When searching for a device connection switch, the distance should not exceed 1 meter. Only up to two mobile phone binding devices, when third-party mobile phone wants to bind, bound mobile phone must be unbinded.
- Page 9 Switch control instructions...
-
Page 10: Switch Control
Switch Control Click “Device Image” or the name area to control on/off of the device. Timing Control After setting the timing group, the device will be switched on/switched off at fixed time under offline and online condition. - Page 11 Voice Control Voice control, through set the switch name, the name of each switch and the keyword, can call the switch on / off. Overall Control Auto Control On the control interface, you can make One-Key Control or set Two-Way Three-Way switch device. Auto Control(Limited to Bluetooth device only) Open Auto Control function, the device will be on automatically when connected, and when disconnected the device will be off...
- Page 12 Rotation control (Limited to Bluetooth device only) Turn on the rotation control function, return to the main page, turn the phone to the horizontal screen, and then turn it to the vertical screen will turn off all the switch Size Size：86mm*86mm*33mm...
- Page 13 FCC statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 14 and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
