Summary of Contents for Santos 34-1
- Page 1 COLD DRINKS DISPENSER No. 34 USER AND MAINTENANCE MANUAL IMPORTANT: documents included in this manual to be kept: • “CE” COMPLIANCE DECLARATION • WARRANTY CERTIFICATE *408.071 - *408.072 - *408.072 Model no 34 1/15 408071-72-73 en ma 2010.12...
-
Page 2: Table Of Contents
Electrical wiring diagram 110-120V 50/60Hz ..............11 Electrical wiring diagram 220-240V 50Hz ..............12 Electrical wiring diagram 220-240V 60Hz ..............13 Figures ...........................14 WARRANTY CERTIFICATE....................15 APPLIANCE IDENTIFICATION PLATE................15 98134 EN 2.2 - 12 2010 2 / 15 www.santos.fr 2/15 408071-72-73 en ma 2010.12... -
Page 3: Ec" Compliance Declaration
Description: COLD DRINKS DISPENSER Type number: 34-1, 34-2, 34-3 complies with: the statutory provisions defined in appendix 1 of the European "machines" directive n°2006/42/CE and the national legislation transposing it the statutory provisions of the following European directives and regulations: o N°... -
Page 4: Safety Rules
9. Unplug the appliance before carrying out any work on it: cleaning, upkeep and maintenance. 10. The use of spare parts other than certified SANTOS original parts is prohibited. INSTALLATION. Install the appliance on a counter which can take the weight of the appliance with the container full. -
Page 5: Electrical Connection
2002/96/CE (WEEE) – Professional Equipment section – so that it can be either recycled or disassembled in order to reduce any impact on the environment. For further information, please contact your dealer or SANTOS. For the elimination or recycling of the appliance components, please contact a specialist company or contact SANTOS Electronic products which have not been out-sorted are potentially dangerous for the environment. -
Page 6: Appliance Description
The temperature of the drink is controlled by factory-set thermostats. Changing that setting is not advised. In normal operation, warm air should be released from the front or back panel. 98134 EN 2.2 - 12 2010 6 / 15 www.santos.fr 6/15 408071-72-73 en ma 2010.12... -
Page 7: Cleaning
To facilitate insertion of the seal, moisten the evaporator dome (4). Or start up the appliance and wait until frost appears on the evaporator before pushing the container and seal down Position the paddle (3) 98134 EN 2.2 - 12 2010 7 / 15 www.santos.fr 7/15 408071-72-73 en ma 2010.12... -
Page 8: Maintenance
To access the condenser: unplug the appliance and unscrew the side panels (9). Spare parts: IMPORTANT: The use of spare parts other than certified SANTOS original spare parts is prohibited Apart from the monthly maintenance, this machine requires no specific maintenance. -
Page 9: Fault Finding
Draining and filling the condensing unit is absolutely prohibited in any place not equipped to collect such gasses. Do not use anything other than R134A 98134 EN 2.2 - 12 2010 9 / 15 www.santos.fr 9/15 408071-72-73 en ma 2010.12... -
Page 10: Appliance Technical Specifications
APPLIANCE TECHNICAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS (1) Model no. 34 34-1 (1 bowl) 34.2 (2 bowls) 34-3 (3 bowls) type Power supply voltage 100-120 220-240 220-240 100-120 220-240 220-240 100-120 220-240 220-240 Frequency (Hz) 50/60 50/60 50/60 Input power (μF) Capacitor (optional) 53μF... -
Page 11: Electrical Wiring Diagram 110-120V 50/60Hz
Blue Blue Compressor Black Black Thermostat 1 Black ON/OFF 1 Paddle 1 Thermostat 2 Brown ON/OFF 2 Paddle 2 Brown Brown Blue Green / Yellow 98134 EN 2.2 - 12 2010 11 / 15 www.santos.fr 11/15 408071-72-73 en ma 2010.12... -
Page 12: Electrical Wiring Diagram 220-240V 50Hz
Electrical wiring diagram 220-240V 50Hz Green / Yellow Black Brown Black Blue Blue Compressor Black Black Thermostat 1 Black ON/OFF 1 Paddle 1 Thermostat 2 Brown ON/OFF 2 Paddle 2 Brown Brown Blue Black Green / Yellow 12/15 408071-72-73 en ma 2010.12... -
Page 13: Electrical Wiring Diagram 220-240V 60Hz
Black Black Thermostat 1 Black ON/OFF 1 Paddle 1 Thermostat 2 Brown ON/OFF 2 Paddle 2 Brown Brown Blue Yellow or Black Green / Yellow 98134 EN 2.2 - 12 2010 13 / 15 www.santos.fr 13/15 408071-72-73 en ma 2010.12... -
Page 14: Figures
Figures Fig. A REF Description Juice container Paddle Evaporator Pourer spout Distribution nozzle Evaporator seal Paddle switch Side panels Base/casing Lever Thermostat Fig. 98134 EN 2.2 - 12 2010 14 / 15 www.santos.fr 14/15 408071-72-73 en ma 2010.12... -
Page 15: Warranty Certificate
Our guarantee does not extend to the payment of penalties, the repair of direct or indirect damages and notably to any loss of income resulting from the nonconformity or the defectiveness of products, SANTOS's global responsibility being limited to the sale price of the delivered product and to the possible repair of the defective products.
