Bluetooth Keyboard User Manual
WELCOME
Thank you for selecting this product. Your Bluetooth keyboard adopted the latest developed
technology. We hope you'll enjoy using it.
PRODUCT SPECIFICATIONS & FEATURES
1. Product size: 294(L)*148(W)*9(T)mm
2. Unit Weight: 375±10g
3. Number of Keys: 78
4. Protocol:
BLUETOOTH 2.0 USB Interface
5. Operation Range: up to 10meter
6. Battery: 3.7V 500mAH Lithium Polymer battery
7. Working Current:
@ 3.7V DC
2.3—3.6mA (MAX)
8. Operating temperature:
0~60℃
0~ 95% RH
9. Storage temperature:
-20~60℃
0~90% RH
10. Key Operation Force: 65± 20g
11. Key Switch life: 8 million cycles min
12. System Compatible: Windows 98 / Windows ME / Windows 2000 / Windows NT
/ Windows XP / Windows Vista / Windows 7 / Mac OS 10.6
Precautions
This manual include important safety measure and information of using the product
correctly. For avoiding operate incorrectly, please read this manual carefully before
using the product.
1). Do not use the keyboard in the extremely hot, cold, dusty or damp enviroment.
2). Do not drop or hit the keyboard.
3). The service life of battery is subject to the working condition and environment.
4). Please charge the battery in the following instances:
a. The red LED blinks slowly.
b. All Keys and buttons don't function after the keyboard was stayed unused for a
certain period.
About the keyboard
1). Top View
Advertisement
Table of Contents
Summary of Contents for Maxtro MK-8008BT
- Page 1 Bluetooth Keyboard User Manual WELCOME Thank you for selecting this product. Your Bluetooth keyboard adopted the latest developed technology. We hope you’ll enjoy using it. PRODUCT SPECIFICATIONS & FEATURES 1. Product size: 294(L)*148(W)*9(T)mm 2. Unit Weight: 375±10g 3. Number of Keys: 78 4.
- Page 2 2). Front View 3). Side View LED Indicators: 1). LED Blue for Bluetooth Synch Pairing Push the ON-OFF button to ON and press the PAIR button once. The Blue LED will be blinking. It indicates that the Bluetooth keyboard is searching for USB Dongle or other paired device.
- Page 3 The Red LED will blink slowly when the battery is low. In battery charge mode, the Red LED will blink fastly. When the battery was fully charged, the Red LED will light up constantly. The Red LED will go out in 2 minutes after the charging cable was unplugged. Basic Operations a.
- Page 4 Step 4). The Bluetooth keyboard will automatically search for Bluetooth paired device after the PAIR button was pressed.. Input the security code which displays on the dialog box by the Bluetooth keyboard and press Enter. When the Bluetooth Synch LED stop winking, it means the Bluetooth connection was established successfully between the keyboard and the PC or Notebook.
- Page 5 Step 5). It will take a few seconds for the computer to automatically install some drivers once the Bluetooth connection has been established. Upon installation of the drivers, the Bluetooth keyboard is ready to work. As long as the PAIR button was not pressed again or the Paired device was not removed, users no need to make pairing any more after the pairing process was accomplished.
- Page 6 b. Charging Please charge the battery by the accompanied USB charing cable when the Red LED blinks slowly. Plug the standard USB connector to an USB port of PC or notebook and plug the Mini-B USB connector to the 5V DC-IN port of the keyboard. In battery charge mode, the Red LED will blink fastly.
-
Page 7: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
