InterRanger IR-200
Instruction Manual
PL-545
January 1998
33455450
Technology based. Customer driven.
Rev
1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InterRanger IR-200 and is the answer not in the manual?

Questions and answers

Related Manuals for Milltronics InterRanger IR-200

Summary of Contents for Milltronics InterRanger IR-200

  • Page 1 InterRanger IR-200 Instruction Manual PL-545 January 1998 33455450 Technology based. Customer driven.

  • Page 3: Table Of Contents

    Test Mode Security “Lockout” for PGM and TEST Modes Drawings are referenced throughout this manual. All referenced drawings are located at the end of the manual. ALSO CONTAINED IN THIS MANUAL IR-200 Communication Protocol InterRanger Profiling Software PL-545 InterRanger IR-200...
  • Page 4 4-20 mA, scalable to any range, 900 max. load » 4 Programmable relays, rated to 7A @ 250Vac » 1 Alarm relay with panel light Enclosure » Suitable for outdoor (Type 4X / NEMA 4X / IP65 enclosure) InterRanger IR-200 PL-545...

  • Page 5: Equipment

    These components are required to install the InterRanger Sensor correctly. » 3/4” stainless steel or galvanized conduit » 3/4” pipe coupling Optional These components are available from Milltronics: Mounting: » Rail mount for Monitor » Rail mount for Transceiver »...
  • Page 6 Sensor signal enabling it to be transmitted over standard signal cable for up to 225 m (750’). For use with the IRT-100D or IRT-100DC Sensor. Temperature Range -30°C to 50°C (-22°F to 122°F) Drawing: 0-8130007Z-DU-B InterRanger IR-200 PL-545...
  • Page 7 Supplied with either a Kynar or 316 ® stainless steel 3/4” NPT nipple and 7.5 m (25’) of Teflon jacketed cable (optional 22.5 m (75’) available). Temperature Range -30°C to 105°C (-22°F to 221°F) Drawing 0-8140002Z-DU-C PL-545 InterRanger IR-200...
  • Page 8 Anodized Aluminum Plate 2” Hand Rail Description This anodized aluminum plate allows the Transceiver to be mounted on a horizontal or vertical, standard 2” hand rail. Two U-bolts are supplied and all holes are pre-drilled. Drawing: 0-8130008Z-DU-C InterRanger IR-200 PL-545...
  • Page 9 100 series Sensor and Stationary Handrail Bracket. This kit should be used if the tank has a surface skimmer so that the Sensor deflects out of the way when the skimmer moves past it. Drawing 0-8140005Z-DD-C Skimmer PL-545 InterRanger IR-200...

  • Page 10: Storage

    (-4°F to 122°F). The Monitor and Transceiver should be sealed to prevent moisture intrusion in humid areas. MAINTENANCE The only part of the InterRanger IR-200 that requires maintenance is the Sensor face and only when it is subject to algae or scale build-up.

  • Page 11: Principles Of Operation

    This height of this zone can be adjusted by the user to eliminate the strong echoes and help detect the weaker echoes. PL-545 InterRanger IR-200...
  • Page 12 InterRanger IR-200 PL-545...

  • Page 13: Hardware Installation

    The IR-200 provides both RS-232-C and RS-485 communication capability with a DOS-based PC that has 640K of base memory and DOS 4.01 or higher. Up to 40 IR-200’s can be monitored using RS-485 and appropriate wiring. Only one type of communication: RS-232 or RS-485 can be used at a time. PL-545 InterRanger IR-200...

  • Page 14: Ir-200 Monitor

    IR-200 MONITOR The IR-200 Monitor is normally mounted near, or on, the tank that it is tracking, usually with the Milltronics Rail Mount assembly (See drawing 0-8130004Z-DU-C). Ensure that the voltage selector switch inside is set for the power available to the unit and that liquid-tight connectors are used to seal all wires entering the enclosure.

  • Page 15: Quick Start

    After the TANK DEPTH has been set, press the run key. While the unit adjusts transmitter power to the tank conditions, the displays will go blank for a few minutes. This is normal. PL-545 InterRanger IR-200...

  • Page 16: Determining Tank Depth

    In the example we then change the TANK DEPTH to 12 feet (your value is determined by your tank depth and sensor placement). The InterRanger IR-200 now takes the next-largest peak and scales it to 80% of the chart range (Figure 2).
  • Page 17 CYCLES (10 in the example). This would mean that the numeric display would update after 10 minutes if the settings from the example are used (1 minute times 10 cycles). Press the PGM key at any time to return to the PROGRAM mode for further parameter adjustments. PL-545 InterRanger IR-200...
  • Page 18 InterRanger IR-200 PL-545...

  • Page 19: Operation

    There are two display formats available for viewing while in the RUN mode described below. Use the next page and previous page keys to switch between the two graphs. shows the Echo Profile Graph (default at startup). shows the Trend Graph. PL-545 InterRanger IR-200...
  • Page 20 12 or 24 hour period (TREND GRAPH TIME SCALE parameter). This graph gives the operator an overview of how the interface of interest fluctuated over the selected time scale. This information is useful when the tank is inspected on a daily basis. InterRanger IR-200 PL-545...

  • Page 21: Program Mode

    These parameters return to their defaults: » Bottom Dead Zone » Top Dead Zone » Relay Number x Function » Relay Number x “On” Setpoint » Relay Number x “Off” Setpoint PL-545 InterRanger IR-200...
  • Page 22 InterRanger IR-200 PL-545...

  • Page 23: Parameters

    This parameter determines how quickly the Echo Profile Graph is updated. Values: 1 = 7.5 seconds 2 = 15 seconds 3 = 30 seconds 4 = 1 minute (standard) PL-545 InterRanger IR-200...
  • Page 24 ‘averaging’. Use a value of 2, ‘median’, for cases where the tank has bottom rakes but no surface skimmers. These cases can produce numbers in which some of the results are inaccurate. The median method eliminates these numbers from consideration. Values: 1 = Averaging 2 = Median InterRanger IR-200 PL-545...
  • Page 25 To use this parameter, first set the GAIN CONTROL to 0 (automatic). Then, set this parameter to the largest transmit power level desired (1 to 100). The AGC’s maximum range is now limited to this number. Normally this number is set to 100%. Values: 0 to 100% PL-545 InterRanger IR-200...
  • Page 26 0. If this option is used, be aware that a reading of 0 may be due to a fouled Sensor, or a completely upset tank. Values: 0 = display no interfaces 1 = display error (default) InterRanger IR-200 PL-545...
  • Page 27 Set this parameter to 0 to activate the relay for interface levels lower than the setpoint described. Set it to 1 to activate the relay for interface levels higher than the setpoint. Values: 0 = Low Alarm 1 = High Alarm PL-545 InterRanger IR-200...
  • Page 28 RELAY NUMBER x ‘ON’ SETPOINT), it will not turn off until the specified interface level reaches the value set in this parameter. The value is in meters or feet depending on the DISPLAY FORMAT parameter. Values: 0.00 to 30.00 m (0.0 to 100.0’) InterRanger IR-200 PL-545...

  • Page 29: Test Mode

    Press the up and down arrow keys to change the settings for any test while it is running. Press the test key again to return to the test mode so that you can select another test. Press the run key to return to run mode. PL-545 InterRanger IR-200...

  • Page 30: Security "Lockout" For Pgm And Test Modes

    There are four DIP switches on this card. For complete access to the PGM and TEST Modes, the switches must be in the following (factory) setting: Switch Status If these switches are set any other way, only the RUN Mode will function. InterRanger IR-200 PL-545...

  • Page 31: Ir-200 Communication Protocol

    Request Tank Profile Request Relay Configuration Request Trend Data Request Program Parameter Value Change Program Parameter Value Change Mode Program Parameter Numbers MODEL IR-200 ORIGINATED MESSAGES Data Report Tank Profile Relay Configuration Trend Data Program Parameter Report Negative Acknowledge PL-545 InterRanger IR-200...
  • Page 32 InterRanger IR-200 PL-545...

  • Page 33: Communication Protocol

    The protocol defined in this document is used for all communications between a host computer and an InterRanger IR-200. The protocol allows the host computer to interrogate the unit to obtain information regarding the operation of the instrument. The computer may also program and control the operation of the IR-200 remotely.
  • Page 34 InterRanger IR-200 PL-545...

  • Page 35: Message Format

    Additional bytes in the data field provide the data applicable to each of the message types. Different message types are defined to perform different functions. The message types that are defined for the blanket level detector are defined later in this document. PL-545 InterRanger IR-200...

  • Page 36: Checksum Field

    16- bit sum of all previous byte values (the value of a two hexadecimal digit pair), excluding the start character. The checksum field is two bytes long. It is transmitted most-significant byte first, as four ASCII-encoded hexadecimal digits (“OOOO” to “FFFF”). InterRanger IR-200 PL-545...

  • Page 37: Error Handling

    Messages with data transmission errors must be ignored. if the host computer receives a message that contains a data transmission error, it may retransmit its request to the remote instruments, if desired. PL-545 InterRanger IR-200...
  • Page 38 InterRanger IR-200 PL-545...

  • Page 39: Model Ir-200 Messages

    The message is formatted as follows: Data Length: Message Type: Additional Data: none Expected Reply: Tank Profile Example: The message string “M0401020007” will request a unit answering to address “04” to send a tank profile data message. PL-545 InterRanger IR-200...

  • Page 40: Request Relay Configuration

    Negative Acknowledge Message Example: If the host computer would like to request the value of the GAIN CONTROL parameter (parameter number 11 or 0B hexadecimal) from analyzer number 1, then the host should transmit the ASCII string “M0102050B0013”. InterRanger IR-200 PL-545...

  • Page 41: Change Program Parameter Value

    “Change Mode” message may be used again to restart the RUN mode. The table in Program Parameter Numbers on page 42 indicates which parameters require this special handling. CHANGE MODE This message commands the Model IR-200 to change its current mode of operation to either the RUN or PGM state. PL-545 InterRanger IR-200...

  • Page 42: Program Parameter Numbers

    Relay Number 2 “on” Setpoint Relay Number 2 “off” Setpoint Relay Number 3 Function Relay Number 3 “on” Setpoint Relay Number 3 “off” Setpoint Relay Number 4 Function Relay Number 4 “on” Setpoint Relay Number 4 “off” Setpoint InterRanger IR-200 PL-545...

  • Page 43: Model Ir-200 Originated Messages

    1: Tank depth not set 2: Unable to determine interface level 3: No echoes are being received 4: Interface level not determined, yet. The instrument scale field of the message specifies the current instrument scale used by the Model IR-200. PL-545 InterRanger IR-200...

  • Page 44: Tank Profile

    0.2 feet. There will still be 249 total points, so the maximum depth will now be 49.8 feet. Likewise, byte $FC may be set to a value of 3 or 4, yielding resolutions of 0.3 and 0.4 feet, respectively. InterRanger IR-200 PL-545...

  • Page 45: Relay Configuration

    These values are transmitted in tenths of feet for instrument scales in feet, hundredths of meters for instrument scales in meters, and percent for the percent of tank depth scale. These data formats match those used to transmit the interface level in data report messages. PL-545 InterRanger IR-200...

  • Page 46: Trend Data

    If the transmitted value normally contains decimal places, the position of the decimal point is implied by the normal format of the parameter. For example, a tank depth of 11.2 feet will be reported as a value of 112 or $0070. InterRanger IR-200 PL-545...

  • Page 47: Negative Acknowledge

    This message is a response to a host originated message to indicate that the requested operation was not possible. The message format is as follows: Data Length: Message Type: Additional Data: none Example: Monitor number 2 would respond R0201FF0102. PL-545 InterRanger IR-200...
  • Page 48 InterRanger IR-200 PL-545...

  • Page 49: Interranger Profiling Software

    INTERRANGER PROFILING SOFTWARE InterRanger Software Introduction Hardware Requirements General RS-232 communications RS-485 communications Setup IR200LOG.EXE Software Installation Operation Main Menu Run Mode Profile Viewer Trend Graph Viewer Program Setup Quit MILLTRONICS SOFTWARE LICENSE PL-545 InterRanger IR-200...
  • Page 50 InterRanger IR-200 PL-545...

  • Page 51: Interranger Software

    Up to 40 units can be monitored with this program and the profiles and trend graphs may be saved to disk. HARDWARE REQUIREMENTS GENERAL IR200LOG.EXE runs in VGA color mode and requires a 80286 or higher processor. This program will NOT run on an XT type machine. PL-545 InterRanger IR-200...

  • Page 52: Rs-232 Communications

    Maximum communication distance is approximately 200 m (600’). 3 wire cable Parts » 3 wire communication cable (shielding discretional) » Female DB9 or DB25 RS-232 connector InterRanger IR-200 PL-545...

  • Page 53: Rs-485 Communications

    RS-232 to RS-485 converter (Milltronics Part #20150158) » Converter power supply (Milltronics Part #24900031) » Optional Repeater for distances >4000’ or for 32 to 40 units (Milltronics Part #21500159) » Termination resistor (130 to 150 ohm, 1/2 W) » Three wire communication cable (shielded if required) »...

  • Page 54: Setup

    SETUP For RS-485 communication, the converter (Milltronics Part #20150158) uses 9600 BAUD as its default. Before running the program, ensure that all units are configured for 9600 BAUD rate (See BAUD RATE parameter) and that each has a unique address (See SERIAL ADDRESS parameter). A 9600 BAUD rate must be set in the IR200LOG program as well (See IR200LOG Software).

  • Page 55: Ir200Log.exe Software

    Use a text editor to create a file e.g. IR200LOG.BAT Enter the following text: @echo off C:\IR200LOG\graphics.com C:\IR200LOG\ir200log.exe echo Milltronics IR-200 Profiling Software. Double-click the IR200.BAT file to load the graphics.com utility and run the IR200LOG.EXE program. PL-545 InterRanger IR-200...
  • Page 56 InterRanger IR-200 PL-545...

  • Page 57: Operation

    28 characters (no punctuation) may be entered at this time to identify the profile later and this will become the graph’s title. The date and time that the profile was saved is automatically logged and will always be displayed on the graph. PL-545 InterRanger IR-200...

  • Page 58: Profile Viewer

    All program settings are made from this menu. Type the appropriate number to toggle the setting. 1. COM Port Selection 2. Baud Rate Selection 3. Communication Type 4. Polling Interval 5. Trend Graph Span 6. Activate Unit Address 7. Assign Unit Names 8. Saving Changes InterRanger IR-200 PL-545...
  • Page 59 3 - Communication Type: Select Full Duplex for RS-232 or RS-422 communication.” This setting will work for RS-232 communication and for RS-485 communication using the Milltronics RS-232 to RS-485 converter (Milltronics Part #20150158). Select Half Duplex for RS-485 communication” if using an older style RS-232/RS-485 converters that does not have transmission on/off switching built in.

  • Page 60: Quit

    8 - Saving changes: Saves all settings in this menu that have been changed or verified, and returns to the Main Menu. QUIT Q = Quit (to return to DOS) Ends the program and returns to DOS. InterRanger IR-200 PL-545...

  • Page 61: Milltronics Software License

    2. COPYRIGHT. The SOFTWARE and its manual is owned by Milltronics or its suppliers and is protected by United States copyright laws and international treaty provisions. Therefore, you must treat the SOFTWARE like any other copyrighted material (e.g., a book or musical recording) except that you may either (a) make one copy of the SOFTWARE solely for backup or archival purposes, or (b) transfer the SOFTWARE to a single hard disk provided you keep the original solely for backup or archival purposes.
