Summary of Contents for PAX Computer Technology BP60A
- Page 1 BP60A（Multifunction Printing Base）Product Instruction PAX Computer Technology（Shenzhen）Co., Ltd.
- Page 2 1. Appearance Instruction Front Charging Contact...
- Page 3 Back Rubber Rubber Foot Foot SNBar Code NameplateLaser Etching Rubber Rubber Foot Foot...
- Page 4 USB2 USB1 RS232 POWER...
- Page 5 The matching diagram for A60 host and intelligent printer base is as follows: 2. Installation Instruction 1）Connect the base's DC port with a 9V/1A power adapter. 2） Use a network cable to connect the base's LAN port with a gateway device that can access the Internet, such as router, LAN switch.
-
Page 6: Terminal Specifications
4. Terminal Specifications Power supply：DC-9V@1A Ethernet：10/100Mbps adaptive network port RS-232 serial port: Maximum transfer rate115200bps USB port：USB2.0 HOST Port Instruction: DC port x 1: Power port TYPE AUSB x 2:USB2.0 Host port, used to connect the scanner gun or keyboard RS-232serial port x 1 : RJ45-8P8C Ethernet x 1 :RJ45-8P8C Working Environment: Working temperature：0℃～50℃... - Page 7 any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
