Summary of Contents for AKG S20 UIS V0.2
- Page 1 AKG S20 UIS V0.2 Alexander.Efimov@harman.com Greta.Vendrell@harman.com Nov 29 2017...
-
Page 2: Revision History
Revision History Date Version Update made to document 2017.11.28 V0.1 1. Overal initial version of UIS 2017.11.29 V0.2 1. Remove HFP function and BT social pairing TBD... - Page 3 ID Design Power ON/OFF Bluetooth Connectors: Volume + Volume - Connectors: Type C...
- Page 4 Touch Panel Behaviour Touch Panel Short Press Long Press Decrease volume by 1 step Decreasing volume quickly 17 (0-16, 0 means mute) steps on iPhone press to trigger press and hold >=1 sec Volume - 17 (0-16, 0 means mute) Increase volume by 1 step Increasing volume quickly steps on iPhone...
- Page 5 LED Behaviour LED Status Off White, Constant White, Slow Flash Red, Constant White, Quick Flash Red, Regular Flash Battery >15% + Fully charge Low battery <15% Charging Power Power Off Off Off Red, Constant (inactivate for 15 minutes or batterry < 5%) Bluetooth Power On/ BT not connected White, Slow Flash...
- Page 6 Need BT connection with phone Priority higher (Bluetooth > Aux) LED indication: blue BT Logic Bluetooth name is “AKG S20” Speaker will try to reconnect last paired phone for 3 mins every time when power on When lost BT connection...
- Page 7 Bluetooth social pairing 2 mobiles can be connected in bluetooth social pairing, the last connected mobile will take control. If more than 2 mobiles added, the initially connected mobile will be removed and last connected one will join.
- Page 8 Audio Feedback table Kinds Action Power Power on Power off Enter BT pairing mode Bluetooth BT succussfully Connected Others Volume_Max...
