- Page 1 YOUR PERSO N AL TREATMENT QUICK REFERENCE GUIDE = 810 nm λ P= 2 Watt INSTRUCTIONS FOR USE www.my-doc.it www.my-doc.it...
- Page 3 Project management: Medical Treatment and Protocols Dr. Pier Francesco Parra Design and Development Ing. Giannino Algeri www.my-doc.it...
-
Page 4: Table Of Contents
INDEX OVERVIEW ......................06 CONTROLS AND INTERFACE .................07 DESCRIPTION OF ITEMS ..................08 THE DISPLAY ......................09 CONTROL KEYS ....................09 INSERTING THE PASSWORD .................09 ASSISTANCE AND ADVICE ................10 TECHNICAL DATA: EXTERNAL POWER SUPPLY ........11 TECHNICAL DATA: AG6 LASER MODEL DOCLASER® SPORT ..11 INSTRUCTIONS FOR DISPOSAL ..............11 PROCEDURE FOR USE ..................12... -
Page 5: Www.my-Doc.it
MANAGEMENT AND CONTROL OF PROTOCOLS WHEN RESULTS PRESENT A SIGNIFICANT DIFFERENCE WITH RESPECT TO THE ESTABLISHED MATHEMATICAL MODEL ..................22 MANAGEMENT OF MEMORY SPACE ............23 MANAGEMENT OF ALARM MESSAGES ............24 GENERAL RULES FOR CORRECT USE ............25 ARCHITECTURE OF THE EXCLUSIVE DOCLASER® PROTOCOL (NOTES) ........................26 www.my-doc.it... -
Page 6: Overview
OVERVIEW DOC LASER® is a Class-IV laser device, certified and classified as a medical instrument in Class 2b (93/42/EEC, 47/2007EEC). It differs from normal therapeutic laser instruments as it is designed to provide for ‘self-administered treatment’. The software installed is of the interactive type;... -
Page 7: Controls And Interface
CONTROLS AND INTERFACE Charge indicator (LED) Socket for battery-charger Extractable fuse switch jack plug disconnector Ventilation slots Laser beamer Emergency stop button Display Interactive controls Switch on/off www.my-doc.it... -
Page 8: Description Of Items
DESCRIPTION OF ITEMS Ventilation slots. These spaces allow for thermal exchange between the internal heat spreader and the environment thanks to the convective movement of air. The slots must be kept free at all times; make sure they are never obstructed by any kind of adhesive or other material. -
Page 9: The Display
‘beep’ is heard, indicating that the ‘switch-off’ command has been activated. INSERTING THE PASSWORD In the phase in which operation is enabled only the directional keys are used; if the password is correct, the device will allow access to the following pages. www.my-doc.it... -
Page 10: Assistance And Advice
ASSISTANCE AND ADVICE If one of the following windows appears on the screen of your DOC LASER device while it is being used, please consult the User Manual. If the restore operation fails and a solution cannot be found, forward an e-mail message to our technical department areatecnica@lasertlr.com. -
Page 11: Technical Data: External Power Supply
www.my-doc.it... -
Page 12: Procedure For Use
PROCEDURE FOR USE 1. Switch on the device by pressing the ‘OK’ key for about 5 seconds 2. At the first start-up select language 3. Wait until the software asks you to insert the password 4. Insert the password (sequence of 4 keys) SELECT LANGUAGE ITALIANO ENGLISH... -
Page 13: Change Language And Restore Factory Configuration
Be carefull, this action will reset all settings and memories: DO YOU WANT TO RESET TO THE VUOI RIPRISTINARE DEFAULT CONFIGURATION? LA CONFIGURAZIONE PA S S W O R D Sequence requested as a password DI FABBRICA? Down Right Left www.my-doc.it... -
Page 14: Treatment
TREATMENTS Your DOCLASER SPORT device contains 30 treatment protocols, 8 of which are not ® directly associated with pain presenting in specific anatomical areas, 3 of which refer to physical problems arising in various parts of the body and 3 protocols (very important and to be adopted only under the guidance of a physician) are proposed for one of the very special benefits produced by laser tissue bio-stimulation: pain-reduction, an anti- inflammatory effect and decontraction. - Page 15 The operator is asked to confirm the painful area selected. If an anatomical area cannot be found, it is possible to repeat the search if necessary. At the third attempt (second repetition) the software will automatically activate the switching-off procedure. www.my-doc.it...
- Page 16 SCEGLI L’AREA SPECIFICA DO YOU WANT TO CONTINUE IDENTIFY THE SPECIFIC AREA AND SEARCH AGAIN FOR A TREATMENT PROTOCOL? MAYBE NON HA IL DOESN’T HAVE THE CHE SERVE AL TUO CASO PROGRAM YOU NEED OTHER OPTIONS ALTRE OPZIONI non ha effetti has no ionizing ionizzanti e le effects ant the...
-
Page 17: Checking Correct Operation Of Contact Sensors
Simply rest the laser emission point on the palm of the hand and LASER LASER check for correct switching (‘on’ / off’) of all four sectors. START TREATMENT www.my-doc.it... -
Page 18: Verifying The Intensity (2 Watts) Of Emitted Power
VERIFYING THE INTENSITY (2W) OF EMITTED POWER CHECK LASER EMISSION After verifying that the contact sensors are functioning Bring the active part of the laser into contact properly, the power emitted by the laser will checked. In with the palm of your hand. -
Page 19: Overview Of Treatment Management
The ‘scattering’ effect will ensure the laser reaches underlying tissues. A light rotating movement can be attempted if it is found that the skin is subject to excessive heat. Also for the treatment of small surface areas (e.g. finger interphalangeal articulation) the laser should be kept focused. www.my-doc.it... -
Page 20: Treatment After The First Session
YOU ARE FOLLOWING TREATMENT NUMBER reminded of the number of repetitions of the treatment TRATTAMENTO NUMERO protocol established on the basis of a patented My-Doc 1 / 2 1 / 2 algorithm. If the user does not follow the preset protocol... -
Page 21: Notes On Protocol Management
(area of pain and new intensity). THE OPERATOR SHOULD CONFIRM YOUR CHOICE EVALUATE THE VARIATION OF PAIN PREVIOUS CURRENT PAIN PAIN FRONT SHOULDER PAIN VERY INTENSE PAIN www.my-doc.it... -
Page 22: Management And Control Of Protocols When Results Present
MANAGEMENT AND CONTROL OF PROTOCOLS WHEN RESULTS PRESENT A SIGNIFICANT DIFERENCE WITH RESPECT TO THE ESTABLISHED MATHEMATICAL MODEL On the basis of exclusive DOC LASER® algorithms, the system monitors the progress of treatment, assessing whether it is necessary to suspend therapy before the end of a planned series of sessions on the basis of evidence that it is not effective or whether it is quite obviously successful and no longer necessary. -
Page 23: Management Of Memory Space
SPORT is proposed as an ideal solution for the problems it is designed to ® treat. You will find this instrument extremely useful for safeguarding the wellbeing of your family, your friends, members of your team or fellow athletes. www.my-doc.it... -
Page 24: Management Of Alarm Messages
MANAGEMENT OF ALARM MESSAGES A L A R M C H E C K C O N T R O L L O A L L A R M I C O N T R O L L O A L L A R M I A L A R M C H E C K D I S P L AY C H E C K B AT T E R I A... -
Page 25: Architecture Of The Exclusive Doclaser® Protocol
It is forbidden to force, modify or try to ignore the content of the messages that are generated. Otherwise, My-Doc cannot be held liable for any unsuccessful outcome. ARCHITECTURE OF THE EXCLUSIVE DOCLASER SPORT ®... - Page 26 ARCHITECTURE OF THE DOCLASER SPORT PROTOCOL (DATA ® ACQUISITION) Insert user’s details (height, weight, age) Indicate painful area of body and evaluation of its intensity (classification) Evaluation of any Is this the first VARIATION of the session of the day? pain Wait for 10 Elementary treatment...
- Page 27 RICERCHE E COLLAUDI M. Masini. Bergamo, 11 March 2011 Technical Manager Ing. Palo Milanesi Registered Offices: TLR s.r.l. u. via Amighetti n.2/a Touch Life Rehab 24125 Bergamo Italy VAT (I) 03245230165 www.lasertlr.com tel. 035 4523869 - fax 035 2922884 www.my-doc.it...
-
Page 28: Notes
NOTES ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................ - Page 29 We should therefore be very grateful if you would kindly fill in our ‘customer satisfaction’ questionnaire. We thank you in advance for your assistance. On receipt of your response we will assign an extension of 4 months to your warranty. www.my-doc.it...
- Page 30 CUSTOMER SATISFACTION LOGISTICS Excellent Good Average Poor Unaccettable Delivery dates respected Flexibility and attention paid to clientele Quality of packaging materials and delivery method PRODUCT QUALITY Excellent Good Average Poor Unaccettable No defects or malfunctioning Easy to use Adequate and complete instructions for use Effective OTHER OBSERVATIONS OR SUGGESTIONS ................
- Page 31 www.my-doc.it...
- Page 32 Help Line +39 (0)444 320 998 Rev. 02 22 07 2011 www.my-doc.it...
