Summary of Contents for Dzyne Tuw
- Page 1 EN V1.01 PV tůw Smartwatch USER GUIDE For the full smartwatch and App User Guide use your smartphone to SCAN this QR code or visit: ByDzyne.com/UserGuides (available in multiple languages)
- Page 2 Tracking Ůr Wellness...
- Page 3 Welcome to your innovative wellness tracker, the tůw Smartwatch from ByDzyne - an intelligent device specifically designed to monitor your daily lifestyle, helping you to improve your overall wellness.
- Page 4 What’s Included In The Box tůw Smartwatch Device with Stainless Steel Black Band • • Additional Stainless Steel Silver Fashion Band • USB Charger (USB-supported adapter not included) • Smartwatch User Guide • App & Languages Insert *Please read the full User Guide prior to use.
- Page 5 tůw Smartwatch Features List Smartwatch Features Fitness Dashboard Countdown Timer Heart Rate Monitor Find Phone Sleep Monitor Stopwatch Bluetooth 5.0 Sport Mode IP67 Waterproof 1m 200mHa Battery *Extra features are also available via the tůw Smartwatch App.
- Page 6 Get To Know Your tůw Smartwatch On/Off Green PPG LED & skin contact sensors for taking measurements. When the sensor is on, a green LED is displayed. Copper contact points for charging Stainless steel, fully adjustable band...
-
Page 7: Table Of Contents
Table Of Contents This smartwatch Charging Your Smartwatch & Battery Life ..........7-8 Putting On Your Smartwatch & Changing The Band ....9-10 is designed to be On / Off / Wake Up ....................11-12 utilized with the Feature Navigation ....................13-14 tůw Smartwatch •... -
Page 8: Charging Your Smartwatch & Battery Life
Charging Your Smartwatch Remove the included USB charger from underneath the insert holding your smartwatch (in the box). Connect the USB cable to any USB-supported charging device (output: 5V 1A). On the backside of the watch align the copper contact points with the copper points on the charging base. - Page 9 Battery Life When the smartwatch’s battery is low, the red lightning bolt icon will appear when you touch the display screen. When the battery is completely exhausted, the smartwatch will automatically turn off. Once placed on the charger, it will automatically turn on.
-
Page 10: Putting On Your Smartwatch & Changing The Band
Putting On Your Smartwatch Your tůw Smartwatch is designed with an adjustable magnetic strap. Simply slide the band through the watch brackets to lengthen. Once on your wrist, pull the magnetic buckle strap tight, then let it rest on the strap. Changing The Band 1. - Page 11 2. Locate the spring-loaded pins in the bracket. One at a time, slide the pin’s knob inwards towards the center and tilt to detach the bracket from the shoulder of the device. 3. Once separated, remove the two pins and insert them into the brackets on your new band.
-
Page 12: On / Off / Wake Up
On / Off / Wake Up To turn on your tůw Smartwatch, simply press and hold the side button for 3 seconds. The smartwatch will vibrate and the tůw logo will appear. To turn off your smartwatch, simply press and hold the side button for 3 seconds until the tůw logo disappears. - Page 13 Wake Up To wake up the smartwatch screen either tap the display screen, press the side button, or rotate your wrist. To change the length of time the display is awake, its sensitivity, and to change other features, refer to the App User Guide.
-
Page 14: Feature Navigation
Feature Navigation Clock/ Fitness Heart Sleep Home Dashboard Rate Data Swipe Left to Right or Right to Left Various features & notifications of the smartwatch are turned on by default when shipped, and can be customized through the App. Go to ByDzyne.com/UserGuides to download the App User Guide. - Page 15 Countdown Find Stopwatch Sport Power Timer Phone Mode Swipe Left to Right or Right to Left...
-
Page 16: Clock / Home
Clock / Home The clock face is your home screen. Swipe your finger up or down across the display screen to change the look of the home screen to that of your choice. To navigate to the various tůw Smartwatch features, simply swipe your finger left to right (or right to left) across the display screen. -
Page 17: Fitness Dashboard
Fitness Dashboard From this screen, get a snapshot of your daily fitness progress including your current daily steps, calories burned, and the distance walked/ran. Use this feature to reach your daily fitness goals. The default goal is set to 9,000 steps*. To view your entire Fitness Dashboard history download and use the tůw Smartwatch App. -
Page 18: Heart Rate Monitor
Heart Rate Monitor This intuitive heart rate feature measures the user’s latest heart rate in real time, in beats per minute, along with a graph of your average heart rates throughout the day. Swipe left or right to access the screen and the measurement will begin. After a few seconds, the results will be displayed and continue to take measurements in real time. -
Page 19: Sleep Data Monitor
Sleep Data Monitor The sleep feature detects when you begin to go to sleep and when you wake up. It accurately and automatically records and displays total sleep duration, including deep and light sleep durations, over a 24 hour period. The smartwatch will display your sleep time and quality of sleep from the last recorded night. -
Page 20: Countdown Timer
Countdown Timer The Countdown Timer is a great feature for interval training. Press “START” and the timer will begin to countdown. Upon reaching zero the smartwatch will vibrate until you press “RESET.” You may also use the pause and resume buttons during an active countdown. -
Page 21: Find Phone
Find Phone When the Find Phone feature is set to ON via the App (feature is ON by default), a user can locate their mobile phone through their smartwatch by touching the Find Phone icon once. If the mobile phone and smartwatch are connected via Bluetooth®... -
Page 22: Stopwatch
Stopwatch Use the built-in stopwatch feature to time your fitness activities easily with one touch. To start the timer, touch the green icon on the bottom-right once and the icon will turn red. Touch the red icon once to pause the timer. To reset the time, touch the gray icon on the bottom- left once. -
Page 23: Sport Mode
Sport Mode Start your workout with the Sport Mode feature to track your elapsed activity time, calories burned (kcal), real-time heart rate (bpm) and steps taken. To begin tracking, press once to activate the sport mode. To lock, pause, or exit, simply swipe your finger once from left to right, then click the appropriate icon. -
Page 24: Extra Features Via The App
Extra Features Via The App In addition to the features on your smartwatch, the following extra features are available for use and customization via the tůw Smartwatch App. • Alarm Clock • Automated or Manual Monitoring • Heart Rate Alert •... -
Page 25: Care & Cleaning
Care & Cleaning Your tůw Smartwatch and black band is designed to be worn day and night. It is important to keep the smartwatch’s sensor clean to ensure an accurate measurement. Wipe the smartwatch face, smartwatch back, and the band with a non-abrasive, lint-free cloth (if necessary, lightly dampen the cloth with fresh water). -
Page 26: Specifications & Material
Specifications & Material Supports Android 5.1 or IOS 8.0 or Above Display: IPS 1.22” Color Touch Screen, 240*240 Main Chip: NRF 52832 Battery: 200mAH Li-Polymer Battery IP67 Waterproof 1m Smartwatch front: Tempered Glass Smartwatch back: Polycarbonate Bands: Stainless steel with N52 NdFeB Magnet (neodymium iron boron) Detachable Quick Release Band... -
Page 27: Product Disclaimer, Warranty, Fcc Compliance
Product Disclaimer The tůw Smartwatch is a general wellness product intended to promote physical fitness by tracking exercise and aerobic activity. The tůw Smartwatch is not a medical device and is not intended to be used in the diagnosis, monitoring, prevention, or treatment of disease. You should not use this information to diagnose or treat a health problem or disease without consulting with a qualified healthcare provider. - Page 28 One-Year Warranty ByDzyne warrants that during the warranty period of one year from the original date of purchase, the included hardware product and accessories will be free from defects in materials and workmanship. The one-year warranty does not warrant against normal wear and tear, nor damage caused by accident, improper use and storage, and unauthorized repair or modifications.
- Page 29 FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: (a) this device may not cause harmful interference, and (b) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 30: Bydzyne.com
ByDzyne.com/tuw...
